QUICK START GUIDE
Boom Microphone Type
Status LED
Pin-hole
Reset Button
DC Power
Charging &
Firmware
Upgrade Port
Universal Microphone Type
Status LED
Pin-hole
Reset Button
DC Power
Charging &
Firmware
Upgrade Port
(–) Button
(+) Button
Microphone
Speakers
(+) Button
(–) Button
Microphone Connector
Speakers
ENGLISH
1.0.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3S PLUS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sena 3S PLUS

Summary of Contents for Sena 3S PLUS

  • Page 1 QUICK START GUIDE ENGLISH Boom Microphone Type Status LED (–) Button Pin-hole Reset Button (+) Button DC Power Microphone Charging & Firmware Speakers Upgrade Port Universal Microphone Type Status LED (+) Button Pin-hole Reset Button (–) Button DC Power Microphone Connector Charging &...
  • Page 2 RIDE CONNECTED Bluetooth 4.1 advanced signal processing enables the ® 3S PLUS headset for scooter or motorcycle to deliver incoming and outgoing audio for music, phone calls, GPS directions, and talk over the intercom with your buddies. Bluetooth ® Two-Way Intercom Intercom up to 400 m (0.2 mi)*...

  • Page 3: Getting Started

    Visit to see how to update your product. 3. Users can follow Sena on Facebook, YouTube, Twitter and Instagram to receive the most up to date information on products, helpful tips and all other announcements regarding Sena products.

  • Page 4: How To Use This Guide

    GETTING STARTED How to Use This Guide The legend and callouts are here to help you read the illustrations. New technology can be confusing, but we’ve created a simple way to perform actions using illustrations. HOLD Function Button(s) to Tap or Hold Icon Legend Press and Hold button the specified...

  • Page 5: Installation

    QUICK START GUIDE Installation Boom Microphone Type QUICK START GUIDE 3S PLUS...
  • Page 6 QUICK START GUIDE Universal Microphone Type 4 - 1 Wired Microphone Wired Microphone 4 - 2 Wired Boom Microphone Wired Boom Microphone...

  • Page 7: Sena Device Manager

    - Android: Google Play Store > Sena Utility - iOS: App Store > Sena Utility Sena Device Manager The Sena Device Manager allows you to upgrade firmware and configure settings directly from your PC. Download the Sena Device Manager from sena.com.

  • Page 8: Basic Operations

    QUICK START GUIDE Basic Operations Power On Power Off HOLD Volume Up Volume Down Checking the Battery Level Instruction is for when powering the headset on. Visual Method HOLD...

  • Page 9: Phone Pairing

    • Rebooting after executing Factory Reset; or • Rebooting after executing Delete All Pairings. HOLD Select 3S PLUS Bluetooth Device A Sena 3S PLUS v1.0 Device B STATUS ..NUMBER Note: • The phone pairing mode lasts for 3 minutes.
  • Page 10 Pairing When the Headset Is Turned Off While the headset is off, press and hold the (+) Button and (-) Button for 5 seconds. HOLD Select 3S PLUS Bluetooth Device A Sena 3S PLUS v1.0 Device B STATUS ..NUMBER...
  • Page 11 QUICK START GUIDE Pairing When the Headset Is Turned On While the headset is on, press and hold the (+) Button for 5 seconds. HOLD Select 3S PLUS Bluetooth Device A Sena 3S PLUS v1.0 Device B STATUS ..NUMBER...

  • Page 12: Mobile Phone

    QUICK START GUIDE Mobile Phone Answer a Call End a Call HOLD Redial Last Number Reject a call HOLD HOLD Make a Call with the Voice Dialer HOLD Music Controls Play/Pause HOLD Next Track Previous Track HOLD HOLD...

  • Page 13: Bluetooth Intercom

    QUICK START GUIDE Bluetooth Intercom The 3S PLUS can be paired with another headset for Bluetooth intercom conversation. Intercom Pairing INTERCOM FRIEND Pairing with Intercom B HOLD “Intercom Pairing” Flashing blue LED confirms intercoms are paired. STATUS Start/End Conversation with Intercom Friend...

  • Page 14: Configuration Menu

    QUICK START GUIDE Configuration Menu Access the Configuration Menu Navigate Between Menu Options HOLD Execute Menu Options Troubleshooting Factory Reset Fault Reset HOLD Press the Pin-hole Reset Button for a second with light pressure. The headset will automatically be turned off and a fault reset will occur.

  • Page 15: Quick Reference

    QUICK REFERENCE TYPE OPERATION BUTTON COMMANDS HOLD Power on Power off Basic Operations Volume up/down Answer a call HOLD End a call HOLD Mobile Reject a call Phone HOLD Voice dial QUICK REFERENCE 3S PLUS...
  • Page 16 QUICK REFERENCE TYPE OPERATION BUTTON COMMANDS HOLD Play/Pause music HOLD Next track Music HOLD Previous track HOLD Intercom pairing Intercom HOLD Start/End intercom 1.0.0_EN_August2020...
