Operating & Service Guide
Keysight 85059G
1.0 mm Connector Gage

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 85059G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Keysight 85059G

Summary of Contents for Keysight 85059G

  • Page 1 Operating & Service Guide Keysight 85059G 1.0 mm Connector Gage...

  • Page 2: Safety Notices

    DOCUMENT OR ANY INFORMATION reproduce, release, perform, CONTAINED HEREIN. SHOULD display, or disclose commercial KEYSIGHT AND THE USER HAVE A computer software or SEPARATE WRITTEN AGREEMENT commercial computer software WITH WARRANTY TERMS COVERING THE MATERIAL IN THIS...

  • Page 3: In This Manual

    Assistance with test and measurements needs and information on finding a local Keysight office are available on the Web at: http://www.keysight.com/find/assist If you do not have access to the Internet, please contact your Keysight field engineer. In any correspondence or telephone conversation, refer to the Keysight product by its model number and full serial number.

  • Page 4: Printing Copies Of Documentation From The Web

    85059G 1.0 mm Connector Gage Getting Assistance from Keysight If You Have Problems With the Connector Gages Kit Contents Keysight stands behind the quality of the connector gages kit contents. If you have problems with any item in the kit, refer to www.keysight.com and the Contact Keysight link.

  • Page 5: Safety And Regulatory Information

    85059G 1.0 mm Connector Gage Safety and Regulatory Information Safety and Regulatory Information Review this product and related documentation to familiarize yourself with safety markings and instructions before you operate the instrument. This product has been designed and tested in accordance with international standards.

  • Page 6: Instruments Covered By Manual

    Keysight 85059G connector gage. The Keysight 85059G connector gage is used to measure connector pin depth of 1.0 mm connectors. The connector gage kit contains the following. — 1.0 mm connector gage (male) —...

  • Page 7: Specifications

    Each gage set is mechanically measured at the factory. These factory measurements are traceable to the U.S.A. National Institute of Standards and Technology (NIST) through mechanical paths. For more information on NIST traceability, contact your nearest Keysight Technologies office. Operating and Service Guide 85059-90015...
  • Page 8 85059G 1.0 mm Connector Gage Specifications Table 2 Specifications, Characteristics, and Conditions Comments Specifications Specified Limits Indicator calibration accuracy 0.00012 in (0.003 mm) From manufacturer specifications Indicator repeatability From manufacturer specifications 0.000079 in (0.002 mm) Typical Characteristics Typical Limits Master repeatability 0.00002 in (0.0005 mm)
  • Page 9 85059G 1.0 mm Connector Gage Specifications Table 3 Example when measuring adapters Device Typical Pin Depth Measurement Observed Pin Depth Guard Banded Pin Depth Uncertainty Limits Limits Adapter –0.0002 to –0.0010 in ±0.0002 in –0.0000 to –0.0012 in –0.0004 to –0.0010 in –0.0040 to –0.0240 mm...

  • Page 10: Installation

    Containers and materials identical to those used in factory packaging are available through Keysight Technologies offices. If the gage kit is being returned to Keysight for calibration or service, attach a tag indicating the type of service required, return address, model number, and serial number. Also, mark the container FRAGILE to assure careful handling.

  • Page 11: Operation

    85059G 1.0 mm Connector Gage Operation Operation Operating Environment Device dimensions change with temperature. Therefore, the temperature of the gages and all connectors must be stable (within ±l °C) before calibration. The operating environment for the connector gage should be within the following limits.
  • Page 12 85059G 1.0 mm Connector Gage Operation Using Connector Gages Before using the connector gages, they must be inspected, cleaned, and zeroed. See also, ID-C112X/1012X and ID-C112CX/1012CX. IMPORTANT! Before you make a measurement, verify the gage is not displaying REV (Reverse) H (Hold). Refer to...
  • Page 13 85059G 1.0 mm Connector Gage Operation Overview of Gage Features Figure 1 85059G Connector Gage Features –Mode –Set –Data (ON-OFF) –Current Mode: INC –Current units: mm –Measured value display area 85059-60100 Female Gage Set 85059-60101 Male Gage Set Operating and Service Guide 85059-90015...

