2.3 Transmitter Installation
1. Connect the TX's HDMI port to the PC's HDMI
port.
2. The light turns from red to flashing blue when
TX is ready for projection.
3. Touch the projection key and the indicator light
turns static blue,which means the projection is
successful.
Note:If projection is unsuccessful,unplug the TX, and supply power to TX's HDMI port via
microUSB-USB cable and power adapter,then connect TX's HDMI port to the PC's HDMI port
again,touch the projection key to project.
4.
ASK nano
User Manual
10
