Alienware MJ-12 m7700a User Manual

Alienware MJ-12 m7700a User Manual

Alienware mj-12 m7700a: user guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MJ-12 m7700a and is the answer not in the manual?

Questions and answers

Related Manuals for Alienware MJ-12 m7700a

Summary of Contents for Alienware MJ-12 m7700a

  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Infor- mation contained herein is for reference only and does not constitute a commitment on the part of the man- ufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 4: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 6: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be dam- aged.
  • Page 7 Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 8: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a Power Safety Warning Before you undertake •...

  • Page 9: Battery Precautions

    Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the com- puter. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way.

  • Page 10: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 11: Travel Considerations

    Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 12 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshoot- ing, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.

  • Page 13: Developing Good Work Habits

    Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
  • Page 14 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

  • Page 15: Table Of Contents

    Notice ...I FCC Statement ...II Instructions for Care and Operation ... IV Power Safety ... VI Battery Precautions ...VII Cleaning ... VIII Servicing ... VIII Travel Considerations ... IX Quick Start Guide Overview ...1-1 Advanced Users ...1-2 Beginners and Not-So-Advanced Users ...1-2 Warning Boxes ...1-2 Not Included ...1-2 System Software ...1-3...
  • Page 16 Preface Adding a Printer ...2-14 USB Printer ...2-14 Install Instructions: ...2-14 Parallel Printer ...2-14 Power Management Overview ...3-1 Advanced Configuration and Power Interface ...3-1 The Power Sources ...3-2 AC/DC Adapter ...3-2 Battery ...3-2 Turning on the Computer ...3-3 Power Schemes ...3-4 System Power Options ...3-6 Hibernate Mode vs.
  • Page 17 WLAN & Bluetooth Combo ...4-13 TV Tuner ...4-13 PC Camera ...4-13 BIOS Utilities Overview ...5-1 The Power-On Self Test (POST) ...5-2 Failing the POST ...5-3 Fatal Errors ...5-3 Non-Fatal Errors ...5-3 The Setup Program ...5-4 Entering Setup ...5-4 Setup Screens ...5-5 Main Menu ...5-6 System Time &...
  • Page 18 Preface Digital TV Broadcast Signal ...7-15 PC Camera ...7-16 PC Camera Driver Installation ...7-16 PC Camera Audio Setup ...7-17 EMAMCAP ...7-19 RAID Setup ...7-21 RAID Mode Setup ...7-22 Troubleshooting Overview ...8-1 Basic Hints and Tips ...8-2 Backup and General Maintenance ...8-3 Viruses ...8-4 Upgrading and Adding New Hardware/Software ...8-5 Problems &...
  • Page 19 Preface Specifications Processor Types ... C-2 Core Logic ... C-2 LCD ... C-2 Security ... C-2 Memory ... C-3 BIOS ... C-3 Video Card Options ... C-3 Storage Options ... C-4 Audio ... C-4 Keyboard & Pointing Device ... C-4 PCMCIA ...
  • Page 20 Preface XVIII...

  • Page 21: Chapter 1: Quick Start Guide

    Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...

  • Page 22: Advanced Users

    Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “Drivers & Utilities” on page 4 - on page 6 - 1 in the User’s Manual.

  • Page 23: System Software

    System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find this manual refers to the following oper- ating systems: •...

  • Page 24: System Startup

    Quick Start Guide System Startup LCD Latches LED Power & Communication Indicators Figure 1 - 1 - Top Panel with LCD Closed Please note that you should always shut your computer down by choosing the Shut Down/Turn Off Computer command from the Start menu in Windows.

  • Page 25: System Map: Top View With Lcd Panel Open

    System Map: Top View with LCD Panel Open Wireless Device Operation Aboard Aircraft The use of any portable electronic transmission devices aboard aircraft usually prohibited. Make sure the mod- ule(s) are OFF if you are using computer aboard aircraft. The key combination Fn + F11 toggles power to the WLAN module, Fn + F12 to the Bluetooth...

  • Page 26: Led Indicators

    Quick Start Guide LED Indicators The two sets of LED indicators (LED Status Indica- tors and LED Power & Communication Indicators) on the computer display helpful information about the current status of the computer. Table 1 - 1 - LED Status Indicators Icon Color Green...

  • Page 27: Ap-Key Buttons

    AP-Key Buttons These buttons access the internet, e-mail or a user-de- fined application with one quick button press. Make sure you install the driver to enable the AP-Key Button functions (refer to “What to Install” on page 4 - Table 1 - 3 - AP-Key Buttons AP-Key Function Activate the Default E-mail Program...
  • Page 28 Quick Start Guide Table 1 - 4 - Function Keys Keys Description Function Key Fn + F3 Mute Toggle Fn + F4 Sleep Toggle Fn + F5 Decrease Audio Volume Fn + F6 Increase Audio Volume Fn + F7 Display Toggle Fn + F8 Decrease LCD Brightness Fn + F9...

  • Page 29: System Map: Front & Rear Views

    System Map: Front & Rear Views Audio "DJ" Player The built-in standalone audio CD player gives you direct hardware control for audio CDs (MP3 compatible) when the computer is shut down, but has a working power source. To prevent your computer from overheating make sure nothing blocks the vent(s)/fan intake(s) while the computer is in use.

  • Page 30: System Map: Left View

    Quick Start Guide System Map: Left View Figure 1 - 5 Left View S-Video-Out Jack 4 * USB 2.0 Ports 2 * Mini-IEEE 1394a Port Line-In Jack S/PDIF-Out Jack Microphone-In Jack Headphone-Out Jack 10-in-1 Card Reader PC Card Slot 10. Infrared Transceiver (see page Mini-IEEE 1394a Both Mini-IEEE 1394a...

