What Is Tempo Sync; To Turn Tempo Sync Off - Alesis ModFX Phingr Reference Manual

What is Tempo Sync?

Flanging occurs over time. Sometimes, you'll want the rate of the
effect to match the beat of your music instead of being random.
For example, you can set the rate so that the flange effect
completes each cycle once per measure, or to a vibrato-like effect
that happens in sixteenth notes. The TEMPO SYNC feature of
the Alesis ModFX series not only lets you set a tempo naturally by
tapping on the TAP TEMPO button, it can automatically adjust its
speed slightly relative to the beat of the incoming audio signal,
after setting the basic speed using the TAP button.
To use Tempo Sync:
You can set the Phlngr to TEMPO SYNC mode as follows:
1. Press the down side of the [MODULATION] rocker switch to
select the next modulation type.
You can see the type of effect by the LED lit next to the name—for
example, TRIANGLE, HYPER TRI, TRIGGERED and so on.
2. Keep pressing the rocker switch through all the normal modes
until you enter TEMPO SYNC mode, and then advance to the
type of modulation you want.
Both the Mod Type and TEMPO SYNC LEDs will be lit. For
example, if you press the down side of the rocker switch when you're in
PATTERN mode, the Phlngr will go to TRIANGLE/TEMPO
SYNC mode. At this point, the TAP TEMPO LED will start
flashing at the last speed it was set at (or will light solid, indicating that
no tempo has been set since the unit was turned on).
3. Tap the [TAP TEMPO] button several times to set the desired
tempo.
The TAP TEMPO LED will flash in time to the hits. As long as
the [RATE] control is in the center position, the flanging speed will
match the tempo.
4. If the tempo isn't quite right, "tap" a steady, discrete beat on
any instrument connected to the input. The internal processor
will then synchronize the tapped tempo with the audio input.
The processor will make slight alterations to the tempo such
that it stays synchronized with the beat of the audio input.

To turn Tempo Sync off:

Simply press the UP side of the [MODULATION] switch
repeatedly until the Tempo Sync LED goes off, then select the
modulation waveform you want.
Using the Phlngr
The RATE knob is
different in Tempo
sync mode
I n TEMPO S YNC m od e, th e
RATE kn o b ac ts as a
m ultiplier to the s p ee d s et b y
TAP TEMPO, s o y ou c a n' t
g et the te mp o to ch a ng e
s ligh tly b y a djus tin g th a t
k no b. Note tha t ch a ng es to
RATE wo n 't a ffe ct th e
fla sh in g o f the TEMPO LED .
