MOZA Mini-P Expanding & Folding Tutorial
Content

Expanding:

Expanding your Mini-P gimbal, please click and follow the steps as shown.
Folding your Mini-P gimbal, please click and follow the steps as shown.
Expanding
1. As shown in the figures below, loosen slide lock, rotate gimbal 180°anticlockwise, then it locks
automatically.
2. As shown in the figures below, push ejector pad on Roll arm to unlocked position, move Tilt arm
upwards and then fasten Tilt knob.
3. As shown in the figures below, loosen Roll knob, raise Roll arm to keep it out of groove of Pan
motor crash pad, push down Pan motor lock and then you are ready to film now.
© 2020 GUDSEN All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOZA Mini-P and is the answer not in the manual?

Questions and answers

Related Manuals for Gudsen MOZA Mini-P

Summary of Contents for Gudsen MOZA Mini-P

  • Page 1 MOZA Mini-P Expanding & Folding Tutorial Content Expanding: Expanding your Mini-P gimbal, please click and follow the steps as shown. Folding: Folding your Mini-P gimbal, please click and follow the steps as shown. Expanding 1. As shown in the figures below, loosen slide lock, rotate gimbal 180°anticlockwise, then it locks automatically.
  • Page 2 Tilt knob and then push ejector pad to locked position. 3. As shown in the figure below, rotate Pan arm, place Pan knob at outer side and push up Pan © 2020 GUDSEN All Rights Reserved.
  • Page 3 4. As shown in the figures below, loosen slide lock, rotate gimbal 180°along the direction of slide lock, then it locks automatically 5. Operation of folding Mini-P is completed. © 2020 GUDSEN All Rights Reserved.
  • Page 4 © 2020 GUDSEN All Rights Reserved.
