Montage und Inbetriebsetzung
Montage et mise en service
Montagio e messa in funzione
Montaje y puesta en servicio

Installation and initial operation

EU/AUS
USA/CAN
Montage des Arretiergewichtes
Montage du contre-poids
Motagio del contappeso
Montaje del contrapeso

Installation of limits stop weight

ø35mm /
1 3/8"
S36
Radius min.
= 50mm / 2"
Z.503.315
c
c =
600 mm, 23 5/8"
d =
300 mm, 11 13/ 16"
d
ø36mm /
1 7/16"
Verlängerungsmutter L= 40mm
Ecrou allongé L= 40mm
Dado prolungato L= 40mm
Tuerca de prolongación L= 40mm
Extension nut L= 40mm / 1 1/2"
3
