Headphone Mix Menu

The headphone mix menu assigns what is routed to the 12 headphone presets.

Creating headphone presets

From the headphone mix menu select a preset and enable
that preset. Enabling the preset allows that preset to be
shown when cycling through the headphone selections. If a
preset is not enabled that preset will not be shown when
cycling through the headphone selections.

Naming a headphone preset

Each preset can be optionally named for easy
identification. To name the preset click on the preset
number – this will open a text editor. In the editor input
the name and press the green

Assigning audio to a headphone preset

For each preset choose the card tracks, output buses,
return inputs or ZaxNet return. Clicking on the selection will
cycle through and assign it to L (left ear), R (right ear), LR
(both left and right ear) for that preset. Multiple items can
be routed simultaneously.

Inverting phase

Select the key to toggle between normal and inverted
PHASE
phase. When a source is select its phase is set to follow the
phase key setting. So if the phase is set to normal all sources
selected will have normal phase and if the phase is set to
inverted all sources selected will have its phase inverted.
When the phase is inverted on a white line will be displayed
across top of the source.
key when done.
ENT
25
