KTM 690 ENDURO R 2021 Setup Instructions

Hide thumbs Also See for 690 ENDURO R 2021:

Advertisement

Quick Links

Download this manual
SETUP INSTRUCTIONS
2021
690 ENDURO R
Art. no. 3214395en

Advertisement

loading
Need help?

Need help?

Do you have a question about the 690 ENDURO R 2021 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KTM 690 ENDURO R 2021

Summary of Contents for KTM 690 ENDURO R 2021

  • Page 1 SETUP INSTRUCTIONS 2021 690 ENDURO R Art. no. 3214395en...
  • Page 3 KTM accepts no liability for delivery options, deviations from fig- ures and descriptions, misprints, and other errors. The models portrayed partly contain special equipment that does not belong to the regular scope of supply.

  • Page 4: Means Of Representation

    1 MEANS OF REPRESENTATION Symbols used The meaning of specific symbols is described below. Indicates an expected reaction (e.g. of a work step or a function). Indicates an unexpected reaction (e.g. of a work step or a function). Indicates a page reference (more information is provided on the specified page). Indicates information with more details or tips.
  • Page 5 To operate the vehicle, the vehicle electronics must be enabled. This process is conducted during initial setup in KTM Dealer.net. Enabling ensures that the initial setup in KTM Dealer.net is docu- mented. Enabling can be performed either temporarily, e.g. for a test ride, or permanently for vehicle handover.
  • Page 6 2 SETUP – Roll down the film at the sides. Info To avoid damaging the motorcycle during unpacking, leave the other films on the vehicle until you have fin- ished work on the vehicle. – Remove the separate enclosure and unpack it. Check that the separate enclosure is complete using the enclosed packing list.
  • Page 7 SETUP 2 – Position all controls in their exact positions on the handlebar. – Tighten screws Guideline Screw, throttle grip 3.5 Nm (2.58 lbf ft) Screw, brake assem- 5 Nm (3.7 lbf ft) – Check the throttle grip for smooth operation. –...
  • Page 8 2 SETUP – Charge the 12-V battery. ( p. 10) – Install the 12-V battery. – Plug in connector on the starter relay. S04681-10 – Remove the rear fairing. ( p. 13) – Take off the side cover. ( p. 13) –...
  • Page 9 – Mount heel protector. ( p. 17) – Refuel. ( p. 18) – Prepare the vehicle according to the specifications in KTM Dealer.net for handover to the customer. – Set the kilometers or miles.
  • Page 10 3 WORK Removing the seat Preparatory work – Open the fuel tank filler cap. ( p. 12) Main work – Pull on loop and raise the rear of the seat. – Pull the seat back and lift it off. S04383-10 Finishing work –...
  • Page 11 WORK 3 Main work – Remove screws – Push the retaining bracket toward the rear and remove it. – Take off positive terminal cover – Disconnect negative cable from the 12-V battery. – Disconnect positive cable from the 12-V battery. –...
  • Page 12 3 WORK Charging the 12-V battery Warning Risk of injury Battery acid and battery gases cause serious chemical burns. – Keep 12 V batteries out of the reach of children. – Wear suitable protective clothing and safety glasses. – Avoid contact with battery acid and battery gases. –...
  • Page 13 WORK 3 Info Follow the charger's instructions exactly. – Disconnect the battery charger after charging the 12-V battery. Guideline The charging current, charging voltage, and charging time must not be exceeded. Recharge the 12-V battery 3 months regularly when the motorcy- cle is not being used Finishing work –...
  • Page 14 3 WORK Opening the fuel tank filler cap Danger Fire hazard Fuel is highly flammable. The fuel in the fuel tank expands when warm and can escape if overfilled. – Do not fuel the vehicle in the vicinity of open flames or lit cigarettes. –...
  • Page 15 WORK 3 3.10 Removing the rear fairing Preparatory work – Open the fuel tank filler cap. ( p. 12) – Remove the seat. ( p. 8) Main work – Remove screws with the bushings. – Remove screws and take off the grab handle. D07483-10 –...
  • Page 16 3 WORK 3.12 Removing the rear left side cover Preparatory work – Open the fuel tank filler cap. ( p. 12) – Remove the seat. ( p. 8) – Remove the rear fairing. ( p. 13) – Take off the side cover. ( p.
  • Page 17 WORK 3 3.14 Installing the rear left side cover Main work – Mount the trim. The trim engages in the bracket. – Mount and tighten screw – Mount and tighten screw Guideline Remaining screws, 5 Nm (3.7 lbf ft) chassis R05345-10 Finishing work –...
  • Page 18 3 WORK 3.16 Mounting side cover Main work – Position the left side cover using holding lugs on bushings and push towards the rear and, in the rear section, down- ward. – Press the left side cover into the rubber bushing in area –...
  • Page 19 WORK 3 – Mount and tighten screw Guideline Screw, tail section M6x21 6 Nm (4.4 lbf ft) D07484-11 – Mount screws with the bushings and tighten. Guideline Screw, trim M5x20 2 Nm (1.5 lbf ft) – Position the grab handle. –...
  • Page 20 3 WORK Warning Voiding of the government approval for road use and the insurance coverage If the heel protector is fitted instead of the footrest bracket, the vehicle no longer conforms to the homologation. The vehicle is homologated in the factory as 2-seater. –...
  • Page 21 WORK 3 Note Material damage Inadequate fuel quality causes the fuel filter to quickly become clogged. In some countries and regions, the available fuel quality and cleanliness may not be sufficient. This will result in problems with the fuel system. – Refuel only with clean fuel that meets the specified standards.
  • Page 22 3 WORK – Press the ‑ button to set the hour. – Confirm the selection using the + button. The setting is adopted and the combination instrument changes to the next menu item. – Press the ‑ button to set the minute. –...

