MARUTI SUZUKI Maruti 800 Service Manual page 25

0B-6 MAINTENANCE AND LUBRICATION
F8D Engine
F8B Engine
Camshaft Timing Belt Replacement
Replace belt with new one. Refer to SECTION 6A or 6A1 for re-
placement procedure.
CAUTION:
D Do not bent or twist timing belt.
D Do not allow timing belt to come into contact with oil,
water, etc.
Valve Lash Inspection
1) Remove cylinder head cover.
2) Inspect intake and exhaust valve lash and adjust as necessary.
Refer to Section 6A or 6A1 for valve lash inspection and adjust-
ment procedure.
F8D Engine
Valve lash
(clearance) ( )
specifica-
Intake
tion
Exhaust
F8B Engine
Valve lash
(g (gap "a") )
specifica-
Intake
tion
Exhaust
3) Install cylinder head cover and tighten bolts to specification.
When cold
(Coolant temp. is (Coolant temp. is
15 – 25 C
or 59 – 77 F) or 140 – 154 F)
0.15 – 0.19 mm
(0.006 – 0.007 in.)
0.13 – 0.17 mm
(0.005 – 0.007 in.)
0.14 – 0.18 mm
(0.006 – 0.007 in.)
When cold
(Coolant temp. is (Coolant temp. is
15 – 25 C
or 59 – 77 F) or 140 – 154 F)
0.13 – 0.17 mm 0.15 – 0.19 mm
(0.005 – 0.007 in.) (0.006 – 0.007 in.)
0.15 – 0.19 mm 0.16 – 0.20 mm
(0.006 – 0.007 in.) (0.006 – 0.008 in.)
When hot
60 – 68 C
When hot
60 – 68 C
