RGBlink ASK nano RX Quick Manual

Settings Wi-Fi
Wi-Fi
ASK nano-XXXXXX
i
Screen Mirroring
ASK nano-XXXXXX
Screen
Mirroring
5
Wi-Fi
Use Wi-Fi
ASK nano XXXXXX
XXXXXX
Android XXXXXX
XXXXXX
XXXXXX
6
Specification
7

Trouble Shooting

Q: What if the pairing of TX and RX fail?
A:
Press the switch on ASK nano RX to switch mode.
●
Power the ASK nano TX by Micro-USB cable.
●
Q: Why is there higher latency and picture distortion compare to HDMI cable?
A:
Wireless transmission is a process of signal encoding and decoding,
●
therefore,signal latency and picture distortion is unavoidable.
Q: What if Android phone projection does not work?
A:
Press the switch button on ASK nano RX to switch the casting mode.
●
Q: What is the differences between the two cast Mode?
A:
TX/DLNA/AirPlay Mode
●
ASK nano TX or iOS phone can cast in this mode
Android phone can only project pictures and videos in this mode.
Miracast Mode
●
Android phone can cast in this mode
ASK nano TX and iOS phone could not cast in this mode
8
