American Dynamics AD168 Installation Instructions

Central Processing Module
Installation Instructions

About This Component

The Central Processing Module (CPM) controls all of the
switching functions of the AD168 bay. Input/output devices
used with the system (such as PCs, system keyboards, alarms,
auxiliaries, and printers) connect to the CPM.
NOTES:
Only one CPM is required for both single and dual
bay applications
The CPM resides in slot Q (shown by the screening
on the front and rear bay surfaces).
The front and rear sections of the CPM are identified
with a PURPLE color code dot.
Avoid static discharge by using proper grounding
methods before handling circuit cards.
Front View
R
Q P O
Rear View
A B C D E
Figure 1 - AD168 Slot Designation (Front & Rear)
Quick Reference Card, CPM, AD168
N M L K J I H
F G H I J K
AD168 SYSTEM COMPONENT(S)
FRONT SIDE (SEE REAR FOR FURTHER INSTRUCTIONS)

Receiving the Component

At the time that the AD168 system component is delivered,
verify that the shipment is complete.
Inspect the box and packing to ensure that there has been no
damage during shipment. If damage is found, notify the
shipping agency and contact your sales representative.
Unpack the component in a secure location and lay out the
individual parts in an orderly fashion.
This kit includes the CPM Replacement Instructions (this
document), and either of two CPM components:
AD168CPM-PC (CPM front module)
●
AD168CPM-BP (CPM rear panel)

Required Tools and Equipment

Small and medium Phillips head screwdriver
PURPLE Color Code Dot
G F E D C B
L M N O P Q
American Dynamics
Technical Support Center
1-800-442-2225 (USA)
(914) 624-7640
A
R
Figure 2 - CPM Rear Panel
8000-0949-01, Revision B
