- Page 1 960P and 1080P HD Video Security DVR System User Manual www.tigersecu.com Copyright © 2017 TIGERSECU, Inc...
- Page 2 Contents Contents ....................1 3. Advance ..................14 Important Information .................3 Playback Menu ......................14 Installation Guide.…................4 1. Playback ................... 14 Chapter 1. Start-up Wizard ..............6 2. Image ....................16 Chapter 2. Live View Screen ..............7 3. Backup ....................17 Status Icons ....................8 Network Menu ..................18 Menu Bar Icons .................
- Page 3 Contents 2. User ..................... 21 3. Time ................... 22 Maintain Menu ..................23 1. Maintenance ................23 2. Import/Export ................23 3. Upgrade ..................24 4. Log ....................24 5. Information ................24 Chapter 4. View DVR remotely on your phone …......25 1. Preparation ...................26 2.
-
Page 4: Important Information
Contact Us cameras and to comply with the applicable laws and regulations. Thank you for purchasing a TIGERSECU Security product. If you require any assistance with your new TIGERSECU product, we're here for you. Your TIGERSECU product is backed by a full two-year warranty and Lifetime Support and we may be... -
Page 5: Installation Guide
Installation Guide 1. Connect the cameras with the DVR 2. Connect the Network Cable with the DVR (Network cable not included in the package) Prepare the DVR, router and network cable. Connect the network cable as above. 3. Connect a display device to the DVR (VGA/HDMI cable not included in the package) A) Prepare the DVR, cameras, 5-way/9-way power splitter, BNC cables and the power adapter(s). - Page 6 B) Power on the monitor. C) Connect the mouse to the USB slot on the DVR back panel. D) You will see TIGERSECU LOGO in a few seconds, then the Start-up wizard. E) The Start-up wizard will guide you through the basic settings.
-
Page 7: Chapter 1. Start-Up Wizard
Chapter 1: Start-up Wizard Step 1: Choose language. Step 4: Format the hard drive. Choose the hard drive and click Format button. Wait a few minutes until complete. (Hard drive might be needed purchased separately.) Step 2: Basic settings. Revise if needed. Step 5: Click Finish. -
Page 8: Chapter 2. Live View Screen
Chapter 2. Live View Screen Live View is where you can watch live feeds from the cameras. It displays one or all the channels available to you. This is useful if you have someone monitoring the channels in real time or you need to check on a specific location. -
Page 9: Menu Bar Icons
ICON Description Menu Bar Icon The blue icon indicates that this camera is currently recording as scheduled. The Menu Bar at the bottom of the screen is a handy place to change the The green icon indicates that this camera is currently viewing format of the Live View screen. - Page 10 Shortcut to go to PTZ. Control the PTZ camera on this panel.
-
Page 11: Chapter 3. Main Menu
Chapter 3. Main Menu From the Main Menu, you can access the major functions of the DVR including channel settings, recording settings, playback of recordings, network settings, motion detection settings, hard drive settings, configuration for the system, and maintenance. -
Page 12: Channel Menu
Main Menu To go to the Main Menu, click the icon as below. Channel Menu The Channel Menu is where you setup how to display the video from the cameras. (This DVR supports PTZ cameras.) 2. IMAGE Adjust 1. LIVE View In Image Adjust page, you can configure settings for video From the Live View page, you may set the channel’s Name and basic Display information on this page. -
Page 13: Privacy Mask
Main Menu NEON/STAR/VIDO/DSCP/VISCA/SAMSUNG/RM110/HY) according to the PTZ 3. Privacy Mask camera’s manual. Then click Apply. Use Privacy Mask if cameras are mounted at home or in an office that requires Don’t forget to check the Enable box. If you want to copy these settings to other privacy. -
Page 14: Video And Audio
Main Menu 2. Schedule 1. Video and Audio In the Schedule page, the DVR allows you to choose the time range to record the video. In the Video and Audio page, for each channel, there are three Quality levels (High, Medium, Low). This give you some options to choose a suitable recording DVR is set by default to record around the clock. -
Page 15: Advance
3. Advance In the Advanced page, the Recycle Recording function is enabled by default. Recycled recording means the newest video continuously replaces the oldest video. If you disable (uncheck) this function, the DVR will stop recording when the hard drive is full. 1. - Page 16 Or you may specify the Start Time here. ③ Here’s the playback interface. ② Click play button or double click the blue area. B. By Event ① Click By Event and Search, choose the day, channels and the type of record you need to watch.
