INSTALLATION &
OPERATING MANUAL
WELLEA SPLIT TANK R32
Indoor & Outdoor
AW-YHPS04-H91
AW-YHPS06-H91
AW-YHPS08-H91
AW-YHPS10-H91
20AW-INSTALLATION & OPERATING MANUAL WELLEA SPLIT TANK R32-EN-20200421
AW-WHPST0410-N91

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WELLEA SPLIT AW-WHPST0410-N91 and is the answer not in the manual?

Questions and answers

Related Manuals for Airwell WELLEA SPLIT AW-WHPST0410-N91

Summary of Contents for Airwell WELLEA SPLIT AW-WHPST0410-N91

  • Page 1 INSTALLATION & OPERATING MANUAL WELLEA SPLIT TANK R32 Indoor & Outdoor AW-WHPST0410-N91 AW-YHPS04-H91 AW-YHPS06-H91 AW-YHPS08-H91 AW-YHPS10-H91 20AW-INSTALLATION & OPERATING MANUAL WELLEA SPLIT TANK R32-EN-20200421...
  • Page 2 Dear Customer, We congratulate you on choosing these product Airwell has been working for years to offer systems able to assure the maximum comfort for a long time with highly-reliable, efficient, high-quality and safe solutions. The target of the company is to offer advanced systems, that assure the best comfort and reduce energy consumption as well as the installation and maintenance costs for the entire life- cycle of the system.

  • Page 3: Table Of Contents

    Safety considerations Information on refrigerant gas General Reception Installation requirements Water connections Refrigerating connections Electrical connections Start - up Control Maintenace Disposal Accessories Technical data Energy data sheets and labelling Pay particular attention to: INSTALLER use USER use...
  • Page 4 Consider sound emissions Functional clearances/access Respect the functional clearances for maintenance For details see the manual sections Internal unit External unit Avoid installations next to bedrooms Place so that it doesn't disturb Install in a local or compartment where the temperature can't drop below 0 °...
  • Page 5 Snowdrifts Condensate discharge Strong winds To avoid the water freezing downstream of the Provide windbreaks or similar drain, lay the tube below the frost line (A). Provide a protection Water features Domestic Hot Water Requirements The requirements vary by the number of people living in the building Between 8°f and 15°f Estimated average daily per capita consumption of hot water...

  • Page 6: Safety Considerations

    1 SAFETY CONSIDERATIONS The precautions in this manual are divided as Meaning of the symbols DANGER, WARNING, indicated on the side. CAUTION and NOTE They are important, so make sure you follow them DANGER closely. Please read these instructions carefully before ...
  • Page 7 1 SAFETY CONSIDERATIONS  Do not touch any switch with wet hands. Touching a switch with wet hands may lead to electric shock. WARNING  The power supply of the WELLEA series complies with IEC / EN 61000-3-11 and must be connected to a suitable power supply network, in able to support a maximum system impedance of Zmax =...
  • Page 8 1 SAFETY CONSIDERATIONS structure may lead to the unit falling causing possible lesions.  Perform installation operations considering the possibility that strong winds, hurricanes or earthquakes may occur. Incorrect installation operations may lead to accidents caused by falling equipment. Make sure electrical operations...
  • Page 9 1 SAFETY CONSIDERATIONS  Never touch the leaking refrigerant directly, as it may lead to serious frostbite injuries. Do not touch the refrigerant pipes during and right after functioning, as they may be hot or cold depending on the conditions of the refrigerant flowing through the pipes, compressor and other parts of the cooling circuit.
  • Page 10 1 SAFETY CONSIDERATIONS • Lightning rods or phone earth cables: the electrical threshold can increase abnormally if hit by lightning.  Install the power supply cable at least one metre from radios prevent interferences or disturbances. Depending on the type of radio wave, one metre may not be enough to avoid disturbances.
  • Page 11 1 SAFETY CONSIDERATIONS  Before the hydraulic connection and electrical wiring operations, verify that the installation area is safe and without hidden dangers such as water, electricity and gas conduits.  Do not touch the fins of the heat exchanger as they may cause injury.

  • Page 12: Information On Refrigerant Gas

    2 INFORMATION ON REFRIGERANT GAS This product contains fluorinated greenhouse gases covered by the Kyoto protocol. Do not discharge gas into air. Refrigerant type: R32 Characteristics of R32 refrigerant: minimum environmental impact thanks to the low Global • Warming Potential GWP low flammability, class A2L according to ISO 817 •...

  • Page 13: General

    3 GENERAL UNIT INDENTIFICATION Serial number label The serial number label is positioned on the unit and allows to indentify all the unit features. Warning  It has not to be removed for any reason. It reports the regulations indications such as: machine type, exmple •...

  • Page 14: Reception

    4 RECEPTION Before accepting the delivery you have to check: that the unit hasn’t been damaged during transport. • Check that the materials delivered correspond with that indicated on • the transport document comparing the data with the identification label ‘A’ positioned on the packaging. In case of damage or anomaly: Write down on the transport document the damage you found and •...
  • Page 15 4 RECEPTION External unit 1 Fork input side 2 Input side for lifting by crane 3 Do not lean it more than 45°, and do not lay it sidelong 4 Do not lean it more than 45°, and do not lay it sidelong DANGER ...
  • Page 16 4 RECEPTION 2- Remove wooden platforms 1 - Components supplied (External unit) • Remove the screws Non-return valve / Water filter / Manual / Welding • fittings / Shut-off valve water / Copper reduction 10- Remove the screws Move the •...
  • Page 17 GENERAL Schema collegamenti Acqueduct Ø 3/4”M Booster 1 (option) Supply line Booster 2 (option) Inertial storage (option) Ø 1”M Drainage tray Provided by the customer System Refrigerant lines Provided by the customer System outlet Ø 1”M Unit drain Provided by the customer System return Ø...
  • Page 18 GENERAL connections Liquid line Solar system output (option) B. Gas line G. Solar system output (option) C. DHW output H. Electric line input D. Domestic hot water recirculation input (DHW ) System return E. Aqueduct input System outlet Components System exchanger Safety valve system (3 bar) System pump 10.

