Sauder Office Port Series Instruction Booklet

Sauder Office Port Series Instruction Booklet

Credenza
Hide thumbs Also See for Office Port Series:

Advertisement

Quick Links

Download this manual
sauder.com
Credenza
Offi ce Port Collection | Model 408291
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
For all your
newfangled gadgetry.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-31
Français pg 32-35
Español pg 36-40
Lot # 363436
07/11/14
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

loading
Need help?

Need help?

Do you have a question about the Office Port Series and is the answer not in the manual?

Questions and answers

Related Manuals for Sauder Office Port Series

Summary of Contents for Sauder Office Port Series

  • Page 1 Offi ce Port Collection | Model 408291 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
  • Page 2 Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 6-31 Hammer Not actual size Français 32-35 Español 36-40 Skip the power trip. Safety 41-42 This time. Warranty Page 2 408291 www.sauder.com/services...
  • Page 3 BOTTOM MOLDING (1) SMALL DRAWER BACK (1) EXTENSION BLOCK (2) END MOLDING (2) LARGE DRAWER BACK (1) BASE (1) SMALL DRAWER FRONT (1) DRAWER BACK (1) LARGE BACK (1) SMALL BOTTOM MOLDING (1) D707 D707 D708 www.sauder.com/services 408291 Page 3...
  • Page 4 XX HINGE - 2 HIDDEN CAM - 4 CAM SCREW - 4 ® RAIL BRACKET - 8 FASTENER - 18 GROMMET CAP - 1 PULL - 4 GROMMET - 1 METAL BRACKET - 7 CORD CLIP - 1 Page 4 408291 www.sauder.com/services...
  • Page 5 NNN BLACK 1" PAN HEAD SCREW - 8 BLACK 9/16" LARGE HEAD SCREW - 30 OOO BROWN 1" FLAT HEAD SCREW - 4 BLACK 1/2" FLAT HEAD SCREW - 4 GOLD 5/16" FLAT HEAD SCREW - 28 NAIL - 35 www.sauder.com/services 408291 Page 5...
  • Page 6 fl oor. Scan this QR code or go to this address: http://qr.sauder.com/?ID=1564 To begin assembly, push a SAUDER TWIST-LOCK® å to watch a video on how to assemble your unit. FASTENER (TT) into the large holes in the RIGHT END (A) and LEFT END (B).
  • Page 7 BRACES (H). Turn four CAM SCREWS (8F) into the å BOTTOM MOLDINGS (Y and GG). Arrow Arrow (4 used) Hole The arrow in the HIDDEN CAM must point toward the hole in the edge of the board. www.sauder.com/services 408291 Page 7...
  • Page 8 Fasten eight RAIL BRACKETS (ZZ) to the RIGHT END (A) å and RIGHT UPRIGHT (C). Use sixteen BLACK 9/16" LARGE Remember: HEAD SCREWS (PPP). Righty tighty. Lefty loosey. BLACK 9/16" LARGE HEAD SCREW (16 used in this step) (8 used) Page 8 408291 www.sauder.com/services...
  • Page 9 Step 4 Fasten the EXTENSION BLOCKS (I) to the RIGHT END (A) å and RIGHT UPRIGHT (C). Use four SILVER 2" FLAT HEAD SCREWS (LLL). SILVER 2" FLAT HEAD SCREW (4 used in this step) www.sauder.com/services 408291 Page 9...
  • Page 10 SCREWS (RRR) through holes #1 and #4. NOTE: The CABINET RAILS are marked "CABINET å RIGHT" and "CABINET LEFT" for easy identifi cation. Roller end GOLD 5/16" FLAT HEAD SCREW (8 used in this step) Notched edge Roller end Notched edge Page 10 408291 www.sauder.com/services...
  • Page 11 END. Turn a SCREW into this hole. Push the black lever in and pull the SLIDE from the RAIL. Notched edge Open end GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Notched edge Open end www.sauder.com/services 408291 Page 11...
  • Page 12 HEAD SCREWS (RRR). NOTE: The CABINET RAILS are marked "CABINET å RIGHT" and "CABINET LEFT" for easy identifi cation. Roller end GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Notched edge Roller end Finished edge Page 12 408291 www.sauder.com/services...
  • Page 13 Step 8 Fasten the LEFT END (B) to the TOP (E). Tighten two å ® How to use the SAUDER TWIST-LOCK FASTENER TWIST-LOCK FASTENERS. ® 1. Insert the dowel end of the FASTENER into the hole of the adjoining part.
