5.2
Installation modes
The ISCOM HT803G-WS2 can be installed on a stable workbench or a wall.
Installing the ISCOM HT803G-WS2 on the workbench is
informal because unpredictable events (such as collision or object
falling) may prevent the ISCOM HT803G-WS2 from working
properly or even damage it. We recommend installing it on a wall.
Install the ISCOM HT803G-WS2 on a wall as below:
Step 1 Choose a proper height of installation position so that you can easily
observe LEDs and connect the power supply.
Step 2 Knock two cement nails, with spacing of 155 mm (distance between two
wall-mount holes), into the wall. The diameter of a cement nail should
be smaller than that of the wall-mount hole (8 mm).
Step 3 Align wall-mount holes with knocked cement nails, and hang the device
on nails. The device is hung by the nails on the wall.
Figure 5-1 Wall-mount installation
Step 4 Check by slightly shaking the device whether it is firmly installed on the
wall.
10