  • Page 31: System Map: Right View

    System Map: Right View Changing DVD Regional Codes Go to the Control Panel and double-click System > Hardware (tab), click Device Manager, then click the + next to DVD/CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties di- alogue box, and select the DVD Region (tab) to bring up the control panel to allow you to adjust the regional code (see...

  • Page 32: System Map: Bottom View

    Quick Start Guide System Map: Bottom View Figure 1 - 7 - Bottom View Battery Vent/Fan Intake Memory (RAM) Cover Hard Disk Cover Sub Woofer Video Card Cover CPU Cover Always completely discharge, then fully charge, a new battery before using it. Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.

  • Page 33: Windows Xp Start Menu & Control Panel

    Quick Start Guide Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.

  • Page 34: Video Features

    Quick Start Guide Video Features This computer features different PCI Express video card options (see You can switch display devices, and configure display options, from the Display Properties control panel in Windows as long as the appropriate video driver is installed. For more detailed video information Video Driver Controls”...
  • Page 35 Quick Start Guide Figure 1 - 9 - Display Properties Desktop NVIDIA Display Mode Description Single One of the connected displays is used as the display device Clone Both connected displays output the same view Dualview Both connected displays are treated as separate devices, and act as a virtual desktop Table 1 - 5 - Display Options Video Features 1 - 15...

  • Page 36: Power Management Features

    Quick Start Guide Power Management Features The Power Options control panel in Windows (see page 13) allows you to configure power management features for your computer. You may conserve power through individual components such as the monitor or hard disk (by means of Power Schemes), or you may use either Stand by or Hibernate mode to conserve power throughout the system (enable Hibernate support from the control panel as pictured in Figure 1 - 10).

  • Page 37: Storage Devices, Mouse, Audio & Printer

    Storage Devices, Mouse, Audio & Printer Chapter 2: Storage Devices, Mouse, Audio & Printer Overview Read this chapter to learn more about the following main features and compo- nents of the computer: • Hard Disk Drive • Optical Device • 10-in-1 Card Reader •...

  • Page 38: Hard Disk Drive

    Storage Devices, Mouse, Audio & Printer Power Safety Before attempting to access any of the inter- components your computer please ensure that the ma- chine is not connected to the AC power, and that the machine is turned off. Also ensure that all peripheral ca- bles, including phone lines, are disconnected...

  • Page 39: Optical Device

    Optical Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The ac- tual device will depend on the model you purchased (see on page C - 4). The optical device is usually labeled “Drive D:” and may be used as a boot device if properly set in the BIOS 14).

  • Page 40: Handling Cds Or Dvds

    Storage Devices, Mouse, Audio & Printer CD Emergency Eject If you need to manually eject a CD (e.g. due to an unexpected power interruption) you may push the end of a straightened paper clip into emergency eject hole. However please do NOT use a sharpened pencil or similar object that may break...

  • Page 41: Dvd Regional Codes

    DVD Regional Codes To change the DVD regional codes see page 1 - DVD Regional Coding Region Geographical Location USA, Canada Western Europe, Japan, South Africa, Middle East & Egypt South-East Asia, Taiwan, South Korea, The Philippines, Indonesia, Hong Kong South &...

  • Page 42: 10-In-1 Card Reader

    Storage Devices, Mouse, Audio & Printer Operating System Installation Warning If you are installing an operating system (e.g. Windows XP), have a 10-in-1 Card Reader present, make sure to set the Card Reader option in the BIOS to “Disabled”. “Card Reader: (Advanced Menu >...

  • Page 43: Pc Card Slot

    PC Card Slot The computer is equipped with a PCMCIA 3.3V/5V slot for one type II PC Card. Inserting and Removing PC Cards • Align the PC Card with the slot and push it in until it locks into place. •...

  • Page 44: Touchpad And Buttons/Mouse

    Storage Devices, Mouse, Audio & Printer Mouse Driver If you are using an ex- ternal mouse your op- erating system may be able to auto-configure your mouse during its installation or only en- able its basic functions. Be sure to check the device’s user docu- mentation for details.

  • Page 45: Configuring The Infrared Settings For Fir

    Configuring the Infrared Settings for FIR To configure your computer for Fast Infrared (FIR) communication follow these steps: Click Start, point to Settings and click Control Panel (or just click Start > Control Panel). Double-click Wireless Link (Printers and Other Hardware Category) icon. Click Hardware (tab), and click the Properties button, then click the Advanced (tab).

  • Page 46: Audio Features

    Storage Devices, Mouse, Audio & Printer Sound Volume Adjustment How high the sound volume can be set de- pends on the setting of volume control within Windows. Click the Volume icon on the taskbar to check the setting. Figure 2 - 7 Realtek Audio Configuration Menus...

  • Page 47: Channel Sound Support

    Storage Devices, Mouse, Audio & Printer 8 Channel Sound Support If you wish to configure your system for 8 channel sound support, then the fol- lowing ports should be used as outputs. • Side Speaker Out - Connect to S/PDIF Out •...

  • Page 48: Audio "Dj" Cd Player

    Storage Devices, Mouse, Audio & Printer Disk Eject Warning Don’t try to eject a CD/ DVD while the system is accessing it. This may cause the system to “crash”. Stop the disk first then eject it, or press the stop but- ton twice.
  • Page 49 Audio "DJ" Power Button Previous Track Next Track Shuffle (loop, in order, shuffle) LED Display Play/Pause Stop (press twice to eject the CD/DVD) Volume Down Volume Up 10. Audio Format Indicator 11. Shuffle Mode Indicator 12. Track Indicator Note: The time will be displayed on the LED Display if set in the BIOS (see “Display Time on LED (Advanced Menu >...

