Hillsdale Furniture Hutchinson 104066 Quick Start Manual

Examine all packaging material for small parts that may have come loose during shipment. Periodic checks are recommended to insure that all components are
in proper posi�on, �ght and free from damage. Keep this assembly instruc�on for future reference. Adult assembly is required. The product of Hillsdale Furniture,
LLC is designed for residen�al use only. Customer Service Phone Number: 502-562-0000
CODE QTY
1 8 ¼" * 15mm Sunk Bolts
2 6 ¼" * 15mm Allen Bolts
3 2 ¼" * 22mm Allen Bolts
4 8 Ø6.5 Spring Washers
5 8 Ø6.5 * δ1.5 Flat Washers
6 1 Allen Wrench
WARNING
• Do not let any sharp objects touch or rub the surface of
the product.
• When assembling, do not let children play around the
working area.
• Please confirm all parts are correct before star�ng the
assembly process.
• Do not �ghten all bolts and screws completely un�l the
en�re unit has been assembled and set up.
• Be careful if using power tools as they can over �ghten
screws and strip threads.
CARE & MAINTENANCE: The touch of a so� cloth is all the maintenance the finish will ever need. Please do not use harsh or abrasive cleaners for polishing, as they may
cause damage to the finish. Periodic checks are recommended to make sure that all hardware is securely �ghtened.
Hutchinson Swivel Stool
Model #104066-113273 Counter Stool
Model #104066-113272 Barstool
HARDWARE CODE QTY COMPONENTS
A 1 Seat
C 1 Back
A
B
B
D
Date: 05-19-2017
CODE QTY COMPONENTS
B 4 Legs
D 1 Support Ring
C
B
B
Page 1 of 2
