- Page 1 FAA APPROVED MAULE MAULE MT-7-235 Airplane Serial No._______________________ Airplane Serial No._______________________ Registration No._________________________ Registration No._________________________ THIS DOCUMENT MUST BE KEPT IN THE AIRPLANE AT ALL TIMES. THIS DOCUMENT MUST BE KEPT IN THE AIRPLANE AT ALL TIMES. THIS DOCUMENT MUST BE KEPT IN THE AIRPLANE AT ALL TIMES.
-
Page 2: Log Of Revisions
MAULE AEROSPACE TECHNOLOGY, INC. MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 LOG OF REVISIONS Page i Page i REV. DESCRIPTION APPROVAL AND DATE APPROVAL AND DATE PAGES Propeller mod. no. B2D37C224 Propeller mod. no. B2D37C224-C/G-90RA-9 corrected to B2D37C224... -
Page 3: Log Of Supplements
08/19/02 of Wipline Model 3000 Amphibious Floats - Maule Drawing 9188A. Rev. A (05/17/99) Inst. of Aqua Model 2400 Floats - Maule Drawing 9135A, Rev. E or later revision. Rev. A 08/19/02 (11/19/99) Inst. of Century Flight Systems Century IIB Autopilot - Maule Installation Manual AK513. -
Page 4: Table Of Contents
MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 Page iii TABLE OF CONTENTS ITEM COVER PAGE LOG OF REVISIONS……………………………….…………………….. i LOG OF SUPPLEMENTS………………………….…………………..… ii TABLE OF CONTENTS…………………………….…………………..iii & iiii GENERAL SECTION I Plan View……………………………………………..…………….. 1 Maximum Weight……………………………..……………. 2 Center of Gravity Limits………………………..…………. -
Page 5: Table Of Contents
MAULE AEROSPACE TECHNOLOGY, INC. MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 Page iiii TABLE OF CONTENTS WEIGHT AND BALANCE AND EQUIPMENT LIST WEIGHT AND BALANCE AND EQUIPMENT LIST WEIGHT AND BALANCE AND EQUIPMENT LIST SECTION V Weight and Balance Data……………………………... -
Page 6: Plan View
MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION I - GENERAL PAGE 1... -
Page 7: Section I
MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION I GENERAL : NORMAL CATEGORY OPERATION MAXIMUM WEIGHT: 2500 Pounds CENTER OF GRAVITY LIMITS: +15.0 to +20.5 @ 2500 lbs. +12.0 to +20.5 @ 1800 lbs. or less Straight line variation between points given Datum: Wing Leading Edge NOTE: It is the responsibility of the pilot to assure that the airplane is property loaded. -
Page 8: Limitations
MAULE AEROSPACE TECHNOLOGY, INC. MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION II LIMITATIONS AIRSPEED LIMITS: All airspeeds are Indicated Airspeeds (IAS). : All airspeeds are Indicated Airspeeds (IAS). A. AIRSPEED INDICATOR MARKINGS: AIRSPEED INDICATOR MARKINGS: Red Radial, (V... -
Page 9: Power Plant Limits
MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION II - LIMITATIONS POWER PLANT LIMITS: Engine: Lycoming IO-540-W1A5D or IO-540-W1A5 Engine Limits: 235 hp @ 2400 rpm, Full Throttle Continuous Propeller: Hartzell: Constant Speed HC-C2YR-1BF/F8468A-6R (78") or -3R (81") McCauley: Constant Speed B3D32C414-C/G-82NDA-4 (78") or... -
Page 10: Flight Load Factors
MAULE AEROSPACE TECHNOLOGY, INC. MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION II - LIMITATIONS FLIGHT LOAD FACTORS: Cont'd. //////////////////////// DO NOT EXCEED 23 INCHES M.P. DO NOT EXCEED 23 INCHES M.P. BELOW 2050 RPM. WHEN EQUIPPED BELOW 2050 RPM. WHEN EQUIPPED... - Page 11 MAULE AEROSPACE TECHNOLOGY, INC. MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION II - LIMITATIONS PLACARDS: (Cont’d) At the main fuel tank selector valve on the At the main fuel tank selector valve on the left kick panel:...
-
Page 12: Normal Procedures
MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION III NORMAL PROCEDURES: PREFLIGHT INSPECTION: A. INTERIOR: BAT Switch…………………………………..ON Fuel Gauges…………………………………… CHECK INDICATIONS All Electrical Switches………………………… OFF BAT Switch……………………………………. OFF Flaps…………………………………………… FULL DOWN (3RD NOTCH) EXTERIOR: Begin at the left front door, proceed around the left wing to the nose area, then around the right wing and back to the fuselage, then around the tail section. -
Page 13: Operating Check Lists
MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION III - NORMAL PROCEDURES PREFLIGHT INSPECTION: (Cont'd) Nose Gear............CHECK TIRE INFLATION & STRUT EX- TENSION, CLEAN STRUT Right Landing Gear…………………………… CHECK TIRE INFLATION & BRAKE LINE Right Wing & Controls……………………….. - Page 14 MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION III - NORMAL PROCEDURES OPERATING CHECK LISTS: (Cont'd) Mixture Control………….………………..FULL LEAN Starter Switch..........TWIST FULL RIGHT TO ENGAGE FULL RICH WHEN ENGINE STARTS TO Mixture Control..........FIRE NOTE: FOR A HOT START, DO NOT PRIME. A HOT ENGINE MAY FLOOD ON A START ATTEMPT.