  • Page 50: Adding A Printer

    Storage Devices, Mouse, Audio & Printer Parallel Printer After setting up the printer attach the paral- lel cable to the printer. Connect the printer’s parallel cable to the Parallel port. Turn ON the printer, then the computer. Windows will identify the printer and either load one of its own drivers or ask you to...

  • Page 51: Chapter 3: Power Management

    Chapter 3: Power Management Overview To conserve power, especially when using the battery, your computer uses the ACPI power management system. Power management conserves power by controlling individual components of the computer (the monitor and hard disk drive) or the whole system. This chapter covers: •...

  • Page 52: The Power Sources

    Power Management Power Button as Stand by or Hibernate Button If you are using a fully ACPI-compliant (such as Windows XP) you can use the OS’s “Power Options” con- trol panel to set the power button to send the system into Stand by or Hibernate mode (see your OS’s docu- mentation, or...

  • Page 53: Turning On The Computer

    Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the power button on the front panel. When the computer is on, you can use the power button as a Stand by/Hiber- nate/Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and holding the power button for longer than this will shut the com- puter down).

  • Page 54: Power Schemes

    Power Management Resuming Operation Press a key on the keyboard to have the system resume from Monitor or Hard Disk Stand by. Figure 3 - 1 Power Schemes 3 - 4 Power Schemes Power Schemes You can set your computer to conserve power through individual components by means of Power Schemes.
  • Page 55 Power Management Each Windows Power Scheme will also adjust the processor performance of your machine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose the Home/Office Desk scheme for maximum performance when the computer is powered from an AC power source.

  • Page 56: System Power Options

    Power Management System Power Options You can use the system power options to stop the computer’s operation and restart where you left off. This system features Stand by and Hibernate sleep mode levels (Hibernate mode will need to be enabled by clicking the option in the Hibernate tab in the Power Options control panel - Figure 3 - 2 on page 3 -...

  • Page 57: Stand By

    Stand by Stand by saves the least amount of power, but takes the shortest time to return to full operation. During Stand by the hard disk is turned off, and the CPU is made to idle at its slowest speed. All open applications are retained in memo- ry.

  • Page 58: Configuring The Power Button

    Power Management Figure 3 - 3 Power Options (Advanced - Power Buttons) 3 - 8 Configuring the Power Button Configuring the Power Button The power button may be set to send the computer in to either Stand by or Hibernate mode. In Stand by mode, the LED bernate mode the LED will be off.

  • Page 59: Battery Information

    Battery Information Please follow these simple guidelines to get the best use out of your battery. New Battery Always completely discharge, then fully charge, a new battery (see FAQ” on page 3 - 12 for instructions on how to do this). Battery Life Your computer’s battery life is dependent upon many factors, including the programs you are running, and peripheral devices attached.

  • Page 60: Recharging The Battery With The Ac/Dc Adapter

    Power Management Conserving Battery Power To conserve battery pow- Lower the brightness lev- el of the LCD display. The system will decrease LCD brightness slightly to save power when it is not pow- ered by the AC/DC adapt- Close modem or commu- nication applications when they are not being...

  • Page 61: Proper Handling Of The Battery Pack

    Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g.

  • Page 62: Battery Faq

    Power Management Caution Danger of explosion if battery is incorrectly replaced. Replace only with the same equivalent type recommended by the manufacturer. Dis- card used battery ac- cording manufacturer’s structions. 3 - 12 Battery Information Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery.

  • Page 63: Chapter 4: Drivers & Utilities

    Chapter 4: Drivers & Utilities This chapter deals with installing the drivers and utilities essential to the operation or improvement of some of the computer’s subsystems. The system takes advantage of some newer hardware compo- nents for which the latest versions of most available operating systems haven’t built in drivers and utili- ties.

  • Page 64: What To Install

    Drivers & Utilities What to Install The Device Drivers & Utilities + User’s Manual CD-ROM contains the drivers and utilities necessary for the proper operation of the computer. The drivers for all the modules (WLAN, Bluetooth, PC Camera and TV Tuner) are on the separate CD-ROMs supplied. Table 4 - 1, on page 4 - 7 lists what you need to install manually according to your choice of the operating system, and it is very important that the driv-...
  • Page 65 Drivers & Utilities Navigate (Browse..) to D: You will notice that many of the instructions for driver installation require you to “Navigate (Browse) to D:”. We assume that you will install all drivers and utilities from the built-in CD device and it is assigned to “Drive D:”.

  • Page 66: Service Packs

    Drivers & Utilities Service Packs Check the warnings on the following pages regard- ing installation of the appropriate Service Pack for your Windows OS. If you are unsure of the Service Pack currently installed see below. Make sure you have installed the appropriate Service Pack before installing all the drivers.

  • Page 67: Authorized Driver Message

    Authorized Driver Message If you receive a message telling you that the driver you are installing is not authorized (Digital Signa- ture Not Found), just click Yes or Continue Any- way to ignore the message and continue the installation procedure. You will receive this message in cases where the driver has been released after the version of Win- dows you are currently using.

  • Page 68: Driver Installation

    Drivers & Utilities Driver Installation Insert the Device Drivers & Utilities + User’s Man- ual CD-ROM and the Notebook Driver Installa- tion application will run automatically. If you want to install the driver manually see Installation” on page 4 - Check the driver installation order from 1, on page 4 - 7 (the drivers must be installed...

