- Page 1 ALIENWARE M11x ® COMPREHENSIVE SPECIFICATIONS...
- Page 2 Reproduction of these materials in any manner whatsoever without the prior written permission of Dell Inc. is strictly prohibited. Trademarks used in this manual: Alienware is a trademark or registered trademarks of Alienware Corporation.; Dell is a trademark of Dell Inc.; Intel and Pentium are the registered trademarks and Core is a trademark of Intel Corporation in the U.S.
-
Page 3: Comprehensive Specifications
COMPREHENSIVE SPECIFICATIONS COMPREHENSIVE SPECIFICATIONS... - Page 4 COMPREHENSIVE SPECIFICATIONS Computer Model Alienware M11x Dimensions Height (Front and Back) Width Depth Weight with 8-cell battery (starting at) 32.7 mm (1.29 inches) 285.7 mm (11.25 inches) 233.3 mm (9.19 inches) 1.99 kg (4.39 lb) NOTE: The weight of your laptop will vary depending on the configuration ordered and the manufacturing variability.
- Page 5 Processor and System Chipset Processor L2 cache Intel Pentium Dual Core Intel Core2 Duo Bus clock System chipset SDRAM bus width Processor address bus width Processor data width BIOS EPROM Graphics bus PCI bus COMPREHENSIVE SPECIFICATIONS Intel Pentium™ Dual Core Intel Core™2 Duo ®...
- Page 6 COMPREHENSIVE SPECIFICATIONS Memory Connectors Capacities Memory type Memory configurations possible IEEE 1394 A IEEE 1394A controller IEEE 1394 interface Ports and Connectors Network adapter HDMI two internally-accessible DDR3 SODIMM sockets 1 GB, 2 GB, and 4 GB 800 MHz (dual-channel configurations) 2 GB, 4 GB, and 8 GB JMicron JMB380 compliant with standard IEE1394a-2000 specification...
- Page 7 Ports and Connectors DisplayPort Audio 3-in-1 Media Card Reader SIM card IEEE 1394 Communications Network adapter Wireless COMPREHENSIVE SPECIFICATIONS one 20-pin connector two audio output/headphone connectors and one audio input/microphone connector one combo connector one SIM card slot one 4-pin serial connector 10/100 Mbps Ethernet LAN on system board •...
- Page 8 COMPREHENSIVE SPECIFICATIONS Video Video controller integrated on the system board Discrete video controller Video memory Intel GS45 Nvidia NV11P-GS1 External display support Audio Controller Speaker Internal speaker amplifier Internal microphone support Volume controls Intel GS45 Nvidia NV11P-GS1 dynamic based on system memory capacity 1 GB VGA, HDMI, and DisplayPort Realtek ALC665...
- Page 9 Hard-Drive Storage Interface Number of hard drives Hard drive Type Cards Supported Media cards Video cards COMPREHENSIVE SPECIFICATIONS SATA 2.5 inch SATA hard drive standard portable and solid-state hard-drives • Secure Digital (SD) memory card • MultiMedia Card (MMC) • Memory Stick PRO •...
- Page 10 COMPREHENSIVE SPECIFICATIONS Display Type (WLED) Maximum resolution Dimensions Height Width Diagonal Refresh rate Operating angle Pixel pitch Controls 11.6 inch HD+ TrueLife 1366 x 768 144 mm (5.67 inches) 256.12 mm (10.08 inches) 293.83 mm (11.57 inches) 60 Hz 0° (closed) to 140° 0.2550 mm brightness can be controlled through keyboard shortcuts...
- Page 11 COMPREHENSIVE SPECIFICATIONS 82 (Korea, U.S, and Canada); 83 (Europe); 86 (Japan) RGB; colors can be changed by invoking the AlienFX application in the Alienware Command Center. For information, see your Mobile Manual. 240 cpi 71.7 mm (2.82 inches) sensor-active area 34.0 mm (1.33 inches) rectangle...
- Page 12 COMPREHENSIVE SPECIFICATIONS Battery 8-cell “smart” lithium ion (63 Whr) Height Width Depth Weight Voltage Operating time Life span (approximate) Temperature range Operating Storage Coin-cell battery 11.2 mm (0.44 inches) 173 mm (6.81 inches) 109.4 mm (4.31 inches) 0.43 kg (0.94 lb) 14.8 V battery operating time varies depending on operating conditions and can be significantly reduced under...
- Page 13 AC Adapter Type Input voltage Input current (maximum) Input frequency Output current Output power Rated output voltage Temperature range Operating Storage Connector types DC connector AC connector COMPREHENSIVE SPECIFICATIONS 65 W 100-240 VAC 1.7 A 50-60 Hz 3.34 A (continuous) 65 W 19.5 VDC 0°...
- Page 14 COMPREHENSIVE SPECIFICATIONS Computer Environment Temperature range Operating Storage Relative humidity (maximum) Operating Storage Maximum vibration (using a random vibration spectrum that simulates user environment) Operating Storage Maximum shock (Measured with hard drive in operating status and a 2-ms half-sine pulse for operating.
- Page 15 Computer Environment Altitude (maximum) Operating Storage Airborne contaminant level COMPREHENSIVE SPECIFICATIONS –15.2 to 3048 m (–50 to 10,000 ft) –15.2 to 10,668 m (–50 to 35,000 ft) G2 or lower as defined by ISA-S71.04-1985...