  • Page 19: Installation Requirements

    5 INSTALLATION REQUIREMENTS If the total refrigerant charge in the system is <1.84 kg there are no minimum surface requirements. a Indoor unit A Room where the unit is installed. B Room adjacent to room A. Area A+B must be greater than or equal to the minimum surface required in table 2 according to the total charge.
  • Page 20 5 INSTALLATION REQUIREMENTS Table 1 - Maximum refrigerant charge allowed in a room: Indoor unit For H values lower than 600 mm, the value of • H considered is 600 mm to comply to IEC 60335-2-40:2018 Clause GG 2. For intermediate Aroom, values, consider the •...
  • Page 21 5 INSTALLATION REQUIREMENTS Table 3 - Minimuim venting opening area for natural ventilation: indoor unit untill 6 kW of power (VAmin) For H values lower that 600 mm, the value of H considered is 600 mm to comply to IEC 60335-2- •...
  • Page 22 5 INSTALLATION REQUIREMENTS Positioning The installation has been implemented by qualified technical personnel only and that the instructions contained in the present manual and the local regulations in force have been adhered to. Choose the installation place according to the following criteria: customer approval •...
  • Page 23 5 INSTALLATION REQUIREMENTS External unit Installed EXTERNAL • in fixed positions • If the unit is installed on a roof or terrace, check the load capacity and the possibility for discharging the condensate. Installation standards: spaces for the air intake/exhaust •...
  • Page 24 5 INSTALLATION REQUIREMENTS 1 Consider clearances and direction of expelled air. Single unit installation 2 Units side by side 3 Units in parallel 4 Keep the min. distances from the podestrian areas. 5 Avoid installations next to bedrooms or windows. Consider sound emissions 6 Provide windbreaks (or similar) in locations with strong winds.
  • Page 25 5 INSTALLATION REQUIREMENTS Condensate drain When a heat pump is running it produces a considerable amount of water due to the defrosting cycles of the external coil. NOTE  The condensation must be eliminated in a manner to avoid wetting pedestrian areas. With extensive very cold outdoor temperatures, condensation could freeze outside the unit blocking the flow and causing a slow build-up of ice;...
  • Page 26 5 INSTALLATION REQUIREMENTS Internal unit installed inside • in a dry room/compartment where the temperature cannot fall • below 0 degrees in fixed positions • Keep to the indicated safety spaces. Prefer places where the unit doesn't disturb the neighbours. Avoid installations in places subject to flooding Avoid installations next to bedrooms or windows.
  • Page 27 5 INSTALLATION REQUIREMENTS Access to the internal parts 1 Remove the screws (A) 2 Remove the panel 3 Remove the screws (B) Remove the panel Same sequence for the opposite side. 4 Electrical panel opening, unscrew knobs (C) Keyboard cable connected...
  • Page 28 5 INSTALLATION REQUIREMENTS Levilling internal unit Position the internal unit on a flat, level surface. Adjust the support feet.

  • Page 29: Water Connections

    6 WATER CONNECTIONS Hydraulic connection schema Make sure that the safety devices are installed on the DHW circuit (thermostatic valve) when the anti- Legionella function is enabled. Indicative plumbing diagram The system components must be defined by Designer and Installer (ex. expansion tanks, vents, taps, calibration/safety valves etc.) Indispensabile components system (not supplied) Domestic Hot Water output...
  • Page 30 6 WATER CONNECTIONS An air bleed valve Install the highest points of tubes in a way that the air can escape form the circuit. Water filter (supplied as standard) The filter is extremely important: it helps to lockout any impurities in the water and avoid clogging the system and heat exchanger.
  • Page 31 6 WATER CONNECTIONS Note  Fill the storage tank (DHW) only during the unit start-up.  If the house is not immediately lived ,or the unit is turned off for long periods, empty the storage tank to avoid the stagnation of the water, or with temperatures close to 0°C the risk of freeze.
  • Page 32 6 WATER CONNECTIONS available. A mesh filter is designed to catch large dirt particles. This filter is usually placed in the part with the larger flow. A tissue filter is designed to catch the finer particles. Exclusions The warranty does not cover damage formed by limestone, deposits and impurities deriving from the water supply and/or by the malfunctioning of the system cleaning system.
  • Page 33 6 WATER CONNECTIONS Domestic hot water tank charge Maximum DWH system pressure 6 bar DWH saftey valve setting 6 bar 1 Before charging, position the systems general switch in the 'off' position . 2 Check that the draining taps of the system DWH are closed (A).