  • Page 69: Manual Driver Installation

    Windows XP (SP2) & Windows XP Media Center Edition (SP2) Driver Page Chipset Page 4 - 9 RAID Page 4 - 9 AMD Processor Page 4 - 10 Page 4 - 10 Video (VGA) Page 4 - 10 Audio Modem Page 4 - 11 Network (LAN) Page 4 - 11...

  • Page 70: Windows Xp

    Drivers & Utilities Windows XP Driver Installation Procedure This section covers driver and utility installation in- structions for Windows XP Home & Professional. Insert the Device Drivers & Utilities + User’s Man- ual CD-ROM and click the appropriate driver name from the NoteBook Driver Installation menu and follow the instructions to install the driv- er, or Click Start and navigate (Browse..) to fol- low the manual setup instructions.

  • Page 71: Chipset

    Chipset 1. Double-click Chipset. Click Start (menu) > Run... and navigate (Browse..) to D:\Drivers\00CHIPSET\Setup.exe and click OK. 2. Click Next > Yes > Next > Next. 3. Click OK to restart the computer. Drivers & Utilities RAID 1. Double-click RAID. Click Start (menu) >...

  • Page 72: Amd Processor

    Drivers & Utilities AMD Processor 1. Double-click AMD. Click Start (menu) > Run... and navigate (Browse..) to D:\Drivers\02AMD\setup.exe and click 2. Click Next > Yes > Next > Next. 3. Click the button “Yes, I want to restart the computer now.”, and click Finish. Video (VGA) 1.

  • Page 73: Modem

    Modem 1. Double-click Modem. Click Start (menu) > Run... and navigate (Browse..) to (one of the following) D:\Drivers\05MODEM\Setup.exe and click 2. Click OK > OK. 3. Click Yes to restart the computer. 4. The modem is now ready for configuration. Modem Country Selection Be sure to check if the modem country selection is ap- propriate for you (Control Panel >...

  • Page 74: Ap-Key Buttons

    Drivers & Utilities AP-Key Buttons 1. Double-click AP-key. Click Start (menu) > Run... and navigate (Browse..) to D:\Drivers\07AP-Key\AKSETUP.exe and click OK. 2. Click Next. 3. Click Finish to restart your computer. 4 - 12 Windows XP TouchPad 1. Double-click Touchpad. Click Start (menu) >...

  • Page 75: Module Drivers

    Module Drivers See the following pages for the driver installation procedures for any modules included in your pur- chase option. Wireless LAN See the install procedure in “Intel WLAN Driver Installation” on page 7 - 4 WLAN Driver Installation” on page 7 - WLAN &...
  • Page 76 Drivers & Utilities 4 - 14...

  • Page 77: Chapter 5: Bios Utilities

    Chapter 5: BIOS Utilities Overview This chapter gives a brief introduction to the computer’s built-in software: Diagnostics: The POST (Power-On Self Test) Configuration: The Setup utility If your computer has never been set up, or you are making important changes to the system (e.g.

  • Page 78: The Power-On Self Test (Post)

    BIOS Utilities POST OR Phoenix Firstware Screen If you have disabled the Boot Diagnostic Screen POST screen will not appear (see page 11), and the Firstware Screen will appear instead. Figure 5 - 1 POST Screen 5 - 2 The Power-On Self Test (POST) The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to con- duct a POST, including a quick test of the on-board RAM (memory).

  • Page 79: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non-fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.

  • Page 80: The Setup Program

    BIOS Utilities The Setup Program The Phoenix Setup program tells the system how to configure itself and man- age basic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen in Figure 5 - 1 on page 5 - 2 is usually...

  • Page 81: Setup Screens

    Setup Screens The following pages contain additional advice on portions of the Setup. Along the top of the screen is a menu bar with five (5) menu headings. When you select a heading, a new screen appears. Scroll through the features listed on each screen to make changes to Setup.

  • Page 82: Main Menu

    BIOS Utilities Figure 5 - 2 Main Menu 5 - 6 Main Menu Main Menu PhoenixBIOS Setup Utility Main Main Advanced Security System Time: [22:11:05] System Date: [00/22/2005] IDE Channel 0 Master [FUJITSU MHT2040AT-(PM)] IDE Channel 0 Slave [FUJITSU MHT2040AT-(PM)] IDE Channel 1 Master [TSSTcorpCDW/DVD TS-L462A-] IDE Channel 1 Slave...

  • Page 83: Ide Channel 0/1/2/3 Master/Slave (Main Menu)

    BIOS Utilities IDE Channel 0/1/2/3 Master/Slave (Main Menu) Pressing Enter here opens the sub-menu to show the configuration of hard disks and CD/DVD device(s) on the computer’s IDE Channels. Use the Auto (Type:) setting to have the items configured automatically for you. System/Extended Memory: (Main Menu) This item contain information on the system memory, and is not user config- urable.

  • Page 84: Advanced Menu

    BIOS Utilities Figure 5 - 3 Advanced Menu 5 - 8 Advanced Menu Advanced Menu PhoenixBIOS Setup Utility Main Advanced Advanced Security Setup Warning Setting items on this menu to incorrect values may cause your system to malfunction. Advanced Chipset Control I/O Device Configuration Reset Configuration Data: [No]...
  • Page 85 SATA RAID Enable (Advanced Menu > Advanced Chipset Control) Enable/Disable SATA RAID mode from this menu (see page 7 - 21). PhoenixBIOS Setup Utility Advanced Advanced Advanced Chipset Control SATA RAID Enable [Enabled] CPU FAN Speed: [Auto] Card Reader: [Enabled] Display Time on LED [Enabled] Help...

