DEMO MANUAL DC2518A

PERFORMANCE SUMMARY

PARAMETER
VPWR Supply Input Operating Range
VDD33 Supply Input Operating Range
ADC Total Unadjusted Error
ADC Voltage Sensing Input Range
ADC Current Sensing Input Range
ADC Voltage Sensing Resolution
ADC Current Sense Resolution
DAC Resolution
DAC Full Scale Output Voltage
Temperature Sensor TUE
Voltage Supervisor Input Voltage
Range (Programmable)
Voltage Supervisor Sensing Resolution
Voltage Supervisor
Total Unadjusted Error (TUE)
2
I C Serial Clock Frequency
DEMO BOARD SYSTEM SPECIFICATIONS
NOMINAL
UNTRIMMED V
CH0 +12V ±1%
CH1 –12V ±1%
CH2 +48V ±1%
CH3 –48V ±1%
Notes:
– Keep load currents < 100mA on ±48V channels and < 250mA on ±12V channels.
– Output voltages can be margined by ±10% from nominal with the default resistor values. These values can be eas-
ily changed. See section Changing Nominal Output Voltages. Use the LTC2975 Resistor Selection Tool which is
accessed from LTpowerPlay.
2
Specifications are at T
CONDITIONS
V ≥ 1V
IN
Differential Current Sense Voltage
0V ≤ V ≤ 6V
IN_ADC
0mV < |V
IN_ADC
16mV < |V
IN_ADC
32mV < |V
IN_ADC
63.9mV < |V
IN_ADC
127.9mV < |V
IN_ADC
Buffer Gain Setting 0
Buffer Gain Setting 1
V
SENSEP[n]
0V to 3.8V Range: 4.096/1024
0V to 6V Range: 8.192/1024
2V < V < 6V, Low Resolution Mode
IN_VS
1.5V < V < 3.8V, High Resolution Mode
IN_VS
0.8V < V < 1.5V, High Resolution Mode
IN_VS
REGULATOR
PART #
OUT
LT3081
LT3090
LT8330
LT8580
= 25°C
A
| < 16mV
| < 32mV
| < 63.9mV
| < 127.9mV
|
RESISTORS THAT SET
UNTRIMMED V
OUT
R3, R4
R17, R18
R34, R35
R52
VALUE
9V to 15V
3.13V to 3.47V
±0.25%
–0.1V to 6V
–170mV to 170mV
122µV/LSB
15.6µV/LSB
31.25µV/LSB
62.5µV/LSB
125µV/LSB
250µV/LSB
10 Bits
1.38V Typ.
2.65V Typ.
±1°C
0V to 6V (Low Resolution)
0V to 3.8V (High Resolution)
4mV/LSB
8mV/LSB
±1.25 %
±1.0 %
±1.5 %
10kHz to 400kHz
RDAC MARGIN RANGE
R31, R32
R40
R58, R59
±10%
±10%
±5%
±5%
