The REAL 6100 PLUS is a Class I medical device. It is CE marked in accordance with the Swedish Medical Products
Agency's code of statutes for medical devices, LVFS 2003:11, and has been tested and approved in accordance with
EN 12184, Class A. All textiles used for the chair have been tested and approved in accordance with EN 1021-1 and EN
1021-2. Mercado Medic AB is certified to ISO 9001, ISO 14001 and ISO 13485 and complies with applicable labour and
environmental legislation.
If you have any questions about your product or if something unexpected has happened, please contact your dealer
first, otherwise you are welcome to contact us at Mercado Medic AB.
PDF versions of our instructions for use and care with magnification options can be found on our website:
www.mercado.se. Information is also provided on the website about accessories that can be installed on Mercado
Medic's chairs, as well as any field safety notices, prescribing support or recalls of products and accessories.
We reserve the right to make changes to this manual and its contents.
Sufficient competence in the safe use of this product is achieved by carefully reading
through these instructions for use and care before using the chair for the first time.
INSTRUCTIONS FOR USE AND MAINTENANCE
REAL 6100 PLUS with the Shark control unit

TABLE OF CONTENTS

Important information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Expected service life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Checkpoints before operation . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Storage, cleaning and maintenance . . . . . . . . . . . . . . . . . . . . . . . 4
for REAL 6100 PLUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Transfers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Your REAL 6100 PLUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Shark control unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Troubleshooting & actions for Shark . . . . . . . . . . . . . . . . . . . . . 14
Programming schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Instructions for destruction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Mercado Medic AB products . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Doc.no.
20-07457-UK-02
Amended
2020-12-04
Valid from
2011-12-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the REAL 6100 plus and is the answer not in the manual?

Questions and answers

Related Manuals for Mercado Medic REAL 6100 plus

Summary of Contents for Mercado Medic REAL 6100 plus

  • Page 1: Table Of Contents

    Technical information and measurements for REAL 6100 PLUS ....... . . 4 Transfers .

  • Page 3: Important Information

    • Chairs with an adjustable seat tilt must be in a fixed position when transferring to or from the chair. • The REAL 6100 PLUS must not be operated when the seat is in the raised position. If the seat is raised, the obstacle-climb- ing capability may be reduced as the chair runs more slowly and less power reaches the drive wheels.

  • Page 4: Checkpoints Before Operation

    Remove any dirt, crumbs and similar. from Mercado Medic AB. Apply a thin layer of foam and rub the foam in evenly with a damp cloth. TECHNICAL INFORMATION AND MEASUREMENTS FOR REAL 6100 PLUS TECHNICAL INFORMATION STANDARD DIMENSIONS, CONTINUED Maximum user weight...

  • Page 5: Transfers

    TRANSFERS TRANSFERRING TO AND FROM THE CHAIR Please note: Always consult your prescriber for advice on the most suitable technique for transferring to and from the wheelchair, from the front or the side. What best suits you and your needs and thus minimises the risk of injury.

  • Page 6: Your Real 6100 Plus

    YOUR REAL 6100 PLUS 1. Backrest adjustable in height, angle and depth. 2. Armrests adjustable in width and height. 3. Control unit (also controls electrical seat functions). 4. Seat adjustable in height. Seat tilt is available as an accessory. 5. Drive wheels, puncture free.
  • Page 7 ARMRESTS The user can adjust the height and width of the CONTROLS armrests. If the chair has foldable armrests, these 1. Height. To adjust the height of an armrest, loosen the knob (1). Pull/ can also be folded backwards. press the armrest to the desired height. Then tighten the knob. 2.
  • Page 8 TRANSPORT IN VEHICLE When transporting the by car, The chair is not suitable for sitting in during REAL 6100 PLUS the user must transfer to the vehicle seat. During transport. transport, the chair must be equipped with transport loops and must be secured using the tension straps on the transport vehicle.
  • Page 9 SEAT TILT THERE ARE THREE TYPES OF SEAT TILT: CONTROLS Gas spring, crank-operated and electric tilt. 1. Gas spring under armrest. The gas spring control is located under one of the 2. Gas spring under seat. armrests (1) or under the right rear edge of the seat 3.
  • Page 10 FOOTPLATE The height and the angle of the footplate can CONTROLS be adjusted. 1. Height. Loosen the knob (1) to adjust the height of the foot- plate. Then pull or push the footplate to the desired height 2. Leg support angle. The angle of the leg support can be adjusted to four different positions.

  • Page 11: Shark Control Unit

    SHARK CONTROL UNIT MANOEUVRING DRIVING TO LOCK THE SHARK CONTROL UNIT Turn on the main switch (1). Check the battery level (4). The battery level should not be down to the red When the control unit is switched on, hold down the marking.

  • Page 12: Charging

    CHARGING DAILY USE Connect the charger's charging plug to the charging jack on the control unit and the power cord to the wall socket. The charger indicates charging ongoing and charging completed. ! Remember to unplug the charging plug before using the chair. Charge the chair for at least 12 hours prior to initial use.

  • Page 13: Service And Troubleshooting Of Shark Control Unit

    CONTINUED CHARGING IMPORTANT INFORMATION • The charger is equipped with protection against • The charger complies with the following standards: EN incorrect polarity, the short-circuiting of battery cables, 60601-1, EN 60601-1-2, EN 12184, ISO 7176-14. mains/battery sparking, and overheating The combination of chair and charger also complies with ISO 7176-21.

  • Page 14: Troubleshooting & Actions For Shark

    TROUBLESHOOTING & ACTIONS FOR SHARK 1 FLASHING SIGNAL – USER ERROR 8 FLASHING SIGNAL - SHARK POWER MODULE FAILURE Timeout, motor failure, or user error. Release the joystick Check cords and connections on the SHARK control so it goes into neutral mode and try operating again. unit.

  • Page 15: Service & Troubleshooting Of Real 6100 Plus

    SERVICE & TROUBLESHOOTING OF REAL 6100 PLUS SYMPTOM CAUSE ACTION Control unit does not work Control unit broken Reprogram or replace it Control unit does not work Cabling broken Replace Control unit does not work Battery Replace Wheels are not moving...

  • Page 16: Checklist Reconditioning And Service Real 6100 Plus

    CHECKLIST RECONDITIONING AND SERVICE REAL 6100 PLUS Important information: The Product does not require periodic maintenance in cases where it has a responsible prescriber in the healthcare sector. In markets outside of Sweden and Norway where a distributor has sold the Product directly to the user (where applicable), and therefore there is no responsible prescriber, periodic maintenance must be carried out every other year during the Product’s entire life cycle according to sections 1-12 in this section.

  • Page 17: Instructions For Destruction

    CHECKLIST RECONDITIONING AND SERVICE REAL 6100 PLUS, CONT. 7. Seat frame 8. Backrest mechanism … 9.4. Armrest mechanics/function Check all welds and that there is no … 7.1. Mechanics/welds … 8.1. Function/wear damage to the tube system that may Thoroughly inspect all welded Check and replace any worn parts, impair or weaken the structure.

  • Page 20: Guidelines For Individual Customisations Of

    Mercado Medic AB for written approval. Parts to be evaluated must be sent physically to Mercado Medic AB, either by the customer or the supplier of the part in question. Mercado Medic AB will then contact the supplier of the part in question. If a combination agreement is of interest, Mercado Medic AB will conduct a risk analysis on the desired part.
