- Page 1 User Manual PCE-DPM 3 Dew Point Thermometer User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 6 October 2020 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
Measurement window ................4 Main menu and symbols ..............5 Functions ......................... 5 Recording function ......................6 Display settings ........................ 7 Environmental parameters/ measurement settings ............8 Further settings ........................ 9 Warranty ....................10 Disposal ....................10 © PCE Instruments... -
Page 3: Safety Notes
We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. © PCE Instruments... -
Page 4: Specifications
Ø5.9 cm LCD Power supply - battery 3.7 V, 3000 mAh Power supply – mains adaptor Primary: 100 ... 240 VAC, 0.25 A Secondary: 5 VDC, 1 A Interface / mains connection via micro USB Weight approx. 610 g © PCE Instruments... -
Page 5: Device Description
On/off switch, hold key Arrow left key Interface 1 (no function) Micro USB interface Enter key Arrow up key Arrow right key Arrow down key Interface 2 for connecting the probe G1/2'' connection thread Handle of the probe © PCE Instruments... -
Page 6: Keyboard Description
In addition, you can hold the currently displayed values with the hold key and save them with the enter key (4) according to your preference. To exit hold mode, press the back key (1). Then press the back key (1) to view the saved values in the measurement window. © PCE Instruments... -
Page 7: Main Menu And Symbols
Use the arrow keys to select On/Off and press the enter key to activate the alarm. If the measured value exceeds the high limit value or falls below the low limit value, the bell symbol appears at the top and an acoustic signal can be heard. Press the enter key again to deactivate the alarm. © PCE Instruments... -
Page 8: Recording Function
The recorded data is saved in CSV format and can therefore be easily opened on a terminal device with Excel. Attention: Make sure to save the data to your computer. Display data: By means of the menu item "View DataFile", you can open and display the CSV data file via the device. © PCE Instruments... -
Page 9: Display Settings
Attention: You can select a maximum of two parameters. If you want to select a new parameter, you must first remove the other parameter. The parameters can also be changed with the on/off key or the hold key. (For T d/f - dew point, for example, you can switch between Fahrenheit and Celsius). © PCE Instruments... -
Page 10: Environmental Parameters/ Measurement Settings
Setting the probe pressure Here you can set the pressure value P of the measured gas and the corresponding unit bara, barg, psia or psig. Change the value and select the unit by pressing the arrow up or down keys. © PCE Instruments... -
Page 11: Further Settings
3 Brightness: Press the enter key to change the value. 10 different brightness levels can be selected. Set the time and date, increase or decrease the number with the up or down keys and confirm your entry with the enter key. © PCE Instruments... -
Page 12: Warranty
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments... - Page 13 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