  • Page 14 MODESTY PANEL insert into the holes in the TOP (E). Do not tighten the TWIST-LOCK® FASTENERS at this time. BLACK 1-7/8" FLAT HEAD SCREW (2 used in this step) Finished edge Notch These two TWIST-LOCK® FASTENERS will be tightened in Step 15. Page 14 408291 www.sauder.com/services...
  • Page 15 - L O T E N ® E R S Edge without holes S u r f a c I S T i t h F A S - L O T E N ® E R S www.sauder.com/services 408291 Page 15...
  • Page 16 Fasten the RIGHT END (A) to the TOP (E) and BRACES (H). å Tighten four TWIST-LOCK® FASTENERS. NOTE: Be sure the METAL PINS in the BRACES insert into å the holes in the RIGHT END. Notched edge Page 16 408291 www.sauder.com/services...
  • Page 17 Slide the END MOLDINGS* (Z) onto the notched edges of å the RIGHT END (A) and RIGHT UPRIGHT (C). * U.S. Patent No. 5,499,886 å Slide the END MOLDINGS (Z) onto the notched edges. Groove These edges must be even. Groove www.sauder.com/services 408291 Page 17...
  • Page 18 Step 13 Fasten the BOTTOM MOLDINGS (Y and GG) to å the BOTTOM (F) and BRACE (H). Tighten four HIDDEN CAMS. Page 18 408291 www.sauder.com/services...
  • Page 19 Next, fasten the BASES (J and N) to the ENDS (A and B), å BLACK 9/16" LARGE HEAD SCREW UPRIGHTS (C and D), BOTTOM (F), and BRACE (H). Use seven (14 used for the METAL BRACKETS) BLACK 9/16" LARGE HEAD SCREWS (PPP). (7 used) www.sauder.com/services 408291 Page 19...
  • Page 20 BACK. Carefully cut out the holes needed. NAIL (35 used in this step) Tighten the TWIST-LOCK® FASTENERS in the MODESTY å PANEL (G) at this time. Cut-out for lifting the desk Tighten two TWIST-LOCK® FASTENERS. Cut-out for lifting the desk Page 20 408291 www.sauder.com/services...
  • Page 21 Fasten two HINGES (XX) to the DOOR (L). Use four å BLACK 1/2" FLAT HEAD SCREWS (QQQ). Don't worry. It isn't Rome. This can be built in a day. BLACK 1/2" FLAT HEAD SCREW (4 used in this step) www.sauder.com/services 408291 Page 21...
  • Page 22 UPRIGHT (D). Hinge Fasten a PULL (CCC) to the DOOR (L). Use two BLACK 1" å PAN HEAD SCREWS (NNN). See the next step for adjustments. å BLACK 1" PAN HEAD SCREW (2 used in this step) Page 22 408291 www.sauder.com/services...
  • Page 23 To adjust the DOORS in or out (depth), loosen the mounting å screw one turn and move the DOORS in or out, as needed. Tighten the mounting screw after making adjustments. Mounting screw (depth) Adjusting screw (horizontal) (vertical adjustment) www.sauder.com/services 408291 Page 23...
  • Page 24 Turn the CORD CLIP (BBB) into the KEYBOARD SHELF (P). å NOTE: The CORD CLIP is used to hold your keyboard cord å against the KEYBOARD SHELF. BROWN 1" FLAT HEAD SCREW (4 used in this step) Roller end Roller end Finished edge Page 24 408291 www.sauder.com/services...
  • Page 25 NOTE: Be sure the LARGE DRAWER BOTTOM (D708) inserts into the groove of the LARGE DRAWER BACK (D78). å Repeat this step for the smaller drawers using parts (CC, D18, D19, D74, and D707) and parts (V, D10, D11, D86 and D707). å www.sauder.com/services 408291 Page 25...
  • Page 26 "DRAWER LEFT" for easy identifi cation. Screw head - turn CAM to line up holes in Open end the SLIDES with holes in DRAWER SIDES Open end GOLD 5/16" FLAT HEAD SCREW (12 used in this step) Page 26 408291 www.sauder.com/services...
  • Page 27 Slide another FILE GLIDE (6B) onto the other end of the FILE å RODS (RR), then press this FILE GLIDE over the LEFT DRAWER SIDE (D88). Insert the FILE RODS into the holes of your choice in the FILE GLIDES, depending on your fi le sizes. www.sauder.com/services 408291 Page 27...
  • Page 28 Fasten a PULL (CCC) to the LARGE DRAWER FRONT (T). å Use two BLACK 1" PAN HEAD SCREWS (NNN). Repeat fastening the PULLS to the other drawers. å BLACK 1" PAN HEAD SCREW (6 used in this step) Page 28 408291 www.sauder.com/services...
