Upper Roller Cams

The Upper Roller Cams compress the Upper Punches to make tablets.
Watch a video to see what a worn Upper Roller Cam looks like at
com/rtp-9-inspecting-roller-cams
Tools and Materials Needed
• Set of metric wrenches
• Set of metric Allen keys with ball ends
• Crosshead screwdriver
• New Upper Roller Cams
• Disposable latex/rubber gloves (for food grade products and to protect hands from grease)
• Hairnet and/or beard net (food grade products only)
• Sterile shoe covers (food grade products only)
WARNING: To prevent any potential personal injury, ALWAYS unplug the RTP
41
Instructions
Note: Wear latex/rubber gloves (and appropriate food grade attire if applicable) during this process.
Remove the Upper Roller Cams
1. Lift up the Hoppers and set aside.
2. Loosen by hand the two screws on both of the Hoppers' holders and remove them.
3. Loosen the screws on the top covering of the machine.
4. Lift up the top covering from the machine and set aside.
43
from the electrical outlet when replacing parts.
®
3
