Task Force Tips ULTIMATIC Manual page 12

MODEL
HM-VPGI
SHOWN
MID-MATIC 55 PSI (3 BAR) VERSION
Automatic Pressure Control Flow Range:
70-180 gpm @ 55 psi
260-680 l/min @ 3 bar
MODEL
H-VPGI
SHOWN
HANDLINE 100 PSI (7 BAR) VERSION
Automatic Pressure Control Flow Range:
95-300 gpm @ 100 psi
360-1150 l/min @ 7 bar
©Copyright Task Force Tips, Inc. 2002 - 2016
55 psi/ 3 bar Version
Mid-Matic 55 psi (3 bar) Version
Curve A B C
70 125 150 180 (l/min) 265 473 568 681
Flow (gpm)
38 47 52
Pressure (psi)
22 43 55
Reaction (lbs)
100 psi/ 7 bar Version
Handline, 100 psi (7 bar) Version
Curve A B C
95 125 200 300 (l/min) 360 473 757 1136
Flow (gpm)
91 100 100 126
Pressure (psi)
46 63 101 170
Reaction (lbs)
12
D A B C D
64 2.6 3.2 3.6 4.4
(bar)
73 10 20 25 33
(kgf)
D A B C D
6.3 6.9 6.9 8.7
(bar)
21 29 46 77
(kgf)