  • Page 86: I/O Device Configuration (Advanced Menu)

    BIOS Utilities Card Reader: (Advanced Menu > Advanced Chipset Control) This option allows you to enable/disable support for the 10-in-1 Card Read- er. and is “Enabled” by default. However if you are installing an operating system (e.g. Windows XP) it is recommended that you disable the card reader, as otherwise the card reader slots will automatically be defined as drives “C:”...

  • Page 87: Reset Configuration Data (Advanced Menu)

    BIOS Utilities Reset Configuration Data (Advanced Menu) This item is set to No as default. You can change the setting to Yes if you have installed a new add-on which has reconfigured the system, resulting in such a serious system conflict that the operating system is unable to boot. Boot Diagnostic Screen: (Advanced Menu) Use this menu item to enable/disable the Boot-time Diagnostic Screen (or POST screen - see...

  • Page 88: Security Menu

    BIOS Utilities Figure 5 - 5 Security Menu Security Menu changes make here affect the access to the Setup utility itself, and also access to your ma- chine as it boots up af- ter you turn it on. These settings do not affect your machine or network passwords...

  • Page 89: Password On Boot: (Security Menu)

    Password on boot: (Security Menu) Specify whether or not a password (supervisor or user password) should be entered to boot the computer. If “Enabled” is selected, only users who enter a correct password can boot the system (see the warning in the sidebar). The default setting is “Disabled”.

  • Page 90: Boot Menu

    BIOS Utilities Figure 5 - 6 Boot Menu 5 - 14 Boot Menu Boot Menu PhoenixBIOS Setup Utility Main Advanced Security Boot priority order: USB FDC: HDD 1: FUJITSU MHT2040AT-(PM) SATA 1: PCI SCSI: CD-ROM 1: TSSTcorpCDW/DVD TS-L462A- USB KEY: PCI LAN: Excluded from boot order: : HDD 2:...

  • Page 91: Exit Menu

    Exit Menu PhoenixBIOS Setup Utility Main Advanced Security Exit Saving Changes Exit Discarding Changes Load Setup Defaults Discard Changes Save Changes Help Select Item Exit Select Menu Enter Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup. You can also choose to restore the original Setup defaults that will return the Setup to its original state, and erase any previous changes you have made in a previous session.
  • Page 92 BIOS Utilities 5 - 16...

  • Page 93: Chapter 6: Upgrading The Computer

    Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps outlined to make the desired upgrades. If you have any trouble or prob- lems you can contact your service representative for further help. Before you begin you will need: •...

  • Page 94: When Not To Upgrade

    Upgrading The Computer Power Safety Warning Before you undertake any upgrade proce- dures, make sure that you have turned off the power, discon- nected all peripherals and cables (including telephone lines). It is advisable to also re- move your battery in order to prevent acci- dentally turning...

  • Page 95: Removing The Battery

    Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons it is best to remove the battery. Turn the computer off, and turn it over. Loosen screws Release the battery, and lift the battery out of the battery bay. Upgrading The Computer Warranty Warning Please check with your...

  • Page 96: Upgrading The Hard Disk Drive(S)

    Upgrading The Computer HDD System Warning New HDD’s are blank. Before you begin make sure: You have backed up any data you want to keep from your old HDD. You have all the CD- ROMs and FDDs re- quired to install your oper- ating system programs.
  • Page 97 Release the cable and lift the hard disk assembly computer. Remove screws in order to separate the bracket from the hard disk(s), and disconnect the cable Reverse the process to install a new hard disk(s). up out off the (see sidebar). Upgrading the Hard Disk Drive(s) 6 - 5 Upgrading The Computer Hard Disk Cable...

  • Page 98: Upgrading The System Memory (Ram)

    Upgrading The Computer Memory Sockets If you are installing one memory module then it must be in- stalled in the lower memory socket. Figure 6 - 4 RAM Cover Removal 6 - 6 Upgrading the System Memory (RAM) Upgrading the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line (SO-DIMM) DDR type memory modules (see total memory size is automatically detected by the POST routine once you...
  • Page 99 Gently pull the two release latches ( socket in the direction indicated by the arrows in The RAM module will pop-up, and you can remove it. Pull the latches to release the second module if necessary. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory socket (if you are installing only one RAM module, then it must be inserted into the lower socket only).

  • Page 100: Upgrading The Optical (Cd/Dvd) Device(S)

    Upgrading The Computer Figure 6 - 6 Removing the CD/ DVD Device(s) 6 - 8 Upgrading the Optical (CD/DVD) Device(s) Upgrading the Optical (CD/DVD) Device(s) Turn off the computer, and turn it over and remove the battery. Locate the hard disk bay cover and remove screws the bay cover.

  • Page 101: Chapter 7: Modules

    Modules Chapter 7: Modules Overview This chapter contains the information on the various modules (some of which are optional) which may come with your computer, depending on the config- uration purchased. If you are unsure please contact your service representa- tive.

  • Page 102: The Wireless Lan & Bluetooth Modules

    Modules Wireless Device Operation Aboard Aircraft The use of any porta- ble electronic trans- mission devices aboard aircraft is usu- ally prohibited. Make sure the module(s) are OFF if you are using the computer aboard aircraft. 7 - 2 The Wireless LAN & Bluetooth Modules The Wireless LAN &...

