Gudsen MOZA iFocus Wireless Lens Control System Upgrade Tutorial

System Upgrade Tutorial for MOZA iFocus Wireless Lens Control.

Notice:

1. MOZA iFocus firmware cannot be upgrade separately.

To upgrade the iFocus you will need to use a

2 Gimbal

MOZA Wireless Handunit.

2. MOZA iFocus cannot upgrade with MOZA Aircross 2

gimbal currently.

3. Our official video tutorial for this document:

https://www.youtube.com/watch?v=b9R8uTDou_Q&t=313s

Download Software:

Please download MOZA Master Software on your computer and install the software following the

steps below:

https://www.gudsen.com/upfile/admin/file/download/MOZA-Master-1.3.0-Tutorial.pdf?v1

Upgrading iFocus with MOZA Air 2 Gimbal:

1. Turn off the iFocus Motor and Air 2 Gimbal.

2. Connect the Air 2 Gimbal and iFocus via Multi-CAN cable (Fig 2), then connect the Air 2 Gimbal

to the computer via USB Type-C cable (Fig 1).

Fig3. IFocus Motor in Boot Mode

MOZA Air

Fig1. Connect Air 2 Gimbal, iFocus

and Computer

Fig2. Connect to the multi-can connector on Air 2 Gimbal

Fig4. Air 2 Gimbal in Boot Mode

Table of Contents

Do you have a question about the MOZA iFocus Wireless Lens Control and is the answer not in the manual?

Page 1 System Upgrade Tutorial for MOZA iFocus Wireless Lens Control. Notice: 1. MOZA iFocus firmware cannot be upgrade separately. To upgrade the iFocus you will need to use a MOZA Air 2 Gimbal MOZA Wireless Handunit. 2. MOZA iFocus cannot upgrade with MOZA Aircross 2 gimbal currently.
Page 2 6. The software will automatically open the upgrade interface. After the firmware has downloaded, click the “upgrade” button. Upgrading can take about 30 seconds. 7. During the upgrade, the screen will display “Upgrading”. Once the upgrade is complete, the screen will display “Upgrade Success”. © 2020 GUDSEN All Rights Reserved.
Page 3 Then press the power button (hold the top button in and then press the power button at the same time) “Boot Mode” will be displayed on the Wireless Handunit‟s screen. Now, the Wirelsss Handunit is in boot mode. 5. Launch the MOZA Master software, select “iFocus” from the device list. © 2020 GUDSEN All Rights Reserved.
Page 4 Power on the iFocus. The iFocus status LED light will flash blue, please wait about 10 seconds for calibration to finish. Once calibration is finished about 10 seconds, please power off the iFocus. 10. Reboot the Wireless Handunit and iFocus. Now, the Wireless Handunit and iFocus firmware upgrade is finished. © 2020 GUDSEN All Rights Reserved.
