CALIBRATION MODE

E
Before calibration tune the guitar to standard
pitch! (red tuning bank
1. When the TronicalTune PLUS is switched off,
press the ON button.
2. Strum the open strings once.
3. When all LEDs are GREEN
are tuned. The TronicalTune PLUS turns off
automatically
(if any LEDs are not green, pluck those
.
strings individually)
NOTE: You must calibrate the TronicalTune PLUS:
- after installing for the first time
- if you change your strings' gauge, type, or brand
- if you perform a master system reset or firmware update
- if you are facing issues like erratic ROBOHEAD
movements, strings not tuning properly, etc.
E LED).
, all six strings
CALIBRATION:
1. Press ON three times. Press the
button to select CYAN A
2. Press ENTER twice. The string LEDs blink
3. Strum all strings once. All lights should shine
GREEN briefly then turn off. If the LEDs continue to
flash RED , mute all strings and then strum again.
4. Once the strings have turned off from being
GREEN , or show a combination of
RED LEDs, mute all strings. Then all string LEDs
blink RED .
5. Repeat steps 3 and 4 until the LEDs light
SEQUENTIALLY and one string LED is lit.
CATEGORY FUNCTIONS
E Calibration Mode
A Accuracy Level
D RoboHead Delay
G RoboHead Speed
B Interference Level
LEFT/RIGHT
.
RED
BLUE and
.