  • Page 34: Refrigerating Connections

    7 REFRIGERATING CONNECTIONS Refrigerant lines Unit is designed to ensure the best comfort and energy efficiency levels. To maintain these high values is necessary to consider the system details that could adversely affect on performances. NOTE Warning: Fire hazard In particular: Flammable materials ...
  • Page 35 7 REFRIGERATING CONNECTIONS Ducting Pressure Equipment Directive This unit is a subset: to operate it has to be combined to another unit. It is an installer responsability : follow the PED Directive and to the national regulations of PED • Directive realization consider the insertion of any additional security devices •...
  • Page 36 7 REFRIGERATING CONNECTIONS Internal unit Type of pipes The internal unit shipped with a nitrogen charge Size . 4kW - 6kW 8kW - 10kW of about 1 bar. If it is discharged, test the leaks also before the Liquid Ø external 1/4”...
  • Page 37 7 REFRIGERATING CONNECTIONS internal unit vacuum operation is delivered with charged refrigerator circuits in the following manner: Internal unit Nitrogen precharge External unit charged with refrigerant (voltage 220-240 ~ 50) Size 8kW - 10kW 1,55 1,55 1,65 * total charge t CO2-eq 1,04 1,04...
  • Page 38 7 REFRIGERATING CONNECTIONS After having completed the refrigerating connections the sealing of the refrigerating circuit must be checked: maintain close the indoor unit cocks 1 and 2 • connect pipes D and H to cocks 1 and 2 • • close cocks A, B, C and I •...

  • Page 39: Electrical Connections

    8 ELECTRICAL CONNECTIONS The characteristics of the lines must be determined by specialized personnel able to design electrical installations in compliance with This unit is required reliable earthing regulations in force. before usage, otherwise might cause The protective equipment of the unit supply line must be able to death or injury.
  • Page 40 8 ELECTRICAL CONNECTIONS Electrical connection schema...
  • Page 41 8 ELECTRICAL CONNECTIONS Settaggio dip-switch External unit connected. Set dip-switch according to the installed unit. DIP switch ON=1 OFF=0 Size 4kW-6kW Size 8kW-10kW Outdoor unit size 8kW - 10kW Outdoor unit size 4kW - 6kW With solar Without solar 0/0= without IBH end AHS 1/0= with AHS for heat mode 0/1= with IBH 1/1= with AHS for heat mode and DHW mode...
  • Page 42 8 ELECTRICAL CONNECTIONS Connection wired controller Power supply Connection outdoor unit Solar pump Solar signal input Zone pump 1 Connection solar pump station 220/240VAC input Zone pump 2 DHW recirculation...
  • Page 43 8 ELECTRICAL CONNECTIONS Thermostat connection Method 2 Method 1 Method 3 Remote switch or tank booster heater switch Valve 3-way 2-way Mixing valve Antifreeze e-heating tape Defrost...
  • Page 44 8 ELECTRICAL CONNECTIONS Additional heat source...
  • Page 45 8 ELECTRICAL CONNECTIONS External unit connections Carry out the connection in accordance with the electric connection layout. Remove screws A Remove the protective cover B Power supply 220-240 ~ 50HZ Bus connections Use a 3-conductor shielded cable as an internal/external signal cable, and earth the shielding.
  • Page 46 8 ELECTRICAL CONNECTIONS Boiler connection (to be supplied by the client) Boiler Electrical connection T1 = water temperature probe (positioned inside the unit) KM10 = Relè (provided by the customer) YV1 = 2-way valve (to be supplied by the client) with end contact to enable the boiler P = pump (provided by the customer) Set DIP 4 of bank S1 to ON value...

