TX Illumination
1
HDMI interface, connect
display or projector
3
Indicator light
RX Illumination
1
HDMI interface,connect
display or projector
3
Indicator light
Indicator light
TX
Light Red
Flash Blue
Static Blue
RX
Flash Blue
ASK nano
2
4
2
4
Illumination
TX is opening
Waiting for the connection
Successful connection and projection
Illumination
RX is power on and ready for projection
User Manual
Projection key
Micro USB Power interface
Mode switch key,switch
TX/DLNA/AirPlay Mode and
Miracast Mode
Micro USB power interface
8
