Computer Desk
Model 408995
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
For all your
newfangled gadgetry.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-28
Français pg 29-32
Español pg 33-36
Lot # 531618
07/30/19
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

loading
Need help?

Need help?

Do you have a question about the 408995 and is the answer not in the manual?

Questions and answers

Related Manuals for Sauder 408995

Summary of Contents for Sauder 408995

  • Page 1 Model 408995 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987. English pg 1-28 Français pg 29-32...
  • Page 2 Table of Contents Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 6-28 Hammer Not actual size Français 29-32 Español 33-36 Safety 37-38 Warranty Page 2 408995 www.sauder.com/services...
  • Page 3 MODESTY PANEL (1) DRAWER FRONT (1) TOP (1) SHELF (1) END MOLDING (1) RIGHT DRAWER SIDE (1) BACK (1) BOTTOM MOLDING (1) LEFT DRAWER SIDE (1) DOOR (1) FRONT MOLDING (1) DRAWER BACK (1) BASE (1) D707 www.sauder.com/services 408995 Page 3...
  • Page 4 FILE GLIDE - 2 HIDDEN CAM - 21 5G ANGLE BRACKET - 4 33G RAIL BRACKET - 2 CAM DOWEL - 21 22H HINGE SPACER - 2 KEYBOARD HINGE - 2 HINGE - 2 KNOB - 3 Page 4 408995 www.sauder.com/services...

  • Page 5: Table Of Contents

    18S BROWN 1" FLAT HEAD SCREW - 4 30S BLACK 1-9/16" FLAT HEAD SCREW - 4 SILVER 5/8" FLAT HEAD SCREW - 8 BLACK 7/8" MACHINE SCREW - 3 SILVER 9/16" LARGE HEAD SCREW - 2 www.sauder.com/services 408995 Page 5...
  • Page 6 PANEL (F), and SHELF (G). Then, insert a CAM DOWEL (2F) into each HIDDEN CAM. Do not tighten the HIDDEN CAMS in this step. Arrow Arrow (21 used) Arrow Arrow Insert the metal end of the CAM DOWEL into the HIDDEN CAM. Page 6 408995 www.sauder.com/services...
  • Page 7 Lefty loosey. NOTE: The CABINET RAILS are marked "CABINET å RIGHT" and "CABINET LEFT" for easy identifi cation. GOLD 5/16" FLAT HEAD SCREW Finished edge (4 used in this step) Roller end Finished edge Roller end www.sauder.com/services 408995 Page 7...
  • Page 8 UPRIGHT (C). Use four GOLD 5/16" FLAT HEAD SCREWS (3S). BLACK 9/16" LARGE HEAD SCREW (4 used for the RAIL BRACKETS) GOLD 5/16" FLAT HEAD SCREW (4 used for the RAILS) Roller end Notched edge Roller end Finished edge Page 8 408995 www.sauder.com/services...
  • Page 9 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees www.sauder.com/services 408995 Page 9...
  • Page 10 Fasten the BOTTOM (E) to the LEFT END (B). Tighten the å Minimum HIDDEN CAM. 190 degrees Long edge with CAM DOWELS S u r f a c H I D D E N i t h Page 10 408995 www.sauder.com/services...
  • Page 11 SHELF (G). Tighten three HIDDEN CAMS. Maximum Arrow 210 degrees NOTE: Be sure the METAL PIN in the BOTTOM (E) å inserts into the hole in the UPRIGHT (C). Minimum 190 degrees Edge with CAM DOWELS Finished edge www.sauder.com/services 408995 Page 11...
  • Page 12 Step 7 Fasten the MOLDINGS (S and T) to the BOTTOM (E) and å SHELF (G). Tighten four HIDDEN CAMS. Maximum Arrow 210 degrees Minimum 190 degrees These edges should be almost even. Page 12 408995 www.sauder.com/services...
  • Page 13 LEFT END and UPRIGHT. Fasten the BASE (J) to the LEFT END (B) and UPRIGHT (C). Use å four BLACK 9/16" LARGE HEAD SCREWS (1S). BLACK 9/16" LARGE HEAD SCREW (8 used in this step) (4 used) www.sauder.com/services 408995 Page 13...
  • Page 14 Step 9 Fasten the LEFT END (B) and UPRIGHT (C) to the TOP (D). å Tighten four HIDDEN CAMS. Maximum Arrow 210 degrees Minimum 190 degrees Finished edge Unfi nished edge Page 14 408995 www.sauder.com/services...
  • Page 15 å two BLACK 1-7/8" FLAT HEAD SCREWS (2S). Minimum 190 degrees D E N H I D i t h f a c S u r BLACK 1-7/8" FLAT HEAD SCREW (2 used in this step) www.sauder.com/services 408995 Page 15...
  • Page 16 Step 11 Fasten the RIGHT END (A) to the TOP (D) and MODESTY å PANEL (F). Tighten fi ve HIDDEN CAMS. Maximum Arrow 210 degrees Minimum 190 degrees Notched edge Page 16 408995 www.sauder.com/services...
  • Page 17 RIGHT END (A). Don't worry. It isn't Rome. This can be built *U.S. Patent No. 5,499,886 å in a day. The groove is closer to this edge. Slide the END MOLDING (R) onto the notched edge. Notched edge www.sauder.com/services 408995 Page 17...

