- Page 1 04GREEN0606SD-V5 ASSEMBLY INSTRUCTIONS 6 X 6 GREENHOUSE...
- Page 2 04GREEN0606SD-V5 Please retain product label and instructions for future reference Overall Dimensions: Width = 1215mm Depth = 1887mm Height = 2066mm Base Dimensions: Width =1191mm Depth = 1862mm Before assembly please make sure you have a suitable base ready to erect your...
- Page 3 Please retain product label and instructions for future reference Nail Bag 30mm Screw x 33 16mm Screws x 6 40mm Screw x 8 20mm Screw x 6 50mm Screw x 52 70mm Screw x 8 30mm Black Screw x 18 Strip 542mm x2 S1244-542mm Strip 1576mm x4...
- Page 4 Please retain product label and instructions for future reference Step 1 Step 3 Lay the Base Frames down as shown in Attatch the window strips using 3x30mm the diagram. Ensure the base is square screws as per the diagram. Ensure the and layed on level ground, x the base framing does not protude the width of framing (No.
- Page 5 Please retain product label and instructions for future reference Step 4 Step 6 Fix the corners of the 2 of the Window Fix the Door Sides x2 (No. 1) between the Sides (No. 2) together with 3x50mm window panels using 6x50mm screws in screws as shown in the diagram.
- Page 6 Please retain product label and instructions for future reference Step 8 Step 10 Fix the Door Gable tops (No. 3) & Fix the shorter Door strip (No. 16) to the Plain Gable top (No. 4) to the top of the door opening with 3x30mm panels using 4x50mm screws per screws.
- Page 7 Please retain product label and instructions for future reference Step 12 Step 13 Fix the strips (No. 29, 30, 31) onto the Attach the strip (No.32) onto the window window frame using 3x30mm screws per panel with 4x30mm screws. Drop the strip.
- Page 8 Please retain product label and instructions for future reference Please retain product label and instructions for future reference Step 12 Fix the Casement stay (No. 18) to the Step 14 opening window then align the xings onto the window panel frame. Ensure the Attach the Roof Support bar (No.
- Page 9 Please retain product label and instructions for future reference Step 16 Step 18 Fit the Fascia x4 (No. 9) and the nial’s Fix the corner trims (No.23) in postion (No. 20)to the building using 14x30mm using 4x30mm screws screws as shown in the diagram. 16x30mm Screws 14x30mm Screws 30mm...
- Page 10 Please retain product label and instructions for future reference Step 18 It is ESSENTIAL to seal around all window framing with silicone sealant (not included) to minimize water ingress. *Please note: This image is for illustrative purpose and may di er from your product (in regards to the number of windows) however the principle is the same.
