American Dynamics AD1305 Specifications

FEATURES
•
Corner-mounted
•
Heavy-gauge steel
construction
•
Tamper resistant
•
Distortion-free Lexan ®
viewing window
•
203 mm (8 in) maximum
camera length
•
Perfect for use in
elevators
•
Easy to install
AD1305
CORNER MOUNT HOUSING
The AD1305 is an attractive, tamper resistant
corner-mounted housing. Primarily designed for
use in elevators, this compact unit is also perfect
for stairwells, entrances, hallways, small offices,
jail holding rooms, etc.
Construction is of heavy gauge steel throughout
with a 6.35 mm (0.25 in) thick replaceable Lexan
window. All mounting bolts and cable entries
are protected. The housing is secured from
unauthorized entries by the use of two tamper
resistant security screws.
The housing permits maximum viewing
coverage in confined areas for most low-profile
cameras using wide angle lenses. The exposed
surface of the unit has a beige baked enamel
finish.
www.americandynamics.net