  • Page 48: Start - Up

    9 START-UP General The indicated operations should be done by F.GAS qualified technician with specific training on the product. Upon request, the service centres performing the start-up. The electrical, water connections and the other system works are by the installer. Agree upon in advance the star-up data with the service centre.
  • Page 49 9 START-UP Are the anti-vibration joints on the hydraulic connections present ? Was the system loaded, placed under pressure and was the air let out ? Have you verified the expansion tank charge ? Is the solar installation present? The circuit is charged? Was the condensate produced by the external unit drained correctly ? Can it freeze ? Is the capacity of air to the external unit adequate ? Is there air recirculation ? Have the electrical connections to the external unit been made ?
  • Page 50 9 START-UP Refrigerant circuit 1 Visually inspect the refrigerating circuit: the presence of oil stains can by a symptom of leakage (caused e.g. by transportation, handling or other). 2 Verify that the refrigerating circuit is in pressure: Using the unit manometers, if present, or service manometers. 3 Make sure that all the service outlets are closed with proper caps;...
  • Page 51 9 START-UP Compressor casing resistances Connect the compressor oil heating resistances at least 8 hours before the compressor is to be started: at the first unit start-up • after each prolonged period of inactivity • 1 Power the heaters: isolator switch on 1 / ON. 2 Check the power consumption of the resistances to make sure that they are functioning.
  • Page 52 9 START-UP Field settings During installation, the unit settings and parameters should be configured by the installer to suit the installa- tion configuration, climate conditions and end-user preferences. The relevant settings are accessible and programmable through the FOR SERVICEMAN menu on the unit user interface.
  • Page 53 9 START-UP Description of terms About FOR SERVICEMAN The terms related to this unit are shown in the FOR SERVICEMAN is designed for the installer to table below. set the parameter. • Setting the composition of equipment. Setting the parameter. •...
  • Page 54 9 START-UP DHW：domestic hot water DHW MODE SETTING typically consists of the following: DHW MODE: enable or disable the DHW mode • DISINFEZIONE: enable or disable the • disinfection DHW PRIORITY：set the priority between • domestic hot water heating and space operation.
  • Page 55 9 START-UP Figure (under) illustrates the operation of the T4DHWMIN sets the outside temperature below heat pump and immersion heater in DHW mode. which the heat pump will not operate in DHW If the DHW tank water temperature (T5) is less mode.
  • Page 56 9 START-UP DHWPUMP TIME RUN sets whether or not the user is able to set the recirculation pump in DHW mode. For installations with a recirculation pump, select ON so that the user is able to set pump start times. PUMP RUNNING TIME sets the length of time the pump runs for at each of the user specified start times on the DHW PUMP tab on the DOMESTIC...
  • Page 57 9 START-UP T4CMAX sets the outside temperature above dTSC sets the temperature difference between which the heat pump will not operate in cooling the actual room temperature (Ta) and set room mode. The maximum value that T4CMAX can take temperature (TS) above which the heat pump is 46°C, which is the cooling mode upper outside provides chilled water to the space cooling temperature operating limit of the heat pump.
  • Page 58 9 START-UP T4HMIN sets the outside temperature below Menu HEATING MODE SETTING which the heat pump will not operate in heating MENU > FOR SERVICEMAN > HEAT MODE SETTING mode. The lowest value that T4HMIN can take is -25°C, which is the heating mode lower outside temperature operating limit of the heat pump.
  • Page 59 9 START-UP ZONE1 H-EMISSION sets the emission type for Menu TEMP. TYPE SETTING heating mode. MENU > FOR SERVICEMAN > TEMP. TYPE SETTING Select type: RAD = radiators FCU = fancoil FLH = radiant panels ZONE2 H-EMISSION sets the emission type for heating mode.
  • Page 60 9 START-UP Menu ROOM THERMOSTAT dT1_IBH_ON sets the temperature difference between the heat pump’s leaving water set MENU > FOR SERVICEMAN > ROOM THERMOSTAT temperature (T1S) and the heat pump’s leaving water temperature (T1) above which the backup electric heater heating element(s) are on. When T1S - T1 ≥...
  • Page 61 9 START-UP MenU RESTORE FACTORY SETTINGS Menu HOLIDAY AWAY SETTING MENU > FOR SERVICEMAN > RESTORE FACTORY MENU > FOR SERVICEMAN > HOLIDAY AWAY SETTINGS SETTING RESTORE FACTORY SETTINGS is used to restore all the parameters set in the user interface to their factory defaults.
  • Page 62 9 START-UP AIR PURGE operation MENU > FOR SERVICEMAN > TEST RUN > AIR PURGE Once installation is complete it is important to run the air purge function to remove any air which may be present in the water piping and which could cause malfunctions during operation.
  • Page 63 9 START-UP After a further 2 mins the flow switch start to HEAT MODE RUNNING operation check the water flow. If the water flow rate is MENU > FOR SERVICEMAN > TEST RUN > HEAT sufficient, both PUMPI and PUMPO operate until MODE RUNNING the next command is received.
  • Page 64 9 START-UP DHW MODE RUNNING operation PREHEATING FOR FLOOR MENU > FOR SERVICEMAN > TEST RUN > DHW MENU > FOR SERVICEMAN > SPECIAL FUNCTION > MODE RUNNING PREHEATING FOR FLOOR The DHW MODE RUNNING operation is used to check the operation of the system in DHW mode During the DHW MODE RUNNING operation, the DHW set temperature is 55°C.
  • Page 65 9 START-UP Whilst the preheating for floor operation is For newly-installed under floor heating systems, running, the number of minutes that it has been floor drying up mode can be used to remove running for and the heat pump’s leaving water moisture from the floor slab and subfloor to temperature are displayed on the user interface.
  • Page 66 9 START-UP POWER INPUT LIMITATION MENU > FOR SERVICEMAN > POWER INPUT LIMITATION How to set the POWER INPUT LIMITATION AUTO RESTART MENU > FOR SERVICEMAN > AUTO RESTART The AUTO RESTART function is used to select whether the unit reapplies the user interface settings at the time when power returns after a INPUT DEFINE power supply failure.
  • Page 67 9 START-UP CLIMATE CURVES The climate related curves can be selected in the user interface, MENU > PRESET TEMPERATURE > WEATHER TEMP. SET. The curves for heating mode and ECO heating mode are the same but the default curve is curve 4 in heating mode, while in ECO mode, the default curve is curve 6.
  • Page 68 9 START-UP Figure B High temperature curves for heating mode Note: It only has the curves of the high temperature setting for heating, if the high temperature is set for heating. Curve 4 is default in high temperature heating mode and curve 6 is default in ECO mode. Figure C Low temperature curves for cooling mode Notes:...
  • Page 69 9 START-UP Figure D High temperature curves for cooling mode Notes: It only has the curves of the high temperature setting for cooling, if the high temperature is set for cooling. Curve 4 is default in high temperature cooling mode. Automatic setting curve for heating mode Automatic setting curve for cooling mode The setting of T1SETH1, T1SETH2, T4H1, T4H2 refer to Part HEATING MODE SETTING Menu”...
  • Page 70 10 CONTROL Functionn Enter the menu structure from the home page MENU To set the ON / OFF functionor DHW mode turn on or off the func- ON / OFF tion in the menu structure Long press for unlocking /locking the controller UNLOCK Go to the next step when programming a schedule in the menu struc- LEFT - R...
  • Page 71 10 CONTROL Lock The compressor is activated At the next scheduled action, the temperature The pumpi is activated will decrease. The temperature not change Weekly schedule The temperature will decrese Timer The temperature will increse Outside temperature Fan coil Wi-Fi Radiator Domestic hot water The disinfect (anti-legionella) function is acti-...

