AMX MODERO NXT-CA12 Dimension Manual

NXD-CV12
NXD-CA12
UNLESS OTHERWISE SPECIFIED:
NOTICE: This drawing is the
property of AMX Corporation.
TOLERANCE ON DECIMAL DIMENSIONS: XX = .010
All information contained herein
XXX = .005
that is not generally known
TOLERANCE ON HOLE DIAMETERS:
UNDER .250 ú = +/- .005
shall be confidential except
.250 TO .500 = +.006 -.005
to the extent the information
OVER .500 = +.008 -.005
has been previously established.
FRACTIONAL DIMENSIONS INCLUDING HOLES: +/- 1/64
ANGLES: +/- 1.0°
This drawing may not be copied,
SURFACE FLATNESS .003 TIR PER LINEAR INCH.
reproduced, or used as the basis
ALL DIMENSIONS IN INCHES.
for manufacture or sale without
DO NOT SCALE THIS DRAWING.
written permission.
REVISIONS
REV ECN DESCRIPTION
A 4253 RELEASE TO PRODUCTION
REL APPR REL DATE REV APPR
DRAWN J.L. 09-30-02
ENGR SERV JM 10/11/02
PICTORIAL
ENGINEER PL 10/11/02
NXT-CV12, AND NXT-CA12, MODERO 12.1"
PROD ENGR
MAS 10/11/02
COLOR ACTIVE TILT
MATL SUP MP 10/11/02
QUALITY AVT 10/11/02 SIZE SCALE: DWG. NO.
95-2250-11
D 1/2
THIRD ANGLE
PROJECTION
95225011A
DATE APPROVED
10/14/02
REV.
A
SHEET 1 OF 1
