1
Getting Started
For the S/PDIF Digital out, we suggest that you use a
coaxial cable that is specifically designed for S/PDIF
applications. These cables are better suited for high
frequency (digital) signals and are unbalanced, shielded
coaxial cables with shielded RCA connectors on each end.
Better to get the high quality S/PDIF cables and save
yourself some unnecessary grief.

Setting Levels

Before you can begin mixing different audio sources with your
MultiMix, you must set the level for each channel you're using.
This helps to prevent distortion and clipping. Here's how:
1. Slide the channel fader to unity gain (0).
2. Turn the AUX SEND and GAIN controls all the way down,
and turn the EQ knobs to the center detent (you'll feel a click).
3. Connect the source of the signal to the channel's input.
4. Press the PFL / SOLO switch on the channel.
5. Make sure the SOLO MODE switch in the master section is
set to SOLO.
6. Play the instrument at a normal level and watch the LED
meters in the master section.
7. Adjust the channel's gain until the LED meters remain at or
very close to 0 and do not exceed +6dB.
8. If you need to apply EQ, do so and check the meter again.
20