  • Page 72: Control

    10 CONTROL Fan coil Radiator The floor hea ng Domes c hot water Energy cost Free High Smart grid Energy source Photovoltaics From the network From the network Energy absorbed Everage Everage Peak The main screen changes according to the type of system The installer is responsible for configuration.
  • Page 73 10 CONTROL Menu structure Press 3 sec. "UNLOCK" to unlock the keyboard. Operation mode Service information Service call Heat Cool Error code Parameter Auto Diplay Preset temperature Preset temperature Operation parameter Weather temperature set Consultation only ECO mode For serviceman * Domestic hot water (DHW) Please input the password Disinfect (anti-legionella)
  • Page 74 10 CONTROL Using home pages When you turn on the wired controller, the system will enter the language selection page, You can choose your preferred language, then press OK to enter the home pages. If you don't press OK in 60 seconds, the system will enter in the currently selected language. You can use the home pages to read out and change settings that are meant for daily usage.
  • Page 75 10 CONTROL Menu structure About the menu structure You can use the menu structure to read out and configure settings that are NOT meant for daily usage. What you can see and do in the menu structure is described where applicable. To go to the menu structure From a home page, press MENU.
  • Page 76 10 CONTROL If the inerface is unlocked, long press "UNLOCK", the interface will be locked. Long press Long press UNLOCK UNLOCK Turning ON/OFF controls Use the interface to turn on or off the unit for space heating or cooling. The ON/OFF of the unit can be controlled by the interface if •...
  • Page 77 10 CONTROL If DHW MODE SETTING is set on NO, the following screens will be displayed without the DHW function. Use the room thermostat to turn on or off the unit for space heating or cooling. Turning on or off cooling/heating mode is 1.
  • Page 78 10 CONTROL Press RIGHT on the screen and the black cursor appears. When the cursor is on the system temperature side, press the ON/OFF button to turn the radiant panels on/off. The following page is displayed Use the interface to turn on or off the unit for DHW. Press RIGHT on home page, the black cursor will appear When the cursor is on the DHW temperature side, press the ON/ OFF button to turn the domestic hot water production on/off.
  • Page 79 10 CONTROL Adjusting the temperature System water / DHW Press LEFT or Up on home page, the black cursor will appear If the cursor is on the temperature, use the LEFT , RIGHT to select and use Up, Down to adjust the temperature.
  • Page 80 10 CONTROL Adjusting space operation mode Adjusting space operation mode by interface Go to MENU > OPERATION MODE . Press OK The following page will appear: There are three modes to be selected including HEAT, COOL and AUTO mode. Use the LEFT or RIGHT to scroll, press ”OK” to select. Even you don’t press OK button and exit the page by pressing BACK button, the mode would still be effective if the cursor had been moved to the operation mode.
  • Page 81 10 CONTROL Preset Temperature PRESET TEMPERATUER has PRESET TEMP.\WEATHER TEMP. SET\ECO MODE 3 items. Preset Temperature PRESET TEMP. function is used to set different temperature on different time when the heat mode or cool mode is on. PRESET TEMP.= PRESET TEMPERATUER PRESET TEMP.
  • Page 82 10 CONTROL You press OK, and the ■ becomes. The timer 1 is selected. You press OK again, and the becomes ■. The timer 1 is unselected. Press LEFT , RIGHT, Down, UP to scroll and press Down, UP to adjust the time and the temperature Six periods and six temperatures can be set.
  • Page 83 10 CONTROL Weather temperature set WEATHER TEMP. SET= WEATHER TEMPERATURE SET WEATHER TEMP.SET function is used to preset the desired water flow temperature depending on the outside air temperature. During the warmer weather the heating is reduced. To save energy, the weather temp.set can decrease the desired water flow temperature when the outdoor air temperature increased in heating mode.
  • Page 84 10 CONTROL If the WEATHER TEMP.SET is actived, the desired temperature can not be adjusted on the interface. Weather temp.set function is The following page will appear Do you want to turn off it? Move to “NO”, press “OK” to come back to home page, move to “YES”, press “OK”...
  • Page 85 10 CONTROL The following page will appear: Press ON/OFF to turn ON or OFF, and press Up, Down to scroll When the cursor is on the START or on the END, you can press LEFT , RIGHT, Down, Up to scroll and press Up, Down to adjust the time.
  • Page 86 10 CONTROL Domestic Hot Water (DHW) DHW mode typically consists of the following : 1 DISINFECT (anti-legionella) 2 FAST DHW 3 TANK HEATER 4 DHW PUMP (DHW recirculation) DISINFECT (anti-legionella) The DISINFECT function is used to kill the legionella. In disinfect function the tank temperature will be reached 65~70°C forcely.
  • Page 87 10 CONTROL FAST DHW The function is used to force the system to operate in DHW mode. The heat pump and the storage resistance will operate together, and the DHW desired temperature will be changed to 60°C Go to MENU> DOMESTIC HOT WATER > FAST DHW. Press “OK”: Press "ON/OFF"...
  • Page 88 10 CONTROL Press ''ON/OFF''' to select ON or OFF. Use ''BACK''' to exit. If TANK HEATER is effect, the following page will appear Information If CURRENT STATE is OFF, TANK HEATER is invalid. If the T5(sensor of tank) is fault ,tank heater can’t work. DHW Pump (recirculation) if present The pump is the provided by the Customer The DHW PUMP function is used to return water of the water net.
