3M™ E-A-Rfit™ Dual-Ear Validation System User Instruction
3M™ E-A-Rfit™ Dual-Ear Validation System User Instructions
Warnings and Cautions
WARNING
To avoid the risk of electric shock, which if not avoided could result in serious injury or death:
WARNING
•
Do not immerse the 3M™ E-A-Rfit™ Dual-Ear Validation System in any liquid.
•
Use indoors only.
•
Disconnect power cord before cleaning.
•
Clean the exterior surface of the speaker with a clean anti-static cloth.
•
Do not attempt to clean the interior components.
•
There are no serviceable parts.
•
The 3M™ E-A-Rfit™ Dual-Ear Validation System must be returned to the manufacturer for repair.
•
To avoid possible environmental contamination, dispose of the 3M™ E-A-Rfit™ Dual-Ear Validation System according
to applicable governmental regulations.
•
Substitution of components may impair the accuracy of the instrument. Repairs should be performed by authorized
service personnel only.
•
Read the User Guide before operation.
Introduction
This system is comprised of hardware and software that enables the operator to test and record the personal attenuation
rating (PAR) of many 3M hearing protection products. (See Appendix B, "Model, Parts and Accessories" for details.) Software
versions 5.9.1 and higher are compliant with ANSI/ASA S12.71-2018 American National Standard Performance Criteria for
Systems that Estimate the Attenuation of Passive Hearing Protectors for Individual Users.
Getting Started
This product contains the components illustrated below. Please follow the illustrated quick set-up guide in the lid of the case
to assemble your hardware.
User Instructions