  • Page 103: Mini-Pci Wireless Lan Module

    Mini-PCI Wireless LAN Module Before installing the Wireless LAN driver, make sure that the optional WLAN module is on (the LED will be green). Use the WLAN module key combination Fn + F11 to toggle power to the WLAN module. Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - You will be provided with the appropriate driver CD for your module.

  • Page 104: Intel Wlan Driver Installation

    Modules User Guide You can view the User Guides by inserting the Intel PROSet/ Wireless CD-ROM and clicking View User Guides (but- ton) as per Figure 7 - 1. Figure 7 - 1 Intel PROSet/ Wireless 7 - 4 Mini-PCI Wireless LAN Module Intel WLAN Driver Installation 1.

  • Page 105: Ralink 6833 Wlan Driver Installation

    Ralink 6833 WLAN Driver Installation 1. Make sure the WLAN module is powered ON. 2. Insert the Wireless LAN CD-ROM into the CD/DVD drive. 3. The program will run automatically. 4. Click Yes to accept the license agreement. 5. Click Finish. 6.
  • Page 106 Modules Figure 7 - 2 Ralink WLAN Utility Help Menu 7 - 6 Mini-PCI Wireless LAN Module...

  • Page 107: Bluetooth/Wlan Combo Module

    Modules Bluetooth/WLAN Combo Module Before installing the Bluetooth/WLAN driver, make sure that the optional Bluetooth module/WLAN is on. Use the Bluetooth module key combina- tion Fn + F12 to toggle power to the Bluetooth module. Use the WLAN module key combination Fn + F11 to toggle power to the WLAN module (the LED will be orange for Bluetooth and green for WLAN).

  • Page 108: Msi 6855B Wlan Driver Installation

    Modules 7 - 8 Bluetooth/WLAN Combo Module MSI 6855B WLAN Driver Installation 1. Make sure the WLAN module is powered ON. 2. Insert the Wireless LAN CD-ROM into the CD/DVD drive. 3. The program will run automatically. 4. Click Install Software (button) and click Next. 5.
  • Page 109 Changing the Control Setting in WinXP The operating system is the default setting for wireless LAN control in Win- dows XP. It is recommended that you switch to use the WlanUtility to control your WLAN connection. Right-click the WLAN icon Connections.
  • Page 110 Modules Figure 7 - 3 Switching WLAN Controls 7 - 10 Bluetooth/WLAN Combo Module...

  • Page 111: Bluetooth Module

    Bluetooth Module Before installing the Bluetooth driver, make sure that the optional Bluetooth module is on (the LED will be orange). Use the Bluetooth module key combination Fn + F12 to toggle power to the WLAN module. Make sure you install the drivers in the order indicated Table 4 - 1, on page 4 - Bluetooth Driver Installation 1.
  • Page 112 Modules User Guide View the BlueSoleil User Guides from the Help Menu (or press the F1 key) in the IVT Corporation BlueSo- leil - Main Window control panel. Click BlueSoleil User Guides in the Con- tents tab, and click to select the appropriate User Guide from the panel on the right.

  • Page 113: Mini-Pci Tv Tuner Module

    Mini-PCI TV Tuner Module If your purchase includes the optional AverMedia M103 Hybrid Mini-PCI TV Tuner (analog and digital) it will allow you to watch TV, play music CDs, video conference and capture still images and video on your PC. You will need to install the driver and application software as per the instruc- tions overleaf.

  • Page 114: Installing The Avertv Utility Software

    Modules AverTV User Guide Insert the AverTV Util- ity CD-ROM and click Acrobat Reader (but- ton) to install the pro- gram (if you have not already done so) to read the AVerTV User Guide. The guide is accessible from the Start >...

  • Page 115: Digital Tv Broadcast Signal

    Digital TV Broadcast Signal The antenna is the most crucial factor in receiving a clear Digital Terrestrial TV broadcast signal. The passive antenna provided should provide a clear sig- nal when placed beside a window. If the signal is not clear then you can pur- chase an active antenna (it should also be placed beside a window) to improve the signal.

  • Page 116: Pc Camera

    Modules PC Camera & TV Tuner If you have the optional TV Tuner included in your purchase, make sure you install the TV Tuner driver and appli- cation first. After in- stalling the PC Camera driver you will need to select which device to use with the EMAM- CAP program.

  • Page 117: Pc Camera Audio Setup

    PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Go to the Start menu and point to Settings (or click Control Panel) and click Control Panel, then double-click the Sounds &...
  • Page 118 Modules Figure 7 - 6 Audio Setup 7 - 18 PC Camera...

  • Page 119: Emamcap

    EMAMCAP The EMAMCAP video viewer can capture video files to .avi format, and is useful for basic general purpose video viewing and testing (a number of com- mercially available programs support advanced video capture features). Run the EMAMCAP program from the Start > Programs/All Programs > USB2.0 1.3 PC Cam menu (it is recommended that you set the capture file before the capture process - see Set Capture File below).
  • Page 120 Modules Figure 7 - 7 Video Image 7 - 20 PC Camera Eliminating Screen Flicker If you find that the video screen in the EMAMCAP program is flickering, you can try to adjust the setting in the Lighting Selection options. Run the EMAMCAP program.

  • Page 121: Raid Setup

    RAID Setup If your purchase includes the RAID (Redundant Array of Independent Disks) option, then see the instructions on the following pages for an introduction to configuring your hard disk(s) in RAID mode, This will allow you to use your hard disks in combination with Striping (RAID 0) or Mirroring (RAID 1) for fault tolerance and performance.