  • Page 23: Technical Data

    TECHNICAL DATA 4 Chassis tightening torques Screw, chain guard EJOT 2 Nm (1.5 lbf ft) Screw, combination instrument EJOT 1 Nm (0.7 lbf ft) Screw, side cover on spoiler EJOT 1 Nm (0.7 lbf ft) Screw, side stand sensor EJOT 2 Nm (1.5 lbf ft) Fitting, side stand sensor 2 Nm (1.5 lbf ft)
  • Page 24 4 TECHNICAL DATA Screw, front brake disc 14 Nm (10.3 lbf ft) Loctite ® 243™ Screw, ignition lock 10 Nm (7.4 lbf ft) Loctite ® 243™ Screw, license plate holder, bot- 8 Nm (5.9 lbf ft) Screw, license plate holder, top 8 Nm (5.9 lbf ft) Screw, magnetic holder on side 6 Nm (4.4 lbf ft)
  • Page 25 TECHNICAL DATA 4 Screw, rear footrest bracket M8x16 25 Nm (18.4 lbf ft) Screw, side stand bracket 25 Nm (18.4 lbf ft) Loctite ® 243™ Screw, spring holder plate on side 25 Nm (18.4 lbf ft) Loctite ® 243™ stand bracket Screw, steering stem 20 Nm (14.8 lbf ft) Screw, top triple clamp...
  • Page 26 5 SUBSTANCES Super unleaded (ROZ 95) Standard/classification – DIN EN 228 (ROZ 95) Guideline – Only use super unleaded fuel that matches or is equivalent to the specified standard. – Fuel with an ethanol content of up to 10% (E10 fuel) is safe to use. Info Do not use fuel containing methanol (e.g., M15, M85, M100) or more than 10% ethanol (e.g., E15, E25, E85, E100).
  • Page 27 *3214395en* 3214395en 12/2020 KTM Sportmotorcycle GmbH 5230 Mattighofen/Austria Photo: Mitterbauer/KISKA/KTM http://www.ktm.com...