-
Page 17: Image
Main Menu 2. Image Recording Mode Description The DVR only records when it detects something ① Click Search button and then input the Start Time and End Time. Choose the Motion moving in front of a camera. channel and image type you need. Click OK. The DVR only records when you click record Manual button on the menu bar or... -
Page 18: Backup
* Playback Interface Here’s the description of the icon on the playback interface. Icon Description Main Menu Pause Pause the displaying recording files. Stop Stop the displaying recording files. 3. Backup Playback Playback the files in frame after paused. From the Backup page, you can back up your recordings to an external source (USB). -
Page 19: Network Menu
1. Network Files type Chose the type of recording files. Pre/next event Chose the previous or next event files. In the Network page, you can set DHCP and Static IP. These two are the most commonly used network types. Choose DHCP (by default) if you’re new to Digital zoom Zoom partly in the selected channel. -
Page 20: Motion Menu
Main Menu Motion Menu In the Motion Menu, you may set the motion detection features for each channel. This will save a lot of hard drive space and save you time reviewing playbacks. NOTE: Motion recording is enabled by default. 1. -
Page 21: Alarm Out
Main Menu Main Menu HDD Menu On the HDD page, you may check the hard drive’s information and manually format the hard drive. CAUTION: All data will erase during formatting. 1. Alarm Out If you have installed an alarm device, please enable the Alarm Output. Then the alarm will work when video loss, if the To Alarm Out is active on Video Loss System Menu Menu. -
Page 22: System
Main Menu User Type Authorization 1. System Live, Channel select, Snapshot, Playback, Manual Record, Common On the Settings page, basic system settings can be changed. Audio, PTZ. You may setup the Device Name, Video Formats (NTSC for United States, Pal Live, Channel select, Snapshot, Playback, Manual Record, Advanced for European Unions), display Resolution (800*600, 1280*720, 1920*1080) on... -
Page 23: Time
Main Menu Time On the Time page, you can setup basic information regarding Time such as Timezone and Time/Date Format, etc. Enable Daylight Saving time (DST). Set DST Beginning and ending time by choosing month, week etc. Then click OK. -
Page 24: Maintain Menu
Main Menu to factory settings only in cases like when you forget your user name or Maintain Menu password. In the Maintenance Menu, you can view the DVR information, set up the maintenance cycle, upgrade the software, check log files, and import/export files by USB drive. -
Page 25: Upgrade
Main Menu 5. Information 3. Upgrade Here you may check some details about the DVR and Network. You will be notified if upgraded firmware is ready for your DVR. Download the firmware to the USB flash drive and click the button Upgrade from USB Flash Drive to upgrade the firmware. -
Page 26: Chapter 4. View Dvr Remotely On Your Phone
Chapter 4. View DVR Remotely on Your Phone You can view your DVR remotely from your phone if you want to check up on what is happening or receive a notification. -
Page 27: Preparation
View DVR Remotely on Your Phone 1. Preparation Please ensure that network cable is firmly connected, then check whether Step 1: Download CHERE from App Store or Google Play. Cloud is connected. 2. View Remotely via Chere Step 1. Find the QR code. (Menu-> Network -> QR code) Step 2. - Page 28 View DVR Remotely on Your Phone Step 2: Scan QR code Default Username: admin Default Password :00000000 Open CHere on your phone/tablet, choose Scan QR code. Then scan the QR Code on the DVR monitor. Click Login. * You may change the output resolution by clicking three buttons as below. Higher Resolution, lower loading speed.
-
Page 29: Chapter 5. View Dvr Remotely On Your Computer
Chapter 5. View DVR Remotely on Your Computer You can view the DVR remotely from your computer. You may want to do this for DVRs placed in remote locations from where you are. For example, you may want to monitor your cottage from home or work and likewise, monitor your business from home. - Page 30 View DVR Remotely on Your Computer (Web Browser) 1. Preparation Download Maxthon from here: http://www.maxthon.com Step 1. Make sure the network connection is good. Step 3. Restart the browser. Step 2. Download the plugin. After the plugin is successfully installed, close and restart the browser. Then open the page http://www.easyconfigure.com again.
- Page 31 View DVR Remotely on Your Computer View DVR Remotely on Your Computer Step 3: Fill in other information. Default Username: admin. Default password: 00000000. (Eight Zeros) Click Login.
- Page 32 Step 1. Right Click Device List, then click to choose Add Device. Step 2. Download and install CMS software via the link here: http://www.tigersecu.com/CMS/client.zip Step 3. Run CMS. After plugin is successfully installed, run the software, you're supposed to see the page below.
- Page 33 View DVR Remotely on Your Computer (CMS) 3. Icon Icon Icon Description Icon Description Live View (Screen) Lock Remote Playback Local Playback Preset Point Setting E-Map Cruise Config Video (Adjustment) 4. Live View 2. How to login ① Choose P2P as Login Type. Then input the UID. Click , then you will see the preview page.
- Page 34 View DVR Remotely on Your Computer (CMS) 5. Remote Playback ,, then you will see the playback page. Click ① Choose the DVR and the channel you want to playback ② Search and choose the date. Green means there’s recording on that day. Chapter 6: Q&A ③...
-
Page 35: Chapter 6. Q&A
Settings to set the DVR to factory default settings. The default username is admin and the password is 00000000 (eight zeros). 4. I purchased three sets of TIGERSECU DVR, could I use the same app on my phone to keep track of all my DVRs? 2. - Page 36 Chapter 6: Q&A 6. Can I buy longer cables? So that I can mount the cameras further from hours) recording schedule on every channel and day-->Apply. the DVR. Yes, this DVR kit comes with 60ft cables. You may also purchase longer cables to replace them if needed.
- Page 37 Chapter 6: Q&A Step 3: Go back to Record Menu-->Advanced-->Set the Pre-Record Time and Post-Record Time of the Channels that been enabled motion in step 2-->Apply. Then the DVR will record only when motion is detected.