  • Page 29 LEFT END (B) and LEFT help a friend, don't UPRIGHT (D). Set the ADJUSTABLE SHELF (M) onto the leave without a bite. METAL PINS. Insert the GROMMET (EEE) and GROMMET CAP (FFF) å into the TOP (E). (4 used) www.sauder.com/services 408291 Page 29...
  • Page 30 Lift the front of the drawer up and slide it into the unit. Repeat this step to insert the KEYBOARD SHELF (P). 100 lbs. lbs. 25 lbs. 50 lbs. 10 lbs. 15 lbs. 35 lbs. Page 30 408291 www.sauder.com/services...
  • Page 31 #4. The higher the screw in the oblong hole, the higher your drawer front will be. The lower the screw, the lower the drawer front. www.sauder.com/services 408291 Page 31...
  • Page 32 EXTRÉMITÉ DROITE ..............1 (ENSEMBLE DE GLISSIÈRE ILLUSTRÉ À PART) pour future référence. GLISSIÈRE D'EXTENSION ............2 EXTRÉMITÉ GAUCHE ..............1 Pour contacter Sauder COULISSE D'EXTENSION ............2 MONTANT DROIT ................. 1 en ce qui concerne cet GLISSIÈRE DROITE D'ÉLÉMENT ........1 MONTANT GAUCHE ..............
  • Page 33 éviter d’endommager l’élément ou le sol. l’EXTRÉMITÉ. Faire tourner une VIS dans ce trou. Pour commencer l’ a ssemblage, enfoncer une FIXATION TWIST-LOCK® SAUDER (TT) dans les gros trous de l’EXTRÉMITÉ DROITE (A) et ÉTAPE 7 l’EXTRÉMITÉ GAUCHE (B). Répéter cette étape pour les MONTANTS (C et D),le DESSOUS (F), le VOILE DE FOND (G)et Fixer les GLISSIÈRES D’ÉLÉMENT (JJ et KK) aux MONTANTS (C et D).
  • Page 34 REMARQUE : Le CLIP DE CORDON est utilisé pour maintenir le ÉTAPE 16 cordon de clavier contre la TABLETTE DE CLAVIER. Fixer deux CHARNIÈRES (XX) à la PORTE (L). Utiliser quatre VIS NOIRES TÊTE PLATE 13 mm (QQQ). Page 34 408291 www.sauder.com/services...
  • Page 35 Enfoncer les MANCHONS EN CAOUTCHOUC (JJJ) sur les GOUPILLES EN MÉTAL (III) restantes. Insérer les GOUPILLES EN MÉTAL dans les trous choisis de l’EXTRÉMITÉ GAUCHE (B) et du MONTANT GAUCHE (D). Poser la TABLETTE RÉGLABLE (M) sur les GOUPILLES EN MÉTAL. www.sauder.com/services 408291 Page 35...
  • Page 36 RIEL DERECHO DE GABINETE ............1 EXTREMO IZQUIERDO ..................1 pour future référence. RIEL IZQUIERDO DE GABINETE ............1 PARAL DERECHO ....................1 Pour contacter Sauder CORREDERA DERECHA DE CAJÓN ..........1 PARAL IZQUIERDO .....................1 CORREDERA IZQUIERDA DE CAJÓN ......... 1 en ce qui concerne cet LADO DERECHO DE CAJÓN ..............1...
  • Page 37 Para comenzar el ensamblaje, empuje un SUJETADOR EXTENSIÓN en el EXTREMO DERECHO (A) y el PARAL TWIST-LOCK® SAUDER (TT) dentro de los agujeros grandes del DERECHO (C). Utilice cuatro TORNILLOS DORADOS DE CABEZA EXTREMO DERECHO (A) y del EXTREMO IZQUIERDO (B). Repita PERDIDA de 8 mm (RRR).
  • Page 38 NOTA: Asegúrese de insertar las ESPIGAS DE METAL de las RIOSTRAS dentro de los agujeros del EXTREMO DERECHO. PASO 12 Deslice las MOLDURAS DE EXTREMO* (Z) sobre los bordes con muesca del EXTREMO DERECHO (A) y del PARAL DERECHO (C). * Patente EE.UU. No. 5,499,886 Page 38 408291 www.sauder.com/services...
  • Page 39 PUERTA hacia CORREDERAS CORTAS DE CAJÓN (PP y QQ). el interior o hacia el exterior según sea necesario. Apriete el tornillo de montaje después de hacer losajustes. www.sauder.com/services 408291 Page 39...
  • Page 40 NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpie con su pulimento para muebles preferido o un paño húmedo. Seque con un paño. Page 40 408291 www.sauder.com/services...
  • Page 41 à Les téléviseurs peuvent être particulièrement un téléviseur. cet eff et. lourds. De plus, le poids et l’emplacement du tube image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’ a vant. www.sauder.com/services 408291 Page 41...
  • Page 42 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y propensa a volcarse hacia adelante. Page 42 408291 www.sauder.com/services...
  • Page 43 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 44 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
