Getting started
String up your guitar (treble strings)
1
2
Wind the string around the shaft once above the
recess.
NOTE: To ensure that the 1st (e) and 2nd (B) string are securely locked, we recommend to perform
TWO WINDINGS around the string shaft before tightening the Lock Nut.
16
Take off the LockNut and make sure the recess is
turned horizontal to the neck. (90 degree angle).
You can turn the key manually or use the
string-up mode.
Wind the string around the string shaft under the
recess and bring it up through the recess.
3
Hold the string tight and apply the Lock Nut.