  • Page 89 10 CONTROL Schedule SCHEDULE menu contents as follows: 1) TIMER for daily programming. 2) WEEKLY SCHEDULE for weekly programming. 3) SCHEDULE CHECK to check programming 4) CANCEL TIMER to cancel programming TIMER If weekly schedule is ON and the TIMER function is OFF, the setting that is activated takes precedence over the setting that is not.
  • Page 90 10 CONTROL The operation of the controller at the following time: The operationof the controller TIME DHW mode is turned ON 1:00 DHW mode is turned OFF 3:00 HEAT MODE is turned ON 7:00 HEAT MODE is turned OFF 9:00 COOL MODE is turned ON 11:30 COOL MODE is turned OFF...
  • Page 91 10 CONTROL Press LEFT or RIGHT to scroll through the days, press "OK" to select or unselect the day. The Monday to Friday are selected to be scheduled and they have the same schedule. Press RIGHT until the cursor is on CONFIRM, then press OK The following pages will appear ENTER Press LEFT , RIGHT, Down, UP to scroll and adjust the time ,the...
  • Page 92 10 CONTROL Press Down, UP , the timer from Monday to Sunday will appear Cancel timer go to MENU > SCHEDULE > CANCEL TIMER Press ''OK''. The following page will appear Press LEFT , RIGHT, Down, UP to move to “YES” , press OK to cancel timer.
  • Page 93 10 CONTROL Information The ECO or COMFORT MODE has the highest priority, the TIMER or WEEKLY SCHEDULE has the second priority and the PRESET TEMP. Or WEATHER TEMP. SET has the lowest priority. The PRESET TEMP. or WEATHER TEMP. SET becomes invalid, when we set the ECO or COMFORT valid.
  • Page 94 10 CONTROL Options OPTIONS menu contents as following: 1) SILENT MODE 2) HOLIDAY AWAY 3) HOLIDAY HOME 4) BACKUP HEATER Silent mode The SILENT MODE is used to decrease the sound of the unit. However, it also decreases the heating/cooling capacity of the system.
  • Page 95 10 CONTROL If the silent TIMER is selected, Press “OK” to enter, the following page will appear. There are two timers for setting. Move to ■, press '' OK '' to select or unselect. If the two time are both unselected,the silent mode will operate in all time.
  • Page 96 10 CONTROL If holiday away mode is ON, The timer and weekly schedule are invalid except exit. If the CURRENT STATE is OFF,the HOLIDAY AWAY is OFF. If the CURRENT STATE is ON,the HOLIDAY AWAY is ON. The remote control doesn’t accept any orders when holiday away mode is ON.
  • Page 97 10 CONTROL The following page will appear OPTIONS Press LEFT , RIGHT, Down, UP to scroll and press Down, UP to SILENT HOLIDAY BACKUP HOLIDAY MODE AWAY HEATER HOME adjust the time, the mode and the temperature. Move to ■ , press '' OK '' to select or unselect ( the timer is START MODE...
  • Page 98 10 CONTROL Backup Heater (Currently not available) The BACKUP HEATER function is used to force the backup heater. Go to MENU > OPTIONS > BACKUP HEATER. Press ''OK'' . If IBH and AHS is set invalid by DIP switch on the main control board of hydraulic module, the following page will appear IBH= Indoor unit backup heater.
  • Page 99 10 CONTROL The cool/heat mode can't turn on or off when the COOL/HEAT MODE ON/OFF is locked. Cooling or heating mode’s ON/OFF is If you want to turn on or off the cool/heat mode when COOL/ locked. HEAT MODE ON/OFF is locked,the following page will appear Do you want to unlock? The DHW temperature can't be adjusted when the DHW TEMP.
  • Page 100 10 CONTROL Error code is used to show when the fault or proction happen and show the mean of the error code. Press OK the page will appear Press OK to show the mean of the error code E2 comunication fault between controller and indoor unit Information Please contact your dealer.
  • Page 101 10 CONTROL The DISPLAY function is used to set the interface Press ''OK'' to enter and press LEFT , RIGHT, Down, UP to scroll. Operation Parameter This menu Operation parameter is for installer or service engineer reviewing the operation parameter. The values shown on the screens are only indicative At home page, go to MENU >...
  • Page 102 10 CONTROL Information The power consumption parameter is preparatory. if some parameter not be activated in the system, the parameter will show "--" The heat pump capacity is for reference only, not used to judge the ability of the unit. The accuracy of sensor is ±1°C The flow rates parameters are calculated according to the pump running parameters,the deviation is different at different flow rates,the maximum of deviation is 15%.
  • Page 103 10 CONTROL How To Exit For SERVICEMAN If you have set all the parameter. Press ''BACK'', the following page will appear Active the setting and exit? Select ''YES'' and press ''OK'' to exit the FOR SERVICEMAN. After exiting the FOR SERVICEMAN, the unit will be turned off.
  • Page 104 10 CONTROL Table1 The outside temperature curve of the low temperature setting for heating 1-T1S 4- T1S ≥ 20 1-T1S 4- T1S Table2 The outside temperature curve of the low temperature setting for heating 1-T1S 4- T1S 1-T1S 4- T1S...
  • Page 105 10 CONTROL The automatic setting curve The automatic setting curve is the ninth curve,this is the calculation: State: setting from wired controller, if T4H2<T4H1, exchange value; if T1SETH1<T1SETH2, exchange value. Table3 The outside temperature curve of the low temperature setting for cooling -10 ≤...
