Tigersecu Super HD 1080P NVR Series Quick Start Manual

Super HD 1080P NVR Series
Quick Start Guide (V2.4)
Package Contents
Super HD 1080P Security NVR
Wireless Mouse
Power Supply
Set Up Your NVR
See the steps below (expanded instructions on the right) to
complete the initial setup of the NVR:
STEP 1:
STEP 2:
Connect monitor
Connect cameras
STEP 3: STEP 4:
Connect router Connect mouse
(Optional) Install/replace hard drive
Skip this step if you have an NVR with pre-installed hard
disk drive (HDD). Install a surveillance HDD (WD Purple
hard drive is recommended) to record video footage. Or
upgrade your HDD to add extra recording space.
Ensure NVR is powered off and power adapter is
disconnected before installing/replacing HDD.
STEP 1: Connect monitor
Connect the NVR to a TV or desktop computer monitor
using an HDMI or VGA cable (not included). Multiple
Wi-Fi IP Camera
monitors may be connected to the NVR at the same time.
Ethernet Cable
Monitor
STEP 2: Connect cameras
Connect the antenna to the IP camera first.
Test your cameras prior to selecting a permanent mounting
location by powering the cameras and the system up.
STEP 5:
Connect power
TIGERSECU Wi-Fi NVR Systems come with IP cameras pre-
paired to the NVR, so manual pairing is NOT required.
STEP 6:
Simply connect the cameras to the power adapters and
Startup Wizard
you will see the video feeds on the NVR monitor.
Front and back panels shown are for illustration only.
Your NVR's back panel may appear different, with the same ports in different locations.
• Format HDD during STEP 6 Startup
Wizard.
• Or go to the NVR Main Menu, HDD
Menu.
++
NVR
```
Wi-Fi IP Camera
STEP 3: Connect router
Connect the NVR to your router using an Ethernet cable.
Router
High speed internet connection and a router (not
included) are required to enable remote viewing.
Internet is not required for local viewing.
STEP 4: Connect wireless mouse
Connect the included mouse to a USB port on the NVR.
Remove the USB receiver from the mouse battery
compartment and insert it to a USB port on the back panel
of the NVR.
STEP 5: Connect power
Use the included power adapter to connect the NVR to an
electrical outlet.
The Power Supply included is designed ONLY for
use with the TIGERSECU NVR and cameras.
STEP 6: Startup Wizard
The TIGERSECU Startup Wizard will begin when you first
power up your NVR. The Startup Wizard will help you
configure core NVR settings.
Record your password below and store in a secure
place:
NVR
