Tigersecu 402 Series Manual

Video surveillance recorder
Hide thumbs Also See for 402 Series:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 402 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Tigersecu 402 Series

Summary of Contents for Tigersecu 402 Series

  • Page 2: Chapter 1: Important Information

     Contact Us: If you require any assistance with your new TIGERSECU product, we're here for you. Your TIGERSECU product is backed by a full two-year warranty and Lifetime Support and we may be reached by phone, email, or through your Amazon Customer Order Messaging page.

  • Page 3: Chapter 2: Installation Guide

    Chapter 2: Installation Guide 1. Connect the cameras with the DVR A) Prepare the DVR, cameras, 5-way/9-way power splitter, BNC cables and the power adapter(s). (Do not plug in the power adapter to a power source now.) B) Connect the cameras using BNC cables to the video in CH1 to CH(x) connectors. C) Connect 5-way/9-way power splitter to the power adapter.
  • Page 4 B) Power on the monitor. C) Connect the mouse to the USB slot on the DVR back panel. D) You will see TIGERSECU LOGO in a few seconds, then the Start-up wizard. E) The Start-up wizard will guide you through the basic settings.

  • Page 5: Chapter 3: Motion Detection Settings

    Chapter 3: Motion Detection Settings Go to Setting Page Step 1. Click Menu. Step 2. Go to the Motion. (Menu Alarm Motion) Motion Settings Step 1. Enable Motion and Buzzer. DVR will beep when motion is detected. Step 2. Set up sensitivity level (0 to 7, from lowest to highest). Step 3.

  • Page 6: Video Loss Settings

    Video Loss Settings  Show Full Screen: The selected channel will show full screen when the channel lost the feed from its camera.  To Alarm Out: Disabled for this model. No need to change.  Buzzer: You will hear beeps when the channel lost the feed from its camera. ...
  • Page 7 Step 2. Set up Start Time & End Time. Click Add, select the time you want to record. Add or delete when you need to modify or choose more than one period. Step 3. Copy to other Channel and Day. Then Apply. You may copy the settings to all channel or set each channel individually.

  • Page 8: Chapter 4: Playback And Backup

    Chapter 4: Playback and Backup Playback Step 1. Go to Playback. (Menu Playback Playback) Step 2. Choose the date of Start Time. Click Search. Blue squares indicate that there are recordings. Choose start time by clicking the blue area and then click playback.
  • Page 9 Step 3. Choose recordings you want to backup. Click Backup. Step 4. Choose the file type to be saved as (H264/AVI/WAVE). Click Start. Wait Until Backup Finished.

  • Page 10: Chapter 5 View Remotely Via Chere (Mobile App)

    Chapter 5 View Remotely via CHere (Mobile App) 1. Preparation Step 1. Download App: CHere Scan QR Code below to download CHere from Google Play / App Store on your phone. Step 2. Check Network Access and Cloud. (Menu System Information) Please ensure that network cable is firmly connected, then check whether Cloud is connected.
  • Page 11 Step 2: Scan QR code Open CHere on your phone/tablet, choose Scan QR code. Then scan the QR Code on the DVR monitor. Step 3: Login. Fill in the username and Password (not required for Android Devices) Default Username: admin Default Password :00000000 Click Login.

  • Page 12: Chapter 6 View Remotely Via Web Browser

    Chapter 6 View Remotely via Web Browser 1. Preparation Step 1. Make sure the network connection is good. Step 2. Download the plugin. Open web browser on your computer, then type in http://www.easyconfigure.com. Download and install the plugin. *Chrome and Firefox may NOT support the plugin. Maxthon (a web browser) is highly recommended. Download Maxthon from here: http://www.maxthon.com Step 3.
  • Page 13 2. View via P2P Login Step 1: Choose Login type. (P2P Login) Step 2: Find the UID for your DVR. (Menu Network QR code) Step 3: Fill in other information. Username is admin. Type in the password you set (default password is 00000000). Click Login. Enjoy viewing!

  • Page 14: Chapter 7: View Remotely Via Cms

    1. Preparation Step 1. Make sure network connection is good. Step 2. Download and install CMS software via the link here: http://www.tigersecu.com/CMS/client.zip Step 3. Run CMS. After plugin is successfully installed, run the software, you're supposed to see the page below.
  • Page 15 Step 3. Right Click Device, then click Open All Channels. Enjoy viewing! Scan ME for the Detailed Version User Guide * You will also receive the detailed version of user guide from us via Amazon message to your email! http://www.tigersecu.com/DVR/1080P/USERGUIDE Copyright © TIGERSECU, INC. All Rights Reserved.

This manual is also suitable for:

302 series102 series
