Adjustments
LCD/Display Mount Load Ranges
Gas Spring in LCD/Display Post
T (For Tablet)
35N
50N
60N
75N
A (For ALL-IN-ONE)
L (For LCD/Display with small form factor CPU) 5.5-15.5 lbs. (2.5-7kg)
Cart Load Ranges
Spring Type
165N
210N
255N
NOTE: The combined total weight of all peripherals and accessories on the cart should fall within load range of
selected spring type.
16
Amico Accessories Inc.
Load Range
5.5-8 lbs. (2.5-3.6 kg)
7.5-10 lbs. (3.4-4.5 kg)
13-15.5 lbs. (5.8-7 kg)
15.5-18 lbs. (5.8-7 kg)
18 - 22 lbs. (8.1 - 19 kg)
15.5-22 lbs. (5.8-19 kg)
Load Range
3.5 lbs - 13.4 lbs (1.59 kg - 6.1 kg)
17 lbs - 22.5 lbs (10.21 kg - 17.71 kg)
13.5 lbs - 27 lbs (6.12 kg - 12.25 kg)
