Chapter 4: PLC Communications
C-1

C-1: USB Port Setup

The CLICK PLUS USB port is only used to connect to the CLICK programming software.
When a CLICK PLUS device is first connected to a USB port on a Windows PC, a driver is
loaded to allow the CLICK PLUS device to emulate a standard serial port. The CLICK PLUS
will show up as a USB Serial Device in under Ports in Windows Device Manager.
To connect via USB port, click Connect in the PLC menu, then select USB as the port type.
Select the COM port assigned to the USB Serial Device. All other parameters can be left at
their default settings.
