FAS9000 Systems
Installation and Setup Instructions
Prepare for installation | 1
1. Unpack all boxes and inventory contents.
Pre-setup
Attention: Customers with specific power requirements must check
2. Watch the
3. Review the
In the box
10 GbE network cable
Part number 112-00299,
112-00300, or 112-00301
40 GbE network cable
Part number 112-00543
You provide
Setup Videos.
NetApp ONTAP Configuration Guide.
Host cables
Storage cables
MiniSAS HD cable
Part number 112-00436,
112-00437, or 112-00438
Optical network cable
Part number 112-00188,
112-00189, or 112-00090
Rack space
8U per chassis
Prepare for installation
1
Hardware Universe
Controller-to-controller cables
40 GbE cluster interconnect cable
Part number 112-00542 or 112-00543
USB console cable
Part number 112-00508
Screwdriver
Additional network cables
Phillips #2
For connecting your storage
to your network switch and client
Install hardware
Cable storage
2
for their configuration options.
Cable management device
Ethernet cables
Power cables
Note: For more cable information and
part numbers, see the
Laptop or console
With a USB/serial connection and
access to a Web browser to configure
Complete system setup
and configuration
3
4
Slide rail kit
Hardware
Universe.
your storage system
215-15154_2020-12_en-us