  • Page 14: Changing The Battery

    85059G 1.0 mm Connector Gage Operation Changing the Battery For this procedure, refer to Figure 2 on page 15. Use a silver oxide battery (SR44). - If the battery holder is not set properly, the instrument may not display the correct value or a malfunction may result.
  • Page 15 85059G 1.0 mm Connector Gage Operation Figure 2 Installing / Changing the Battery Installing the battery case with battery (top view) Battery installed (bottom view) Battery case and battery (before installing–top view) Battery case and battery (before installing–bottom view) Operating and Service Guide 85059-90015...

  • Page 16: Measurement Mode

    85059G 1.0 mm Connector Gage Operation Measurement Mode The gages have two measurement modes: ABS (Absolute) and INC (Incremental). Do not use ABS for pin depth measurements. For this section, refer to Figure 3 on page Figure 4 on page...
  • Page 17 85059G 1.0 mm Connector Gage Operation Figure 3 85059G Preset Condition After Battery is Changed / Installed and Setting INC Mode 1) Battery installed. Display is flashing. P is blinking. No mode displayed. (I.e., Preset condition) 2) SET button pressed 1st time. Zeros are displayed and P is flashing.

  • Page 18: Zeroing The Gage

    85059G 1.0 mm Connector Gage Operation Zeroing the Gage IMPORTANT! Before you make a measurement, verify the gage is not displaying Hold or REV. Refer to Figure 5 on page 20 Figure 6 on page Gage does not measure zero when initially connected to the gage masters and prior to zero set.
  • Page 19 85059G 1.0 mm Connector Gage Operation Figure 4 85059G Connector Gage with Master Gage - Before and After Zeroing Press SET button to zero the gage. Gage before zeroing Gage after zeroing Gages should be checked often, to make sure that the zero setting has not changed.
  • Page 20 85059G 1.0 mm Connector Gage Operation Figure 5 85059G Exiting REV (Reverse) Mode 1) Down arrow indicates gage is in REV mode. 2a) Hold MODE button until "dir" (direction) is displayed and flashing. 2a) Then press SET button. Now the down arrow is flashing, but "dir"...
  • Page 21 85059G 1.0 mm Connector Gage Operation Figure 6 85059G Exiting Hold ("H") Mode Press the DATA button to exit the Hold ("H") mode. Measuring Connectors IMPORTANT! Before you make a measurement, verify the gage is not displaying H (Hold)or REV (Reverse). Refer to...
  • Page 22 85059G 1.0 mm Connector Gage Operation Enabling/Disabling the Gage IMPORTANT! - The gage powers up in the previous Measurement mode that was set before power down. Refer to “Measurement Mode” on page - If the gage does not power up when the DATA ON/OFF button is pressed, the battery might be exhausted.

  • Page 23: Replaceable Parts

    85059G 1.0 mm Connector Gage Replaceable Parts Replaceable Parts All replaceable parts are shown in Figure Table 3 on page 12, and Figure 8 on page 25. There are no internal replaceable parts within the Gages themselves. Figure 7 85059G Connector Gage with Accessories...
  • Page 24 Miscellaneous Items Operation and Service Guide 85059-90015 Protective end caps as required 1401-0202 a. See Connector Care, refer to http://literature.cdn.keysight.com/litweb/pdf/85051-90032.pdf. b. Refer to Figure 1 on page 13 and to Figure 7 on page c. Refer to “Printing Copies of Documentation from the Web” on page...
  • Page 25 85059G 1.0 mm Connector Gage Replaceable Parts Figure 8 Replaceable Parts for the 85059G Connector Gage Kit (Not all items are shown below. For a complete list, refer to Table 4 on page 24.) 6 mm 14 mm Service Do not attempt to repair the gage or gage master. Any attempt to do so will void warranty.
  • Page 26 85059G 1.0 mm Connector Gage Replaceable Parts Operating and Service Guide 85059-90015...
  • Page 27 Installation Note Xxxxx-xxxxx...
  • Page 28 This information is subject to change without notice. © Keysight Technologies 2018-2020 Edition 1, December 2020 www.keysight.com...
