Installation

Tools and Materials Needed

Before you install and operate the RTP 41
hand for general operation and maintenance:
• Forklift that is rated to lift at least 2,000 kg
• Lifting straps that are rated for at least 2,000 kg
• Level
• Crowbar
• Hammer
• Rubber mallet
• Metric wrench set
• Crosshead screwdriver
• Flathead screwdriver
• Set of metric Allen keys with ball ends
• Long wire pipe cleaner
• Cleaner (e.g. Member's Mark Commercial Lemon Disinfectant)
• Sanitizer (e.g. Member's Mark Commercial Sanitizer)
• Lubricant (NSF approved type for food grade products)
• Grease gun
• Toothbrush
• Cleaning brush set
• Plastic sheet or something similar to cover machine
• Safety goggles
• Hairnet and/or beard net (food grade products only)
• Sterile shoe covers (food grade products only)

The Appropriate Workstation for the Machine

The floor on which the machine is to be placed must support the RTP 41
(approximately 3,696 lbs) weight. The static floor loading limit is 2.43 kN/m2.
The machine's motor requires a three-phase power supply of 220 V/440 V. Ensure to position the
machine near an appropriate electrical plug
Environmental Conditions
It is important that the environment in which you operate and store the RTP 41
appropriate temperature and relative humidity levels. These two environmental factors can
potentially cause the machine to rust and/or cause the tablets to have a lower quality. The table
below shows the acceptable temperature and relative humidity levels:
Machine
RTP 41 ®
, it is best to have the following tools and materials on
®
Temperature
°C °F
0-40 32-104
® 's 1676 kg
® has the
Humidity
20-80% RH
11