  • Page 106 10 CONTROL Table4 The outside temperature curve of the high temperature setting for cooling -10 ≤ T4 ＜15 15 ≤ T4 ＜22 22 ≤ T4 ＜30 30 ≤ T4 ＜46 1 - T1S -10 ≤ T4 ＜15 15 ≤ T4 ＜22 22 ≤...
  • Page 107 10 CONTROL UNIT stata During the Sphera operation is possible to visualize the unit status by the values obtained from sensors and from the main unit operating parameters. Signification Description Operating frequency Compressor operating frequency in Hz. Send value = actual value The actual operating mode of the whole machine.
  • Page 108 10 CONTROL BIT15 Reserved BIT14 Reserved BIT13 Reserved BIT12 Reserved BIT11 Reserved BIT10 Reserved BIT9 Water tank anti-freezing BIT8 Solar signal input Status bit 1 BIT7 Room thermostat refrigeration BIT6 Room thermostat heating BIT5 Foreign machine test mode flag BIT4 Remote ON/OFF (1 : d8) BIT3 Return oil...
  • Page 109 10 CONTROL TF module temperature Units ( ) - Outside machine feedback Water conservancy module curve Actual value - Registration result corresponding to area 1 T1S calculated value1 Water conservancy module curve Actual value --- Calculation result corresponding to area 2 T1S calculated value2 Water flow Actual value *100 units: M3/H...
  • Page 110 10 CONTROL Allarms In case of maloperations the alarms are indicated by the 'Alarm in progress' symbol on the multifunctional keypad. To view the alarms select Menu  Service information To reset the alarm remove its cause and reset the active alarm. Before resetting an alarm identify and remove the cause that generate it.
  • Page 111 10 CONTROL DC fan failure Voltage protection fault High pressure sensor failure (replacement with resistor when the external unit is not instal- led) H6 fault occurs twice in 10 minutes (can be restored after power off) Three times of low pressure protection (less than 0.6MPa ) occurredcontinuously within 1 hour PFC module failure Low voltage switch protection...
  • Page 112 The access to parameters or modifications are allowed only to the installer who assumes all responsibility, in case of doubts please contact Airwell. For any changes not permitted or not approved by Airwell, the same declines any responsibility for malfunctions and/or damages to the unit/system.
  • Page 113 10 CONTROL BIT15 Support for backup heat source (IBH ) Reserved BIT14 IBH supports heating function Reservation BIT13 IBH supports hot water Reserve BIT12 Reservation BIT11 AHS supports heating function Reservation BIT10 AHS supports hot water function Reserve BIT9 Support solar module Reservation Input port definition: BIT8 0= remote switch...
  • Page 114 10 CONTROL dTSH Default: 2°C, range: 1-10°C, adjustment interval 1°C T4hmax Default: 25°C, range: 20-35°C, adjustment interval 1°C T4hmin Default: -15°C, range: -20-5°C, adjustment interval 1°C Hydraulic module electric auxiliary heat IBH to open the ambient temperature, the T4_IBH_on setting range: -15~10°C, default value: -5°C Hydraulic module electric auxiliary heat IBH open temperature difference, setting dT1_IBH_on range: 2~10°C, default value 5°C...
  • Page 115 10 CONTROL T1SetC1 Cooling temperature curve 9 parameters, setting range 5-25°C, default 10°C T1SetC2 Cooling temperature curve 9 parameters, setting range 5-25°C, default 16°C T4C1 Cooling temperature curve 9 parameters, setting range (-5)-46°C, default 35°C T4C2 Cooling temperature curve 9 parameters, setting range (-5)-46°C, default 25°C T1SetH1 Heating temperature curve 9 parameters, setting range 25-60°C, default 35°C T1SetH1...
  • Page 116 11 MAINTENANCE General Maintenance must be performed by authorized centres or by qualified personnel The maintenance allows to: maintaining the unit efficient • reduce the deterioration speed all the equipment is subject to • over time collect information and data to understand the efficiency state •...
  • Page 117 11 MAINTENANCE SAFETY WARNINGS FOR OPERATIONS ON UNITS CONTAINING R32 Area checks Before working on systems containing flammable refrigerants, perform safety checks to reduce the risk of combustion to the minimum. Before performing any reparation operations on the cooling system, comply with the following warnings.
  • Page 118 11 MAINTENANCE containing refrigerant, unless they are manufactured with material intrinsically resistant to corrosion or suitably protected against corrosion. Electrical device checks The reparation and maintenance of electric components must include initial safety checks and component inspection procedures. In case of a fault that compromises safety, do not perform any electrical connection to the circuit until said fault is suitably resolved.
  • Page 119 11 MAINTENANCE Check that the detector is not a possible source of ignition and that it is suitable for the refrigerant. Leak detection equipment must always be set to an LFL percentage and calibrated depending on the refrigerant used, so the correct gas percentage (25% max) must be verified. Leak detection fluids are suitable for most refrigerants, although using detergents containing chlorine should be avoided as this substance may react with the refrigerant and corrode copper pipes.
  • Page 120 11 MAINTENANCE Electrically isolate the system. • Before attempting the procedure, check that: The mechanical manipulation equipment is available, if necessary, to handle refrigerant tanks; • All the personal protection equipment is available and employed correctly; • The recovery procedure is monitored at all times by skilled personnel; •...

