- Page 1 MAULE M-8-235 Star Rocket PERFORMANCE THAT COUNTS! TLC-M-8-235 2099 Georgia Hwy 133 South ~ Moultrie, GA 31788 7/99 Tel: 229-985-2045 ~ Fax: 229-890-2402 ~ www.mauleairinc.com 7/99...
-
Page 2: Foreword
The Maule M-8 is designed and built to give you the airplane you have always want- ed. It is fast, comfortable, and easy to fly, yet no light airplane is safer than the Maule M-8. Its sturdy construction means you will not have to pamper it to enjoy long years of trouble- free service. -
Page 3: Table Of Contents
MAULE AEROSPACE TECHNOLOGY, INC. MAINTENANCE MANUAL M-8-235 TABLE OF CONTENTS ITEM PAGE Foreword..............…… i Warranty....…..........…… i Table of Con- tents…..........…… Log of Revi- sions…........…....… GENERAL DATA SECTION I - General Descrip- tion........……………….. Design Specifica- tions..........….. Fluid Capacities and Specifica- tions......……... - Page 4 MAULE AEROSPACE TECHNOLOGY, INC. MAINTENANCE MANUAL M-8-235 Maule Tailwheel…………………………………………….. Figure One…………………………………………………… Power Plant Sys- tem..…........……… Fuel Sys- tem....…......……….….. Electrical Sys- tem....…........…… Electrical Schematic - 14 Volt..…......…… Electrical Schematic - 28 Volt.......….…… Door Latch Adjustment Proce- dure..………..…….. 7/99...
-
Page 5: Section I
MAULE AEROSPACE TECHNOLOGY, INC. MAINTENANCE MANUAL M-8-235 SECTION I GENERAL DATA GENERAL DESCRIPTION: Type: Five place high wing cabin monoplane. Engine Installation: Single tractor engine in nose of fuselage. Wing: Strut braced, two spar, metal covered, modified USA 35-B airfoil. Fiberglass wing tips. -
Page 6: Fluid Capacities And Specifications
MAULE AEROSPACE TECHNOLOGY, INC. MAINTENANCE MANUAL M-8-235 Wings: Airfoil Modified USA 35-B Chord 63 inches Incidence +30 minutes Dihedral 1.2 degrees Sweepback None Areas: Wing, Aileron and Flaps 165.6 sq.ft. Ailerons (total) 14.2 sq.ft. Flaps (total) 23.9 sq.ft. Horizontal Stabilizer 18.1 sq. -
Page 7: General Maintenance
"electrolyte corrosion". Salt water and chemicals act as an electrolyte between dissimilar metals and can start a strong corrosive action over a short period of time. Maule makes eve- ry effort to separate dissimilar metals with primers and coatings during manufacture, but there are some locations (such as rivets in wing skins) where this is impossible. - Page 8 MAULE AEROSPACE TECHNOLOGY, INC. MAINTENANCE MANUAL M-8-235 Cont’d Care should be taken in the disposal of candy wrappers, paper scraps, cigarette butts, etc. These can work their way under the floorboards and become a fire hazard, mois- ture trap and could jam the control cables.
-
Page 9: Inspection Guides
MAULE AEROSPACE TECHNOLOGY, INC. MAINTENANCE MANUAL M-8-235 INSPECTION GUIDES At 25 Hour Total Time, perform 50 Hour Inspection as described below: At 50 Hour Total Time and every 50 hours thereafter: A. POWER PLANT 1. Perform appropriate inspection as called for in the engine manufacturer's Operator's Manual. - Page 10 CAUTION: For carbureted engine only: If rubber seal on air valve is in poor condition, replace seal with black nitrile rubber with cotton insert and/or if valve plate is loose, re- pair per SB#16. (Check compliance to Maule SB#16.) AIRCRAFT 1.
- Page 11 1/2” dia. is required for later models. CAUTION: Item (a)(4) of AD# 98-15-18 is very misleading as Maule never drills holes in struts to attach cuffs, door clips or any hardware and it is illegal to do so since there are no approved holes in the wing struts under the TC data.
- Page 12 Long Island City, NY Tucker, GA NOTE: Maule Service Bulletin No. 9 covers corrosion resistant parts replacement and is particularly recommended for airplanes operating in a potentially corrosive environment. Compliance to this SB provides for larger stainless steel turnbuckles and corrosion re- sistant steel fasteners and attachment details for the elevator cables.
- Page 13 (Note: earlier model Maule airplanes used a hard seal filler material, which may crack or lose adhesion with the tube.
-
Page 14: Rigging Procedures
MAULE AEROSPACE TECHNOLOGY, INC. MAINTENANCE MANUAL M-8-235 RIGGING PROCEDURES 1. LEVELING: Laterally: The airplane can be accurately leveled laterally using the front spar attach bolts. Turn these two bolts so that a flat on the head is "up". Fabricate two equal length spacers (1½... - Page 15 MAULE AEROSPACE TECHNOLOGY, INC. MAINTENANCE MANUAL M-8-235 4. TAIL ASSEMBLY: With the airplane in level position, the stabilizers should be leveled at their rear spars. The hinge line should be straight from tip to tip. The vertical stabilizer should be plumb at the hinge.
