LFA RTP 41 Standard User Manual page 22

3. Loosen both of the Fill Trays' Thumb Bolts with an Allen key.
4. Loosen both Fill Trays Scrapers and Take-Off Blades' screws with a crosshead screwdriver.
3
5. Run a feeler gauge between the Fill Trays and the Turret to determine the adjustment.
5.1 Note: Start at 0.15 mm and raise appropriately if there is no powder waste/damage to
the Fill Trays. If there is waste, lower it.
6. Adjust the Fill Trays Height Adjusters accordingly and tighten their bolts.
7. Resecure the Fill Trays Scrapers and Take-Off Blades' screws with a crosshead screwdriver.
7.1 Note: Ensure the Take-Off Blades' distance from the Die Table is 1/3 of the tablet's height.
8. Tighten the Fill Trays' Thumb Bolts with an Allen key.
9. Reinsert the Hoppers into the top of the machine.
4
4
22
