Xerox Versant 180 Press Quick Reference

®
Xerox Versant
Quick Reference for Printing Extra Large Sheets (XLS)
on the EX 180 and EX-i 180 Print Servers,
Powered by Fiery
You can print on long sheets up to 330 x 660 mm (26") using the standard
XLS feature. This lets you create Banners, Advertisements, A4 Landscape
Book Covers, Calendars, and Long Sheet Prints. XLS specifications include:
•
Print Speed: Up to 9 ppm, Simplex Mode only
•
Paper Weights: Uncoated - 52-220 gsm; Coated - 72-220 gsm
•
Maximum Paper Size: 330 x 660 mm
•
Maximum Printable Area: 323 x 654 mm
To use this feature, sheets must be fed from Tray 5 and sent to an output
destination of the Offset Catch Tray or a Top Tray of the HCF or Finisher.
®
Also, a GBC AdvancedPunch™ Pro cannot be configured with the system.
To print Extra Long Sheets, follow these steps:
1. Load the paper into the Bypass Tray (Tray 5) located on top
of the 2-Tray OHCF, or directly on the side of the press when no
optional feeders are configured with the system.
a) Open the Tray 5 paper guides wider than the paper to be able to insert the paper.
b) Hold the center of the paper guides and close them so that they touch the edges of the stack.
2. Program the paper at the press Control Panel.
a) After you load the paper, the Paper Tray settings window
opens on the Control Panel.
On this window, touch Change Settings.
b) Select 1. Paper Size.
c) Touch Custom Size.
d) Enter the length (x) and height (y) of the paper you loaded.
For example: 26" x 13"
e) Touch Save.
f) Touch Save.
®