  • Page 18: Nail

    BACK fastened. The unit may collapse. Push on opposite corners of your unit if needed to make it "square". Fasten the BACK (H) to your unit using the NAILS (1N). å NAIL (14 used in this step) Page 18 408995 www.sauder.com/services...

  • Page 19: Silver 5/8" Flat Head Screw

    Step 14 Fasten two HINGES (13H) and HINGE SPACERS (22H) to å the DOOR (I). Use four SILVER 5/8" FLAT HEAD SCREWS (23S). SILVER 5/8" FLAT HEAD SCREW (4 used in this step) www.sauder.com/services 408995 Page 19...

  • Page 20: Black 7/8" Machine Screw

    Fasten a KNOB (25K) to the DOOR (I). Use a BLACK 7/8" å Mounting MACHINE SCREW (37S). screw See the next step for DOOR adjustments. å Hinge BLACK 7/8" MACHINE SCREW (1 used for the KNOB) Page 20 408995 www.sauder.com/services...
  • Page 21 To adjust the DOORS in or out (depth), loosen the mounting å screw one turn and move the DOORS in or out, as needed. Tighten the mounting screw after making adjustments. Mounting screw (depth) Adjusting screw (horizontal) (vertical adjustment) www.sauder.com/services 408995 Page 21...
  • Page 22 Fasten the KEYBOARD HINGES (12H) to the KEYBOARD FRONT å (K). Use four SILVER 5/8" FLAT HEAD SCREWS (23S). SILVER 5/8" FLAT HEAD SCREW (4 used in this step) SILVER 9/16" LARGE HEAD SCREW (2 used in this step) Page 22 408995 www.sauder.com/services...

  • Page 23: Brown 1" Flat Head Screw

    Fasten a KNOB (25K) to the KEYBOARD FRONT (K). Use a å BLACK 7/8" MACHINE SCREW (37S). Roller end BLACK 7/8" MACHINE SCREW (1 used for the KNOB) Roller end BROWN 1" FLAT HEAD SCREW (4 used for the SLIDES) www.sauder.com/services 408995 Page 23...

