Connections
Connecting to the Main Outputs of a mixing
console:
In addition to channel inserts, most mixing consoles have main
insert jacks near the main outputs. You can use insert cables to
connect the Phlngr to the main L/R bus the same way you
connect it to a pair of channels. Simply connect one insert cable
to the left main insert of the mixer, and connect the two mono
jacks to the left INPUT and OUTPUT of the Phlngr. Use another
insert cable to connect the right main insert to the right INPUT
and OUTPUT of the Phlngr.
Alternatively, you could plug the mixing console's main outputs
directly into the Phlngr's inputs, then feed the Phlngr's outputs to
your monitor amps or mixdown recorder. However, if you fade
down the volume at the end of the song, the sound quality may
change as you fade. This is why it's better to use the insert jacks, if
available.