- Page 15 MAULE AEROSPACE TECHNOLOGY, INC. MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION III - NORMAL PROCEDURES NORMAL PROCEDURES 3.2 OPERATING CHECK LISTS: OPERATING CHECK LISTS: (Cont'd) Alternate Air Control..Alternate Air Control..……………………….. TURN LEFT TO UNLOCK AND PULL TURN LEFT TO UNLOCK AND PULL NOTE: NORMAL RPM DROP WITH ALTERNATE AIR IS APPOXIMATELY 50 RPM.
- Page 16 MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 PAGE 10 SECTION III - NORMAL PROCEDURES 3.2 OPERATING CHECK LISTS: (Cont'd) ENGINE SHUT DOWN: Parking Brakes..........ON, IF DESIRED Radios……………………………………..…… All other electrical switches………………..AS DESIRED Flaps…………………………………………… AS DESIRED Magneto Grounding Check......
-
Page 17: Normal Flight Operations
MAULE AEROSPACE TECHNOLOGY, INC. MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION III - NORMAL PROCEDURES NORMAL PROCEDURES 3.3 NORMAL FLIGHT OPERATIONS: NORMAL FLIGHT OPERATIONS: A. NOTE: FLAP SETTINGS: SETTINGS: The following Flap Settings are available: The following Flap Settings are available:... - Page 18 MAULE AEROSPACE TECHNOLOGY, INC. MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION III - NORMAL PROCEDURES NORMAL PROCEDURES D. RUDDER TRIM: NOTE: To assure full effectiveness of the Right Rudder Trim: NOTE: To assure full effectiveness of the Right Rudder Trim: Unlock "T"...
-
Page 19: Door-Off Operation
MAULE AEROSPACE TECHNOLOGY, INC. MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION III - NORMAL PROCEDURES NORMAL PROCEDURES DOOR-OFF OPERATION: OFF OPERATION: This aircraft may be operated with either one (not both) of the front doors removed, This aircraft may be operated with either one (not both) of the front doors removed,... -
Page 20: Emergency Procedures
MAULE AEROSPACE TECHNOLOGY, INC. MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION IV EMERGENCY PROCEDURES EMERGENCY PROCEDURES EMERGENCY BASIC RULES: EMERGENCY BASIC RULES: To assist the pilot when an emergency occurs, three basic rules are established which apply... -
Page 21: Engine Failure After T.o. Or Forced Landing
MAULE AEROSPACE TECHNOLOGY, INC. MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION IV - EMERGENCY EMERGENCY PROCEDURES ENGINE FAILURE AFTER TAKEOFF OR FORCED LANDING: ENGINE FAILURE AFTER TAKEOFF OR FORCED LANDING: (Cont'd) (Cont'd) Electric Fuel Pump Electric Fuel Pump - On... -
Page 22: Smoke And Fume Elimination
MAULE AEROSPACE TECHNOLOGY, INC. MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION IV - EMERGENCY EMERGENCY PROCEDURES 4.13 SMOKE AND FUME ELIMINATION: SMOKE AND FUME ELIMINATION: Cabin Heat Knob Cabin Heat Knob - In Cabin Air Knob Cabin Air Knob - In... - Page 23 MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION V WEIGHT AND BALANCE Serial Number______________________ Registration Number______________________ It is the responsibility of the airplane owner and the pilot to insure that the airplane is loaded properly. The empty weight, empty weight center of gravity and useful load are listed below for this airplane as delivered from the factory.
- Page 24 MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION V - WEIGHT AND BALANCE DETAILED CALCULATIONS OF EMPTY WEIGHT AND EMPTY WEIGHT CENTER OF GRAVITY AS DELIVERED FROM FACTORY: PROCEDURE: Place each of the wheels on a scale with the airplane in approximate level flight attitude.
- Page 25 MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION V - WEIGHT AND BALANCE The above empty weight includes unusable fuel of ** lbs. at 24 inches and 8 quarts of oil at minus 34 inches, plus all items of equipment as marked on the accompanying Equipment Lists.
- Page 26 MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION V - WEIGHT AND BALANCE FORM 56 PAGE 21...
- Page 27 MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION V - WEIGHT AND BALANCE FORM 56 PAGE 22...
- Page 28 MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION V - WEIGHT AND BALANCE FORM 56 PAGE 23...
- Page 29 MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MT-7-235 SECTION V - WEIGHT AND BALANCE SERIAL NO._________________REG.NO.__________________MODEL__________________ EQUIPMENT CHANGE - WEIGHT AND BALANCE ITEM'S (MAKE & MODEL) WEIGHT MOMENTS Previous Aircraft Empty New Empty Weight ______________________lbs. New Empty Center of Gravity ______________ins.
- Page 30 (name and address – optional) and and aircraft serial number be sent to OwnerAlert@mauleairinc.com OwnerAlert@mauleairinc.com for notification of any Maule Service Letters, Service Bu for notification of any Maule Service Letters, Service Bul- letins and/or Manual updates available for downloading from our website at letins and/or Manual updates available for downloading from our website at letins and/or Manual updates available for downloading from our website at mauleairinc.com.
