4-2-6.

Cabinet (G) Section

• Refer to
"Cabinet (G) Section"
253
254
255
264
CAUTION :
For the part of 256 : TAPE (HS16-010 (10X10)), cut TAPE
(HS16-010 (10X40)) (4-548-622-01) into the desired length and use it.
256 : TAPE (HS16-010 (10X10)) は, TAPE (HS16-010 (10X40))
(4-548-622-01) を切って使用すること。
PXW-X160/PXW-X180
on exploded view for Ref. No.
251
#53
A
B
#53
#53
ANT901
X180 Only
252
#53
257
258
259
#53
260
A
261
262
#49
B
#50
263
256
(Size:10mm x 10mm)
4-13
