PROGRAMMING
This decoder supports all program mode and read back feature. With MRC Prodigy
Advance DCC you can read its address and CV value.
CV
Register
Description
CV1
R1
Short address
CV2
R2
Start voltage
CV3
R3
Acceleration
CV4
R4
Deceleration
CV5
---
Top voltage
Speed curve select (0=linear, 1=slow
CV6
increase at slow speed, 2=fast increase at
slow s peed
---
R6
Page number
CV29
R5
Bas ic configuration
CV7
R7
Manufacturer version number
CV8
R8
Manufacturer ID
CV17
---
Long address upper byte
CV18
---
Long address lower byte
CV19
---
Advanced consis t address
When CV21=0, all accessory functions will
CV21
---
follow its own address. When CV21=1, all
functions will follow the consist address
CV49
Sound on/off, horn is always on
CV50
---
Horn type (34 types)
CV51
---
Horn volume
CV52
---
Bell type (8 types)
CV53
---
Bell volume
CV54
---
Bell ring rate
CV55
---
Diesel rumble volume
CV56
---
Brake squeal volume
CV57
---
Dynamic brake volume
CV58
---
Air release volume
CV59
---
Air pump volume
CV60
---
Safety pop valve volume
CV61
---
Engine cooling fan volume
CV62
---
Coupling volume
CV63
Auto ditch lights with horn enable/disable
CV64
---
Rail wheel clack
CV65
Kick s tart voltage
CV67-94
28 speed steps table while CV29.4=1
CV105
---
User identification number
CV106
---
User identification number
CV113
---
Coupling fire volume
CV114
---
Brake release volume
CV115
---
Auto brake squeal enable/disable
CV116
---
Auto bell with horn enable
Light mode, 0=normal headlight
CV117
1=off, dim, bright cycle, 2=rule 17
CV118
ACC1 light mode
CV119
ACC2 light mode
Diesel notch mode, 0=auto-notch
CV122
---
3=manual notch
CV123
Prime mover type( 2 types plus diesel off) 0=G.E.
CV124
Back emf load control on/off
Program it to1 will res tore some the CV to
CV125
---
factory default settng
SPEED TABLE CV67-CV94 FOR 28 SPEED STEPS
When CV29's bit 4 is set to "1" it will use the speed table formed by CV67-CV94
to control speed (motor voltage). It allows you to setup each speed for all 28
speed steps. First, program CV29 to 18 for short addresses (1-127) or program
Range
Default
CV29 to 50 for long addresses (128-9999) to enable speed table control. Then
1-127
3
select throttle to 28 speed steps and run your loco at speed step 1. Use program
0-32
0
CV on the main to change CV67's value (1-255) to adjust step 1's speed. The
0-32
0
kick voltage, CV65 is only applied when the speed step changes from 0 to 1. You
0-32
0
should switch between 0 to 1 many times to check step 1's speed. When done
0-32
32
with CV67, select speed step 2 and program CV68. CV68's value must be
greater then CV67's. When done with CV67-CV94, use read back CV to make
0-2
0
sure their values are in increasing order.
Note: When using MRC Prodigy DCC to program addresses it will automatically
---
---
disable the speed table (set CV29's bit 4 to "0"). Programming CV125 to 1 will
---
2
also disable the speed table and re-program CV67-CV94 to a default linear
---
32
speed setting.
---
143
TROUBLE SHOOTING
192-231
192
This decoder should perform well with all DCC systems. The maximum DCC
0-255
3
output should be less than 15 V. If the locomotive does not respond to com-
0-127
0
mands, it may have lost its address. Please re-program the address and program
---
0
CV19 to 0 (disable consist). If it responds slowly, you should clear its momentum
by reprogramming CV3 and CV4 to zero. If step 1's speed is too high, you should
program start voltage, CV2 to zero. If its top speed is too slow, program top
0-1
1
voltage CV5 to 31. You should also clean the track to improve electrical pickup.
0-33
4
Read your DCC system manual to learn how to program and operate the decoder.
0-3
3
For more information about registers/CVs and their functions, please refer to the
0-7
3
NMRA DCC Standard & Recommended Practices, RP-9.2.2. This is available
0-3
3
directly from the NMRA or their website at www.nmra.org. Whenever the
0-50
3
decoder doesn't work please use the program track to program CV# 125 with
0-3
1
value 1 to restore the decoder to factory settings. This should bring the decoder
0-3
2
to life with address #3.
0-3
3
FCC COMPLIANCE
0-3
3
This device complies with part 15 of the FCC Rules. Operation is subject to the
0-3
3
following two conditions. (1) This device may not cause harmful interference,
0-3
3
and (2) This device must accept any interference received, including interfer-
0-3
3
ence that may cause undesired operation.
0-3
3
0-1
1
RETURN PROCEDURE
0-3
3
This decoder carries a 6 month warranty against factory defects. This warranty
0-63
63
does not include abuse, misuse, neglect, improper installation, or any modifications
1-255
linear
made to this decoder, including but not limited to the removal of the NMRA plug if
0-255
0
applicable. If it should become necessary to return the decoder for warranty repair/
0-255
0
replacement, please include a copy of the original sales receipt. Please
0-3
3
include a letter (printed clearly) with your name, address, daytime phone number,
0-3
3
and a detailed description of the problem you are experiencing. Please also include
0-1
1(enable)
a check or a money order for $8.00 to cover return shipping and handling. If the
0-1
0(disable)
decoder is no longer considered under warranty, then please include a check or a
money order for $29.00 to cover the cost of repair or replacement and return
0-2
0
shipping and handling. Be certain to return the decoder only.
0-6
0
Any questions regarding Warranty Policy can be directed to our Customer
0-6
0
Service Department by calling 732-225-6360 between the hours of 8:30am
and 6:00pm EST, or by emailing: rrtech@modelrectifier.com
0-3
0
Send the decoder to:
0-2
0
Model Rectifier Corporation
0-1
0
Attn: Parts & Service
---
0
80 Newfield Avenue
Edison, NJ 08837-3817 U.S.A
HO Gauge Synchronized
Diesel Sound Decoder For G.E. U23B
(With NMRA 8 pin plug and 9 pin JST connector)
Thank you for purchasing our highly advanced DCC locomotive
sound decoder. Combined with any DCC System, our new
decoder with "Carnegie Hall" sound quality will make your model
railroad come to life.
• Recorded from real G.E. U23B locomotive, plus extra
optional prime mover sound
• 1.5 amp capacity
•
Programmable choice of 34 different horns and 8 bells
• Programmable individual sound volumes
• Programmable for either 2-digit (1-127) or 4-digit
(1-9999) addresses
• Programmable start voltage, and top voltage
• Programmable acceleration rate, and deceleration
• Kick Start (CV 65)
• User programmable custom speed table (CV 67-94)
• Programmable 14, 28, 128 speed steps
• Selectable factory default speed curve
•
Directional lighting (FO) at 0.2 amp rate
•
Programmable for either ditch lights, mars light, gyra
light and prime strobe light
• 28 accessory functions (F1-F28)
• Supports advanced consisting (CV19)
• Supports full read back of CV's
• Supports programming on the main (OPS mode)
• Compatible with NMRA DCC standards
• NMRA 8 pin plug and 9 pin JST connector
• Complies with Part 15 of FCC
• 20mm speaker with baffle included (other size, aftermar-
ket speakers are available from MRC)
• Dimensions: 40.0mm x 17.0mm x 6.5mm
Printed in USA
Item #0001805