  • Page 122: Raid Mode Setup

    Modules Figure 7 - 8 Advanced Menu > Advanced Chipset Control (BIOS) 7 - 22 RAID Setup RAID Mode Setup Install two identical serial hard disk drives Prepare a formatted blank 3.5" 1.44MB floppy diskette, and an external USB floppy disk drive. Create a RAID Driver Diskette by using an operable computer to copy the drvdisk folder from the Device Drivers &...
  • Page 123 Select the CD-ROM/DVD-ROM as the first device in the "Boot priority order" by pressing the <Shift> and <+> keys to move the CD-ROM/DVD- ROM to the top of the order. PhoenixBIOS Setup Utility Main Advanced Security Boot priority order: IDE 1: QSI CD-RW/DVD-ROM SBW242C IDE 0: PCI SCSI: FT TX...
  • Page 124 Modules Figure 7 - 11 VIA RAID BIOS Array Menu Figure 7 - 12 VIA SATA RAID Delete Array 7 - 24 RAID Setup The SATA RAID BIOS Utility will then appear. VIA Tech. VT8237 Series SATA RAID BIOS Ver 4.93 Create Array Delete Array Create/Delete Spare...

  • Page 125: Hard Disks

    13. Select the Create Array menu option, and press Enter. 14. Choose Select Disk Drives from the menu, and press Enter to select the disk drives. 15. Select an option from the Create Array menu and press Enter. • Auto Setup For Performance - Choose this option to quickly set up a RAID level 0 for best performance OR select the option from the Array Mode RAID...

  • Page 126: Operating System Installation Warning

    Modules Operating System Installation Warning If you are installing an operating system (e.g. Windows XP), have a 10-in-1 Card Reader present, make sure to set the Card Reader option in the BIOS to “Disabled”. Figure 7 - 14 RAID Controller OS Select 7 - 26 RAID Setup 16.
  • Page 127 26. Press Enter to continue installing the operating system as normal (see your Windows documentation if you need help on installing the Windows OS). 27. Install the chipset driver as per the instructions in 28. Install the RAID driver as per the instructions in 29.
  • Page 128 Modules 7 - 28...

  • Page 129: Chapter 8: Troubleshooting

    Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 130: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer appears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.

  • Page 131: Backup And General Maintenance

    Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wallet.

  • Page 132: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the definitions file updates are usually downloadable directly from the internet.

  • Page 133: Upgrading And Adding New Hardware/Software

    Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 134 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...

  • Page 135: Problems & Possible Solutions

    Problems & Possible Solutions Problem You turned the power on Battery missing / incorrectly installed. Check the battery bay, make sure the battery is but it doesn’t work. present and seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
  • Page 136 Troubleshooting Problem The computer feels too hot. Nothing appears screen. No image appears on the external monitor I have plugged in and powered on. 8 - 8 Problems & Possible Solutions Possible Cause - Solution Make sure the computer is properly ventilated and the vents/fan intakes are not blocked. If this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour.
  • Page 137 Problem forget boot If you forget the password, you may have to discharge the battery of the CMOS. Contact password. your service representative for help. If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
  • Page 138 Troubleshooting Problem The Audio "DJ" CD Player will not turn on (nothing appears on the LED Display of the player). Unwelcome numbers appear when typing. If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically.
  • Page 139 Problem Wireless LAN/ The modules are off. Check the LED indicator Bluetooth/ modules (see “LED Indicators” on page 1 - cannot be detected. appropriate AP-Key button in order to enable the modules (see Wireless LAN/ The driver(s) for the module(s) have not been installed. Make sure you have installed the Bluetooth/ modules driver for the appropriate module (see the instructions in...
  • Page 140 Troubleshooting 8 - 12...

  • Page 141: Appendix A: Interface (Ports & Jacks)

    Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the ports & jacks which allow your computer to communicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...

  • Page 142: Ports And Jacks

    Interface (Ports & Jacks) Ports and Jacks Item Description Built-In Microphone The built-in microphone allows you to record on your computer DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer. Serial Port Connect a serial type mouse to this port. Parallel Port Connect a parallel type printer to this port.

  • Page 143: Rj-11 Phone Jack

    Interface (Ports & Jacks) Item Description RJ-11 Phone Jack This port connects to the built-in modem. You may plug the telephone line directly into this RJ-11 telephone connection. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port. RJ-45 LAN Jack This port supports LAN (Network) functions.

  • Page 144: Mini-Ieee 1394A Ports

    Interface (Ports & Jacks) Item Description Mini-IEEE 1394a Ports This allows high-speed connection to various peripheral devices, e.g. external disk drives and digital cameras (see note below). IEEE 1394 The Mini-IEEE 1394a ports only support SELF POWERED IEEE 1394 devices. Line-In Jack The Line-In jack allows you to play audio sources through the computer’s speakers.

  • Page 145: Appendix B: Nvidia Video Driver Controls

    Appendix B: NVIDIA Video Driver Controls The basic settings for configuring the LCD are outlined in on page 1 - NVIDIA Video Driver Installation Make sure you install the drivers in the order indicated in page 4 - 1. Double-click VGA from the Notebook Driver Installation menu. Click Start (menu) >...

  • Page 146: Nvidia Display Properties

    NVIDIA Video Driver Controls Taskbar Icon Click the NVIDIA task- bar icon then click NVIDIA Display > Laptop Display bring up the GeForce Go/Quadro control panel. If you cannot see the tray icon , go to the GeForce Go/Quadro FX Go control panel tab and select the Tools item from the Additional Properties...

