U4206A
Probe Cable
Quick Start and Accessory Guide
Socket Adapter
3-Pin Header
Kit Of 34 Pieces
Kit Of 34 Pieces
E5381-82102
E5381-82104
Logic Analyzer
Connection Pods
Tip Resistor
82 ohm Coaxial
Kit Of 34 Pieces
E5381-82101
PROBE CABLE ASSEMBLY
34 Channel, Soft Touch Pro, Single-Ended,
Quad x 160-Pin Direct Connect
Soft Touch Pro
Retention Module
Kit Of 5 Pieces
E5405-68702
Clock Qualifier Connections
Soft Touch Pro
Connector
82 Ohm Resistor
Template
1 Piece
01131-94309
Pin Protector
Extra E5390-25201 Pin
Protectors are included
DO NOT DISCARD THIS
PIN PROTECTOR
To protect the Soft
Touch Pro pins from
being damaged, use the
Pin Protector when
probe is not connected.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Keysight U4206A
Summary of Contents for Keysight U4206A
- Page 1 U4206A Probe Cable 34 Channel, Soft Touch Pro, Single-Ended, Quad x 160-Pin Direct Connect Quick Start and Accessory Guide Socket Adapter 3-Pin Header Tip Resistor Soft Touch Pro 82 Ohm Resistor Retention Module 82 ohm Coaxial Template Kit Of 34 Pieces...
- Page 2 Total Lumped Input C 1.0 pF Total Lumped Input C 1.1 pF Detailed information on the U4206A Probe Cable is available at http://www.keysight.com/find/U4206A. On this webpage, click the Document Library tab and download the user guide. © Keysight Technologies 2015...