  • Page 121: Maintenace

    11 MAINTENANCE 2 Marking of equipment with symbols Compliance with local regulations 3 Disposal of equipment employing flammable refrigerants Compliance with national regulations 4 Storage of equipment/devices The equipment must be stored in compliance with the instructions provided by the manufacturer. 5 Storing packed (unsold) equipment Packing must be performed in such a way that mechanical damage to the equipment inside it does not cause refrigerant leaks.
  • Page 122 11 MAINTENANCE Checklist for recommended regular checks Checks effected on…………………...…………..by……………………………………….of the company…………………………………….. intervention frequency (months) √ □ Panel fixing □ External unit fan fixing □ External unit coil cleaning □ Charged pressure of water system □ Docking joints, caps and shafts □...
  • Page 123 11 MAINTENANCE Unit booklet It’s advisable to create a unit booklet to take notes of the unit interventions. In this way, it will be easier to adequately schedule the various interventions and facilitate any troubleshooting. On the schedule note: date •...
  • Page 124 11 MAINTENANCE External unit fan Check: ensure that the fan and the relative protection grids are well • fixed The fan bearings (evident by noise and anomalous • vibrations ) the terminal protection covers are closed and the cable • holders are properly positioned Access to the fan Remove the screws (A)
  • Page 125 11 MANUTENZIONE Outdoor unit air coil Accidental contact with the exchanger flaps can cause injuries from cut: use protective gloves. The coil must allow maximum thermal exchange, therefore, the surface must be clear from dirt and scaling. Clean the air inlet side. Use a soft brush or aspirator or pressurised air jet or high- pressure water jet machine.
  • Page 126 11 MAINTENANCE Periodic system checks Charge check of expansion tanks • Water filter cleaning check • Check system and aqueduct operating pressures • Expansion vessel Check the expansion vessel charge (at least once a year). First check that the expansion vessel is totally drained of water. If you necessary load with nitrogen, take care that the pressure does not exceed the value indicated on the label.
  • Page 127 11 MAINTENANCE Magnetic sludge Magnetic filter “A” separates the impurities (sand particles, rust ... etc) present in the system water. The impurities are collected in a settling chamber. Cleaning the filter can also be done with a working system. Clean the filter: During the start up of the unit •...
  • Page 128 11 MAINTENANCE Anode rod replace The magnesium sacrificial anodes assure the storage tank anti- corrosive protection. The magnesium anode is replaced when its diameter is ≤ of a third of the original anode. Remove power supply Turn off the water inlet valve (A) •...
  • Page 129 12 DISPOSAL Disconnection WARNING  Before performing any operation, read the warnings found in the Maintenance chapter. Avoid leak or spills into the environment. Before disconnecting the unit, the following must be recovered, if present: Warning: • refrigerant gas Fire hazard Flammable materials Anti-freeze solutions in the hydraulic circuit •...
  • Page 130 14 TECHNICAL INFORMATION Dimensional Internal unit Domestic hot water outlet M 3/4” Aqueduct inlet M 3/4” Return from user side system M 1” Supply to the utility installation M 1” Gas line 5/8” SAE Liquid line 3/8” SAE Electric line input Dhw recirculation circuit inlet M 3/4”...
  • Page 131 14 TECHNICAL INFORMATION External unit Size 4kW - 6kW Compressor compartment Electrical panel Power input Condensate drain Liquid line connection Suction line connection Functional spaces Electric fan (M) Air supply Size Operating weight Shipping weight...
  • Page 132 14 TECHNICAL INFORMATION Size 8kW - 10kW Compressor compartment Electrical panel Power input Condensate drain Liquid line connection Suction line connection Functional spaces 8kW - 10kW Size Electric fan Operating weight (M) Air supply Shipping weight...
  • Page 133 14 TECHNICAL INFORMATION General techinacal data Size 10kW Heating Air 7°C - Water 35°C Heating capacity 4,49 6,32 8,37 10,26 Total power input 0,90 1,32 1,72 2,19 5,01 4,79 4,87 4,68 Water flow-rate 0,22 0,31 0,41 0,48 Nominal available pressure Maximum available pressure Air -7°C - Water 35°C Heating capacity...

  • Page 134: Disposal

    14 TECHNICAL INFORMATION User side entering/leaving water temperature 30/35 °C, source side air 7°C (U.R. = 85% Heat power data, Total power input and COP in accordance with EN 14511:2018 User side entering/leaving water temperature 30/35 °C, source side air -7°C Heat power data, Total power input and COP in accordance with EN 14511:2018 User side entering/leaving water temperature 40/45 °C, source side air 7°C (U.R.

  • Page 135: Accessories

    14 TECHNICAL INFORMATION Construction - Indoor unit Size System characteristics Maximum circuit pressure System expansion tank DHW characteristics Type Storage tank Vitrified Steel Volume of DHW tank Internal pipe coil exchange surface 2,32 Storage dipersion W/K (kWh/24h) 1,81 (2,04) DHW safety heating element Maximum DHW circuit pressure Recommended sanitary expansion tank Dimensions...

  • Page 136: Technical Data

    14 TECHNICAL INFORMATION Operational limits - Cooling Twu [°C] = Exchanger water outlet temperature Tae [°C] = Outdoors exchanger air inlet temperature Normal operating range Operational limits - Heating Twu [°C] = Exchanger water outlet temperature Tae [°C] = Outdoors exchanger air inlet temperature Normal operating range Operational limits - Domestic hot water Twu [°C] = Temperature domestic hot water...
  • Page 137 15 - ENERGY DATA SHEETS AND LABELLING AW-WHPST0410-N91 + AW-YHPS04-H91 2019 811/2013...
  • Page 138 AW-WHPST0410-N91 + AW-YHPS06-H91 2019 811/2013...
  • Page 139 AW-WHPST0410-N91 + AW-YHPS08-H91 2019 811/2013...
  • Page 140 AW-WHPST0410-N91 + AW-YHPS10-H91 2019 811/2013...
  • Page 141 Damien MONTIGNY-LE-BRETONNEUX URNAME/ OM / OGNOME / UNAME / PELLIDOS Riccio 12/03/2020 OMPANY POSITION / ONCTION / OSIZIONE / ETRIEBSPOSITION / ARGO DIRECTEUR GÉNÉRAL AIRWELL RESIDENTIAL SAS - 10 RUE DU FORT DE ST CYR, 78180 MONTIGNY-LE-BRETONNEUX - FR -...
  • Page 142 INSTALLATION & OPARATING MANUAL WELLEA SPLIT TANK R32 Indoor & Outdoor WARNING : The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details. 20AW-INSTALLATION & OPERATING MANUAL WELLEA SPLIT TANK R32-EN-20200421...