  • Page 147: Additional Properties

    Additional Properties The items listed in the Additional Properties window allow you to configure your display(s). If the items do not display you can either click the Additional Properties button, or click the icon . Click pin icon to push pin in to keep the menu open.
  • Page 148 NVIDIA Video Driver Controls Figure B - 3 Screen Examples Help Menus Right-click on many of the items in the tabs to bring up the “What’s This?” button. Click “What’s This?” button to bring up the help menu. B - 4 NVIDIA Display Properties You may make changes to the Display Settings, Color Correction, Video Overlay, Resolutions, Refresh Rates and Screen Rotation by clicking the ap- propriate tab and adjusting the setting.

  • Page 149: Nvidia Nview Desktop Manager

    NVIDIA nView Desktop Manager The nView Desktop Manager allows quick access to control panels for fea- tures such as Desktop Management, Profiles, Hot Keys etc. The Control panel may be accessed as follows. Click Start, point to Settings and click Control Panel (or just click Control Panel).

  • Page 150: Display Devices

    NVIDIA Video Driver Controls Display Wizard Use the Display Wiz- ard in the Desktop Management window to quickly setup and configure any attached displays (see Figure B - B - 4 on page B - 6 Display Devices Display Devices Besides the built-in LCD, you can also use an external monitor/flat panel dis- play or TV as your display device.

  • Page 151: Attaching Other Displays

    Attaching Other Displays If you prefer to use a monitor or flat panel display, connect it to the DVI-Out Port at the rear of the computer. Attach your external monitor to the DVI-Out Port (or TV to the S-Video-Out jack), and turn it on. Go to Additional Properties in the GeForce Go/Quadro FX Go Properties control panel tab (see “NVIDIA Display Properties”...
  • Page 152 NVIDIA Video Driver Controls nView Display Mode Options The display options listed under the Prima- ry/Secondary display drop boxes will differ according to the dis- plays attached, and Display Mode chosen. Click Detect Displays (button) to automati- cally update the at- tached display information.

  • Page 153: Display Modes

    Display Modes Single Display Mode Only one of your displays is used. Clone Mode Clone Mode simply shows an exact copy of the Primary display desktop on the other display(s). This mode will drive multiple displays with the same con- tent and each display device can be configured independently.

  • Page 154: Enabling Tv Display

    NVIDIA Video Driver Controls Detect Displays To get a full range of options from the De- vice Settings menu click the Detect Dis- plays button. Click to select the TV icon, then click the Device Settings button. Figure B - 7 TV Settings B - 10 Enabling TV Display Enabling TV Display...
  • Page 155 NVIDIA Video Driver Controls Set the TV format from the Select TV Format menu. The Advanced option (in Dualview mode) at the bottom of the Select TV Format menu allows you to select TV format by country if you are unsure of your TV format. Figure B - 8 TV Settings and Adjustments...
  • Page 156 NVIDIA Video Driver Controls B - 12...

  • Page 157: Appendix C: Specifications

    Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly proces- sor types/speeds and CD/DVD device types) may be changed or updated due to the manufacturer's release sched- ule.

  • Page 158: Processor Types

    Specifications Feature Processor Types AMD Athlon™ 64 FX-53 (89W), FX-55 (104W) 939-pin OuPGA Package AMD Athlon™ 64 (67 - 85.3 W) 939-pin OuPGA Package AMD Athlon™ 64 X2 (35 - 110 W) 939-pin OuPGA Package AMD Athlon™ 64 X2 (35 - 110 W) 939-pin OuPGA Package Core Logic VIA K8T890CE + VT8237R Chipset...

  • Page 159: Bios

    Feature Memory Two 64-bit wide DDR Data Channels Two 200 Pin DDR SODIMM Sockets Supporting DDR 400MHz Expandable up to 2GB (Compatible with 1024MB, 512MB, 256MB DDR 400MHz Modules) BIOS One 512KB Flash ROM Video Card NVIDIA GeForce Go 6800 Options NV42M High Performance Graphic Chip 256MB DDR OR DDR-III (DDR3) Video RAM...

  • Page 160: Storage Options

    Specifications Feature Storage Options One External USB 1.44Mb Floppy Disk Drive One Changeable Primary 2.5" 9.5mm (h) Serial (SATA) or Parallel (PATA) Hard Disk Drive One Changeable Secondary 2.5" 9.5mm (h) Hard Disk Drive (RAID Option in SATA Configura- tion) Supports Serial (SATA) and Parallel (PATA) HDDs RAID 0, RAID 1, HDD Fault Tolerance System in SATA Configuration One Changeable Primary Optical Device Bay - 12.7 mm (h) for Optical CD/DVD Device Drive...

  • Page 161: I/O Ports

    Feature I/O Ports Four USB 2.0 Ports Two Mini-IEEE1394a Ports One S-Video-Out Jack for TV & HDTV Output One Serial Port One Parallel Port (LPT1) Supporting ECP/EPP One Infrared Transceiver (IrDA 1.1/FIR/SIR/ ASKIR) One DVI-Out Port One PS/2 Port (Mouse/Keyboard) One Headphone/Speaker-Out Jack One Microphone-In Jack Communication...

  • Page 162: Power Management

    Specifications Feature Power Supports ACPI 2.0 Management Power Full Range AC/DC Adapter – AC in 100~240V, 47~63Hz DC Output 20V, 11 A (220 Watts) Easy Changeable 12-Cell Smart Lithium-Ion 6600mAH/14.8V Main Battery Environmental Temperature Spec Operating: Non-Operating: Physical 397mm (w) * 298mm (d) * 49.5mm (h) Dimensions &...

Table of Contents
