Better Bathrooms BeBa 26925 Installation And Maintenance

Basin Wall Hung and Pedestal Mounted
Installation and Maintenance
PLEASE READ THIS INSTRUCTION GUIDE FULLY PRIOR TO COMMENCING ANY PART OF THE INSTALLATION
IMPORTANT ! - This is a suggested method of installation to a solid wall, if the wall type is different you will require a different fixing type
Before commencing any installation check for wires and pipes will not be damaged during drilling
1
Offer the basin to the wall, checking the
basin is level.
Drill the wall in the required location.
If drilling into tile, it is recommended
to tape the
wall in the
area to be
drilled to
prevent
slipping
4
Place the washers over the fixing bar
as shown in the parts drawing, above
(Fixings not supplied)
Please refer to page 2 if fitting with a pedestal basin
2
Insert the wall plug into the drilled hole
tap the plug to the finished wall surface
5
Connect the nut and tighten into position
using a spanner
3
Insert the fixing bar and tighten into the wall
using a spanner or grips
6
Check basin is stable, seal along the back edge
Leave to dry for at least 24 hours
