AFF A700 and
FAS9000 Systems
Installation and Setup Instructions
6-1
6-2
Prepare for installation | 1
1. Go to
Pre-setup
2. Unpack all boxes and inventory contents.
3. Go to the
- Download
- Download and complete the
- Watch the videos listed under
In the box
You provide
mysupport.netapp.com
and
create an
AFF and FAS System Documentation Center
Config
Advisor.
Cluster Configuration
Setup
videos.
Host cables
10 GbE network cable
Part number 112-00299,
112-00300, or 112-00301
40 GbE network cable
Part number 112-00543
Rack space
8U per chassis
Prepare for installation
1
account,
register your
system, and
and click AFF A700 and FAS9000 systems, and then Installation and Setup:
Worksheet.
Storage cables
Controller-to-controller cables
MiniSAS HD cable
40 GbE cluster interconnect cable
Part number 112-00436,
Part number 112-00542 or 112-00543
112-00437, or 112-00438
Optical network cable
Part number 112-00188,
112-00189, or 112-00090
Screwdriver
Additional network cables
Phillips #2
For connecting your storage
to your network switch and client
Install hardware
Cable storage
2
get your license
keys.
USB console cable
Part number 112-00508
Runs the software to configure
Complete system setup
and configuration
3
4
Ethernet cables
Power cables
Client
your storage system
210-06635+B0
Advertisement
Related Manuals for NetApp AFF A700
Summary of Contents for NetApp AFF A700
- Page 1 Pre-setup 2. Unpack all boxes and inventory contents. 3. Go to the AFF and FAS System Documentation Center and click AFF A700 and FAS9000 systems, and then Installation and Setup: - Download Config Advisor. - Download and complete the Cluster Configuration...
- Page 2 Install hardware | 2 Unpack and install the system. • Unpack all boxes and inventory contents. 90 lbs. (41 kg) Empty chassis • Install rail kits, as needed, using the rail kit installation instructions. • Install the empty chassis into the system cabinet or rack. 240 lbs.
- Page 3 Cable storage | 3 Cabling a FAS9000 or an AFF A700 WITH external storage (DS212C or DS224C disk shelves) Mini-SAS HD cable 112-00436, 112-00437, or 112-00438 Connect the shelf-to-shelf ports Connect the controllers to Stack 1 Connect the controllers to Stack 2...
- Page 4 Complete system setup and configuration | 4 Cable and configure your client AFF A700/FAS9000 system micro USB console cable Connect the console cable to the client and the console port on the controller module. Client Ethernet cable Connect the client to the switch on the management subnet: a.