  • Page 24: Black 1-9/16" Flat Head Screw

    Fasten the DRAWER BACK (D78) to the DRAWER SIDES (D28 and D29). Use four BLACK 1-9/16" FLAT HEAD SCREWS (30S). å NOTE: Be sure the DRAWER BOTTOM (D707) inserts into the groove of the DRAWER BACK (D78). å Page 24 408995 www.sauder.com/services...
  • Page 25 (1 used for the KNOB) Roller end Screw head - turn CAM to line up holes in the SLIDES with holes in DRAWER SIDES Roller end GOLD 5/16" FLAT HEAD SCREW (4 used for the SLIDES) www.sauder.com/services 408995 Page 25...
  • Page 26 Step 21 Push the FILE GLIDES (15B) onto the å DRAWER SIDES (D28 and D29). Almost time to celebrate! With a nap. Page 26 408995 www.sauder.com/services...
  • Page 27 Lift the front of the drawer up and slide it into the unit. Repeat this step to insert the KEYBOARD SHELF (L). 70 lbs. 30 lbs. 15 lbs. 30 lbs. www.sauder.com/services 408995 Page 27...
  • Page 28 #3. The higher the screw in the oblong hole, the higher your drawer front will be. The lower the screw, the lower the drawer front. Page 28 408995 www.sauder.com/services...
  • Page 29 Modèle 408995 Bureau d'ordinateur Utilisez les instructions d’ a ssemblage en français avec les NOUS SOMMES LA POUR VOUS AIDER! schémas étape par étape du manuel d’instruction en anglais. Nous faisons de notre mieux pour nous assurer que votre meuble Chaque étape en français correspond à...
  • Page 30 DESSOUS (E) dans le trou dans l'EXTRÉMITÉ GAUCHE (B). ÉTAPE 12 Fixer le DESSOUS (E) à l'EXTRÉMITÉ GAUCHE (B). Serrer Enfi ler la MOULURE D'EXTRÉMITÉ* (R) sur le chant cranté de l’EXCENTRIQUE ESCAMOTABLE. l'EXTRÉMITÉ DROITE (A). * Brevet État Unis n° 5,499,886 Page 30 408995 www.sauder.com/services...
  • Page 31 Serrer les vis après avoir ajusté. Pour ajuster les PORTES vers l'intérieur où vers l'extérieur (profondeur), desserrer la vis de montage un tour et déplacer les PORTES vers l'intérieur ou vers l'extérieur. Serrer la vis de montage après avoir ajusté. www.sauder.com/services 408995 Page 31...
  • Page 32 Répéter cette étape pour insérer la TABLETTE DE CLAVIER (L). REMARQUE : Prière de lire les informations importantes sur la sécurité fi gurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer avec un tissu humide. Essuyer. Page 32 408995 www.sauder.com/services...
  • Page 33 EXTREMO IZQUIERDO ............1 35AZ CAJÓN IZQUIERDO .............. 1 necesita ponerse en PARAL ....................1 CORRIMIENTO DE ARCHIVERO........ 2 contacto con Sauder en PANEL SUPERIOR ..............1 EXCÉNTRICO ESCONDIDO ........21 cuanto a esta unidad, D28 LADO DERECHO DE CAJÓN ........1 PASADOR DE EXCÉNTRICO ........21...
  • Page 34 Inserte la ESPIGA DE METAL (1R) sujetada a un extremo del *Patente EE. 23S. No. 5,499,886 FONDO (E) dentro del agujero del EXTREMO IZQUIERDO (B). Fije el FONDO (E) al EXTREMO IZQUIERDO (B). Apriete el EXCÉNTRICO ESCONDIDO. Page 34 408995 www.sauder.com/services...
  • Page 35 TORNILLO NEGRO PARA METAL de 22 mm (37S). (profundidad), afl oje el tornillo de montaje una vuelta y mueva las PUERTAS hacia el interior o hacia el exterior según sea necesario. Apriete el tornillo de montaje después de hacer los ajustes. www.sauder.com/services 408995 Page 35...
  • Page 36 NOTA: Por favor, lea las páginas de atrás del folleto de paso para insertar el ESTANTE DE TECLADO (L). instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpiar con un trapo húmedo. Seque con un paño. Page 36 408995 www.sauder.com/services...
  • Page 37 à Les téléviseurs peuvent être particulièrement un téléviseur. cet eff et. lourds. De plus, le poids et l’emplacement du tube image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’ a vant. www.sauder.com/services 408995 Page 37...
  • Page 38 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y propensa a volcarse hacia adelante. Page 38 408995 www.sauder.com/services...
  • Page 39 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