-
Page 16: Lubrication
MAULE AEROSPACE TECHNOLOGY, INC. MAINTENANCE MANUAL M-8-235 10. RUDDER TAB: This tab is interconnected with the aileron system to automatically coordinate aileron and rudder controls for simplified handling in the air. (It may be used as a rudder trim tab to make the airplane trim in cruise.) This tab may be ground adjusted by changing the... -
Page 17: Pairs
MAULE AEROSPACE TECHNOLOGY, INC. MAINTENANCE MANUAL M-8-235 FABRIC REPAIRS: (Applicable to polyurethane paint on Ceconite fabric only) REPAIRS: 1. Small holes and damaged areas can easily be repaired without removing the existing paint topcoat. 2. Trim the damaged area to a rectangular or circular shape. -
Page 18: Major Component Parts
The aft fuselage section is covered with Ceconite fabric and standard dope and paint fin- ish as per Maule Specification S-17. Later models are finished with polyurethane or acrylic urethane paint in accordance with Maule Specifications S-40 or S-41, respectively. This fab- ric need not be pulled or punch tested. -
Page 19: Surfaces And Controls
MAULE AEROSPACE TECHNOLOGY, INC. MAINTENANCE MANUAL M-8-235 SURFACES AND CONTROLS AILERONS AND FLAPS: The ailerons and flaps are aluminum alloy structures covered with 2024-T3 skin. The aileron control system consists of a chain drive connecting the two control wheels and is attached to the necessary cables which are routed over pulleys through the fuselage and into the wing section to the aileron horns. -
Page 20: Landing Gear, Wheels And Brakes
MAULE AEROSPACE TECHNOLOGY, INC. MAINTENANCE MANUAL M-8-235 LANDING GEAR, WHEELS AND BRAKES MAIN LANDING GEAR: The main landing gear consists of separate left and right side heat-treated (7075-T651) aluminum spring legs, which are bolted to a square tube truss in the bottom of the fuselage structure. - Page 21 M-8-235 BRAKE CYLINDERS: The hydraulic brakes are actuated by two (2) master cylinders, Maule p/n 4046B, on the left side, and two (2) slave cylinders Cleveland 10-54 on the right side. Check hydraulic oil level in master brake cylinder reservoirs. Proper level is 1/4 inch from top of cylinder.
- Page 22 MAULE P8B TAILWHEEL The tailwheel assembly consist of a Maule SFS-P8B full swivel steerable tailwheel and a leaf type spring mounting. See Fig. 1 for detailed breakdown. If shimmy of the tailwheel becomes a problem, it should be lubricated and adjusted as follows: A.
- Page 23 MAULE AEROSPACE TECHNOLOGY, INC. MAINTENANCE MANUAL M-8-235 Slide lock ring (73B) over the threaded end of the fork spindle and run nut (A1) down until it bottoms on the lock ring. Tighten the nut moderately and note whether or not there is any end play in the bearings.
-
Page 24: Figure 1
MAULE AEROSPACE TECHNOLOGY, INC. MAINTENANCE MANUAL M-8-235 FIGURE 1 7/99... -
Page 25: Power Plant Sys
MAULE AEROSPACE TECHNOLOGY, INC. MAINTENANCE MANUAL M-8-235 Tighten the bracket bolt and back off enough to install the cotter pin. There must be no looseness or play between the bracket (71B) and the spring. Install the connector springs, using the heavier spring on the right side. Install the springs so that the light spring is compressed approximately 1/2 to 3/4 inch. -
Page 26: Fuel System
MAULE AEROSPACE TECHNOLOGY, INC. MAINTENANCE MANUAL M-8-235 Baffling should be checked for security and the rubber sealing extensions should be checked for wear and security. When the cowl is installed, these sealing extensions should lay up, forward or inboard, and provide a good seal against the cowl. -
Page 27: Electrical System
MAULE AEROSPACE TECHNOLOGY, INC. MAINTENANCE MANUAL M-8-235 If installed, two (2) auxiliary wing tip fuel tanks, fifteen (15) gallon (or twenty-one (21) gal- lon) capacity, are mounted in the second from the outboard wing bay. They are fuel transfer tanks and simply supply fuel to the main tank through a small vibrator pump. - Page 28 MAULE AEROSPACE TECHNOLOGY, INC. MAINTENANCE MANUAL M-8-235 The battery is considered fully charged at a hydrometer specific gravity reading of 1.265. A low charge would be 1.225 or lower. Operating with a low charge will shorten the life of the battery and can be prevented by recharging or operating with the electrical equipment turned off until the battery has been sufficiently recharged.
-
Page 29: Electrical Schematic
MAULE AEROSPACE TECHNOLOGY, INC. M-8-235 MAINTENANCE MANUAL FOR Electrical Schematic The wire numbering system has been designed to ease tracing a faulty wire. The code is as shown below the schematic. Wires are plainly labeled near each end. 14 Volt... -
Page 30: Electrical Schematic
MAULE AEROSPACE TECHNOLOGY, INC. M-8-235 MAINTENANCE MANUAL FOR Electrical Schematic The wire numbering system has been designed to ease tracing a faulty wire. The code is as shown below the schematic. Wires are plainly labeled near each end. 28 Volt... -
Page 31: Dure
MAULE AEROSPACE TECHNOLOGY, INC. MAINTENANCE MANUAL M-8-235 7/99...
