Product Overview
Figure 2: Detailed Architecture of a CMICR-4PC Switch
1
2
3
4

Hardware Features

This section describes the different hardware features supported on Cisco Catalyst Micro Series Switches.

PoE and PoE+ Ports

The PoE/PoE+ ports on the switch provide PoE+ support for devices compliant with IEEE 802.3af and IEEE
802.3at and also provide PoE support for end points such as access points, IP camera or surveillance systems,
Cisco IP Phones and so on. The PoE switch ports are Power Source equipment (PSE) capable and source
Four 1 G PoE+ downlink ports
Mode button
1 G Copper uplink port
Power adapter slot
Cisco Catalyst Micro Series Switch Hardware Installation Guide
5 1 G SFP uplink port
6 Micro USB console port
7 microSD memory card slot
- -
Hardware Features
3
